SPECIFICATION
| Lubrication method | Forced lubrication | ||||
|---|---|---|---|---|---|
| Oil pump | Pump type | Trochoid type | |||
| Number of teeth | Inner rotor | 11 | |||
| Outer rotor | 12 | ||||
| Outer rotor diameter x thickness | Mm (in) | 77 x 12 (3.03 x 0.47) | |||
| Performance (Oil temperature 120°C (248°F)) | 600 rpm | Discharge pressure | KPa (kgf/cm 2 , psi) | 30 (0.3, 4.3) | |
| Discharge rate | L (US qt, Imp qt)/min. | 6 (6.3, 5.3) or more | |||
| 6, 000 rpm | Discharge pressure | KPa (kgf/cm 2 , psi) | 260 (2.7, 37.7) | ||
| Discharge rate | L (US qt, Imp qt)/min. | 47 (49.7, 41.4) or more | |||
| Relief valve working pressure (2-step relief) | 1st opening pressure | KPa (kgf/cm 2 , psi) | 150 (1.5, 21.7) | ||
| Main opening pressure | KPa (kgf/cm 2 , psi) | 570 (5.8, 82.6) | |||
| Oil filter | Filter type | Full-flow filter type | |||
| Filtration area | Cm 2 (sq in) | 867 (134.3) | |||
| By-pass valve opening pressure | KPa (kgf/cm 2 , psi) | 160 (1.6, 23.2) | |||
| Outer diameter x width | Mm (in) | 67.4 x 87.1 (2.65 x 3.43) | |||
| Installation screw specifications | M 20 x 1.5 | ||||
| Oil pressure switch | Type | Immersed contact point type | |||
| Operating voltage | 12 V | ||||
| Warning light operating pressure | KPa (kgf/cm 2 , psi) | 14.7 (0.1, 2.1) | |||
| Proof pressure | KPa (kgf/cm 2 , psi) | 981 (10, 142.2) or more | |||
| Engine oil | Total capacity (at overhaul) | L (US qt, Imp qt) | 5.7 (6.0, 5.0) | ||
| When replacing engine oil and oil filter | L (US qt, Imp qt) | 4.8 (5.1, 4.2) | |||
| When replacing engine oil only | L (US qt, Imp qt) | 4.6 (4.9, 4.0) | |||
Specified oil
| CAUTION | Use 0W-20 (synthetic oil). It is acceptable to fill an engine with oil of another brand when replacing the oil, but make sure to use the following engine oil specified by Subaru. |
Engine oil standard SAE viscosity No. Those with the API standard SM "Energy Conserving" or SN "Resource Conserving" logo. or Those with the ILSAC standard GF-4 or GF-5 "starburst mark" displayed on top of the container. 0W-20 (synthetic oil)
Scheme 20
Note. The proper viscosity oil helps the engine maintain its ideal temperature, and cranking speed increased by reducing viscosity friction in hot condition.
Scheme 21
Tightening torque: N.m (kgf-m, ft-lb)
T1: 6.4 (0.7, 4.7)
T2: 10 (1.0, 7.4)
T3: 41.7 (4.3, 30.8)
T4: Refer to OIL PAN.
T5: Refer to OIL PAN UPPER.
Scheme 22
Tightening torque: N.m (kgf-m, ft-lb)
T1: 6.4 (0.7, 4.7)
T2: 18 (1.8, 13.3)
T3: 45 (4.6, 33.2)
The oil pump cannot be disassembled.
Refer to "Chain Cover" for removal and installation procedures. See REMOVAL and INSTALLATION.
Scheme 23
Scheme 24
- Disconnect the ground cable from battery.
- Lift up the vehicle.
- Remove the under cover. Refer to «REMOVAL»(ref-565181-S28182960572013071000000).
- Drain the engine oil. Refer to «REPLACEMENT»(ref-565156-S42948795322013071000000).
- Remove the front exhaust pipe. Refer to «REMOVAL»(ref-565184-S34357625012013071000000).
- Remove the bolts which secure oil pan to oil pan upper.
- Insert an oil pan cutter blade into the gap between oil pan upper and oil pan, and remove the oil pan. CAUTION: Do not use a screwdriver or similar tool in place of oil pan cutter.
Scheme 25
Scheme 26
Scheme 27
- Remove the engine from the vehicle. Refer to «REMOVAL»(ref-565160-S20320245162013071000000).
- Remove the water pump. Refer to «REMOVAL»(ref-565166-S22975881782013071000000).
- Remove the thermostat cover. Refer to «REMOVAL»(ref-565166-S09692638042013071000000).
- Remove the water pipe assembly. Refer to «WATER PUMP»(ref-565166-S01316759882013071000000).
- Remove the oil pan. Refer to «OIL PAN»(ref-565156-S27635577642013071000000).
- Remove clip (A) from the oil pan upper, and remove the oil level switch.
- Remove the bolts which secure oil pan upper to cylinder block, and remove the oil pan upper.
- Remove the baffle plate from the oil pan upper.
- Remove the oil strainer from the oil pan upper.
- Remove stud bolts from the oil pan upper.
