Engine Lubrication System (H6DO): Removal & Installation Subaru Outback BR рестайлинг

REPLACEMENT

Scheme 62

1. Open the engine oil filler cap for quick draining of engine oil.
2. Lift up the vehicle.
3. Remove the under cover. Refer to «REMOVAL»(ref-565181-S28182960572013071000000) .
4. Drain engine oil by loosening the engine oil drain plug. NOTE: Prepare the container for draining of engine oil.
5. Tighten the engine oil drain plug after draining engine oil. NOTE: Use a new drain plug gasket. Tightening torque: 44 N.m (4.5 kgf-m, 32.5 ft-lb)
6. Install the under cover. Refer to «INSTALLATION»(ref-565181-S36610771312013071000000) .
7. Lower the vehicle.
8. Using engine oil of proper quality and viscosity, fill engine oil through the oil filler duct to the "F" line on level gauge. Make sure that the vehicle is parked on a level surface when checking oil level. Recommended oil: Refer to «SPECIFICATION»(ref-565157-S14125166312013071000000) . Engine oil capacity: Refer to «SPECIFICATION»(ref-565157-S14125166312013071000000) .
9. Close the engine oil filler cap.
10. Start the engine to circulate the oil in engine.
11. After the engine stops, recheck the oil level. If necessary, add engine oil up to the "F" line on level gauge.

Scheme 63

REMOVAL

Note. Before removing the oil pan upper, remove the engine from vehicle. Refer to REMOVAL and REMOVAL .

Scheme 64

1. Lift up the vehicle.
2. Remove the under cover. Refer to «REMOVAL»(ref-565181-S28182960572013071000000) .
3. Drain the engine oil. Refer to «REPLACEMENT»(ref-565157-S20989681072013071000000) .
4. Insert an oil pan cutter blade into the gap between oil pan upper and oil pan lower, and remove the oil pan. CAUTION: Do not use a screwdriver or similar tool in place of oil pan cutter.
5. Remove the oil pan lower.

Scheme 65

Scheme 66

1. Apply liquid gasket to the mating surfaces of oil pan, and install the oil pan lower. NOTE: Install within 5 min. after applying liquid gasket. Liquid gasket: THREE BOND 1217G (Part No. K0877Y0100) or equivalent Liquid gasket applying diameter: 5.0±1.0 mm (0.197±0.039 in)
2. Tighten the oil pan lower installing bolts in the numerical order as shown in the figure. Tightening torque: 6.4 N.m (0.7 kgf-m, 4.7 ft-lb)
3. Install the under cover. Refer to «INSTALLATION»(ref-565181-S36610771312013071000000) .
4. Lower the vehicle.
5. Refill the engine oil. Refer to «REPLACEMENT»(ref-565157-S20989681072013071000000) .
6. Check the engine oil level. Refer to «INSPECTION»(ref-565157-S31963468742013071000000) .

Scheme 67

1. Lift up the vehicle.
2. Drain the engine oil. Refer to «REPLACEMENT»(ref-565157-S20989681072013071000000) .
3. Remove the under cover. Refer to «REMOVAL»(ref-565181-S28182960572013071000000) .
4. Remove the engine oil filter using the ST. ST 18332AA020 OIL FILTER WRENCH

INSTALLATION

1. Clean the engine oil filter installation surface of the oil cooler.
2. Obtain a new engine oil filter and apply a thin coat of engine oil to the seal rubber.
3. Install the engine oil filter turning it by hand, being careful not to damage the seal rubber.
4. Tighten more (approx. 3/4 turn) after the seal rubber contacts the oil cooler. When using a torque wrench, tighten to 14 N.m (1.4 kgf-m, 10.3 ft-lb).
5. Install the under cover. Refer to «INSTALLATION»(ref-565181-S36610771312013071000000) .
6. Lower the vehicle.
7. Refill the engine oil. Refer to «REPLACEMENT»(ref-565157-S20989681072013071000000) .
8. Check the engine oil level. Refer to «INSPECTION»(ref-565157-S31963468742013071000000) .

Scheme 68

Scheme 69

1. Lift up the vehicle.
2. Remove the under cover. Refer to «REMOVAL»(ref-565181-S28182960572013071000000) .
3. Drain engine coolant. Refer to «DRAINING OF ENGINE COOLANT»(ref-565167-S19351012342013071000000) .
4. Drain the engine oil. Refer to «REPLACEMENT»(ref-565157-S20989681072013071000000) .
5. Remove the bolts which hold the engine oil cooler water pipe to chain cover and disconnect the water hose from oil cooler.
6. Remove the engine oil filter using the ST. Refer to «REMOVAL»(ref-565157-S06527211262013071000000) . ST 18332AA020 OIL FILTER WRENCH
7. Remove the oil cooler connector and remove the oil cooler.

Scheme 70

Scheme 71

1. Tighten the oil cooler connector to install the oil cooler to the oil pan upper. Tightening torque: 54 N.m (5.5 kgf-m, 39.8 ft-lb) NOTE: Use new O-rings.
2. Attach the engine oil filter. Refer to «INSTALLATION»(ref-565157-S00350399162013071000000) .
3. Attach the bolts which hold the engine oil cooler water pipe to chain cover and connect the water hose to oil cooler. Tightening torque: T: 6.4 N.m (0.7 kgf-m, 4.7 ft-lb)
4. Install the under cover. Refer to «INSTALLATION»(ref-565181-S07136545222013071000000) .
5. Lower the vehicle.
6. Fill the ATF. Refer to «FILLING OF ENGINE COOLANT»(ref-565167-S04263119292013071000000) .
7. Refill the engine oil. Refer to «REPLACEMENT»(ref-565157-S20989681072013071000000) .
8. Check the engine oil level. Refer to «INSPECTION»(ref-565157-S31963468742013071000000) .
