SPECIFICATIONS
| Application | Specification |
| Compressor Type | ZEXEL DKS-17CH |
| Compressor Belt Tension | (1) |
| Compressor Oil Capacity (2) (3) |
| Initial Fill | 6.8 ozs. (180ml) |
| Compressor | 2.4 ozs. (70ml) |
| Receiver/Drier | 1 oz. (30ml) |
| Evaporator Core | 1.7 oz. (50ml) |
| Condenser | 1 oz. (30ml) |
| High Or Low Pressure Hose | .4 oz. (10ml) |
| Refrigerant (R-134a) Capacity | 35.2 ozs. (1000 grams) |
| System Operating Pressures (4) |
| High Side | 406-464 psi (28.0-32.0 kg/cm 2 ) |
| Low Side | 25.4-32.6 psi (1.75-2.25 kg/cm 2 ) |
| (1) Belt tension is maintained by automatic belt tensioner. (2) Use PAG Oil (Part No. 11 61 407) (3) When replacing parts add specified amount of PAG oil for replaced part. When replacing condenser drain any oil first, and refill with specified amount. (4) Pressure switch cut-out points. |
| (1) | Belt tension is maintained by automatic belt tensioner. |
| (2) | Use PAG Oil (Part No. 11 61 407) |
| (3) | When replacing parts add specified amount of PAG oil for replaced part. When replacing condenser drain any oil first, and refill with specified amount. |
| (4) | Pressure switch cut-out points. |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
| A/C Pressure Sensor | 13 (18) |
| Compressor Pipe Fittings | 16 (22) |
| Condenser Bracket Bolts | 30 (40) |
| Condenser Hoses | 18 (25) |
| INCH Lbs. (N.m) |
| Center Console Screws | 44 (5) |
| Clutch Plate Bolt | 106 (12) |
| Compressor-To-Core Support Bolts | 88 (10) |
| Receiver-Drier Fittings | 88 (10) |
Automatic A/C-Heater System Wiring Diagram (2000 S80 - 1 Of 2). Scheme 1
Scheme 1: Automatic A/C-Heater System Wiring Diagram (2000 S80 - 1 Of 2)
Automatic A/C-Heater System Wiring Diagram (2000 S80 - 2 Of 2). Scheme 2
Scheme 2: Automatic A/C-Heater System Wiring Diagram (2000 S80 - 2 Of 2)
Automatic A/C-Heater System Wiring Diagram (2001 S60, S80 & V70 - 1 Of 2). Scheme 3
Scheme 3: Automatic A/C-Heater System Wiring Diagram (2001 S60, S80 & V70 - 1 Of 2)
Automatic A/C-Heater System Wiring Diagram (2001 S60, S80 & V70 - 2 Of 2). Scheme 4
Scheme 4: Automatic A/C-Heater System Wiring Diagram (2001 S60, S80 & V70 - 2 Of 2)
