SPECIFICATION
| Lubrication method | Forced lubrication | ||||
|---|---|---|---|---|---|
| Oil pump | Pump type | Trochoid type | |||
| Number of teeth | Inner rotor | 7 | |||
| Outer rotor | 8 | ||||
| Outer rotor diameter x thickness | Mm (in) | 76 x 30.2 (2.99 x 1.19) | |||
| Performance (Oil temperature 80°C (176°F)) | 600 rpm | Discharge pressure | KPa (kgf/cm 2 , psi) | 98 (1.0, 14) | |
| Discharge rate | L (US qt, Imp qt)/min. | 5.0 (5.3, 4.4) or more | |||
| 6, 000 rpm | Discharge pressure | KPa (kgf/cm 2 , psi) | 392 (4.0, 57) | ||
| Discharge rate | L (US qt, Imp qt)/min. | 82.8 (87.5, 72.9) or more | |||
| Oil filter | Filter type | Full-flow filter type | |||
| Filtration area | Cm 2 (sq in) | 1, 300 (201.5) | |||
| By-pass valve opening pressure | KPa (kgf/cm 2 , psi) | 160 (1.63, 23.2) | |||
| Outer diameter x width | Mm (in) | 80 x 75 (3.15 x 2.95) | |||
| Installation screw specifications | M 20 x 1.5 | ||||
| Oil pressure switch | Type | Immersed contact point type | |||
| Operating voltage - power consumption | 12 V - 3.4 W or less | ||||
| Warning light operating pressure | KPa (kgf/cm 2 , psi) | 14.7 (0.15, 2.1) | |||
| Proof pressure | KPa (kgf/cm 2 , psi) | 980 (10.0, 142) or more | |||
| Engine oil | Total capacity (at overhaul) | L (US qt, Imp qt) | 7.8 (8.2, 6.9) | ||
| When replacing engine oil and oil filter | L (US qt, Imp qt) | 6.5 (6.9, 5.7) | |||
| When replacing engine oil only | L (US qt, Imp qt) | 6.3 (6.7, 5.5) | |||
Recommended oil
| CAUTION | It is acceptable to fill an engine with oil of another brand when replacing the oil, but make sure to use the following engine oil specified by Subaru. |
Engine oil standard Those with the API standard SM "Energy Conserving" or SN "Resource Conserving" logo. or Those with the ILSAC standard GF-4 or GF-5 "starburst mark" displayed on top of the container. SAE viscosity No
Scheme 44
Scheme 45
Note. The proper viscosity oil helps the engine maintain its ideal temperature, and cranking speed increased by reducing viscosity friction in hot condition.
Scheme 46
Tightening torque: N.m (kgf-m, ft-lb)
T1: 6.4 (0.7, 4.7)
T2: 17 (1.7, 12.5)
T3: 23 (2.3, 17.0)
T4: 25 (2.5, 18.4)
T5: 34 (3.5, 25.1)
T6: 44 (4.5, 32.5)
T7: 54 (5.5, 39.8)
T8: 60 (6.1, 44.3)
T9: 90 (9.2, 66.4)
Scheme 47
Tightening torque: N.m (kgf-m, ft-lb)
T1: 6.4 (0.7, 4.7)
T2: 13 (1.3, 9.6)
T3: 24 (2.4, 17.7)
T4: 120 (12.2, 88.5)
