Communication System: Removal & Installation Subaru Outback BR рестайлинг

INSTALLATION

1. Install each part in the reverse order of removal. Tightening torque: Horn assembly: 18 N.m (1.84 kgf-m, 13.3 ft-lb)
2. Adjust the fog light beam. (Model with fog light) Refer to «FOG LIGHT AIMING»(ref-565206-S26614077792013071000000) .

Scheme 29

1. Remove the horn assembly (Hi pitch side and Lo pitch side). Refer to «REMOVAL»(ref-565216-S24369614522013071000000) .
2. Check the horn sounds when applying the battery voltage to the horn assembly. Terminal No. Inspection conditions Specification 1 (+) - Horn case (-) Connect battery to the terminals Sounds
3. If it does not operate normally, replace the horn assembly.

REMOVAL

Note. Horn switch is a unit with the driver's airbag module.

Scheme 30

Scheme 31

1. Position the front wheels straight ahead. (After moving a vehicle 5 m (16 ft) or more with front wheels positioned straight ahead, make sure that the vehicle moves straight ahead.)
2. Turn the ignition switch to OFF.
3. Disconnect the ground cable from battery and wait for at least 60 seconds before starting work.
4. Remove the driver's airbag module assembly. CAUTION: Before handling the airbag module, refer to «CAUTION»(ref-565203-S06105343772013071000000) . Using a hexagon wrench etc. wrapped by protective tape, insert the snap pins and release the locks (3 locations). Disconnect the horn harness and airbag connector and remove the airbag module assembly. Refer to «DRIVER' AIRBAG MODULE, CURTAIN AIRBAG MODULE, PRETENSIONER & LAP SEAT BELT PRETENSIONER»(ref-565203-S37682674332013071000000) .

1. Install the driver's airbag module. Refer to «INSTALLATION»(ref-565203-S14114280362013071000000) .
2. Install each part in the reverse order of removal.

Scheme 32

1. Remove the horn switch. Refer to «REMOVAL»(ref-565216-S23568070672013071000000) .
2. Check that the connection of the horn switch harness connector is correct.
3. Disconnect the horn switch harness connector and check the resistance between the harness connectors. Preparation tool: Circuit tester Terminal No. Inspection conditions Standard Ground terminal (a) - Horn switch terminal (b) The airbag module bracket being pushed Less than 1 ohms The airbag module bracket being separated 1 Mohms or more
4. Replace the driver's airbag module if the inspection result is not within the standard value.

Scheme 33

1. Remove the roll connector. Refer to «REMOVAL»(ref-565203-S00591760812013071000000) .
2. Check the resistance between roll connector terminals. Preparation tool: Circuit tester Terminal No. Inspection conditions Standard A1 - C6 Always Less than 1 ohms
3. Replace the roll connector if the inspection result is not within the standard value.
