INSPECTION
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK COMBINATION METER. Turn the ignition switch to ON. (engine OFF) Check the warning light in the combination meter. | Does the warning light illuminate? | Go to step 2 . | Repair or replace the combination meter. Refer to INSPECTION . |
| 2 CHECK HARNESS CONNECTOR BETWEEN COMBINATION METER AND OIL PRESSURE SWITCH. Turn the ignition switch to OFF. Disconnect the connector from oil pressure switch. Turn the ignition switch to ON. Measure the voltage of harness between oil pressure switch connector and chassis ground. Connector & terminal (E11) No. 1 (+) - Chassis ground (-) | Is the voltage 10 V or more? | Replace the oil pressure switch. Refer to OIL PRESSURE SWITCH . | Go to step 3 . |
| 3 CHECK COMBINATION METER. Turn the ignition switch to OFF. Remove the combination meter. Measure the resistance of combination meter. Terminals No. 19 - No. 8 | Is the resistance less than 10 ohms? | Repair the harness and connector. NOTE: In this case, repair the following item: Open circuit of harness between combination meter and oil pressure switch Poor contact of combination meter connector Poor contact of oil pressure switch connector Poor contact of coupling connector | Repair or replace the combination meter. Refer to INSPECTION . |
| NOTE |
|---|
| In this case, repair the following item: Open circuit of harness between combination meter and oil pressure switch Poor contact of combination meter connector Poor contact of oil pressure switch connector Poor contact of coupling connector |
| CAUTION | If the engine oil is spilt over exhaust pipe or the under cover, wipe it off with cloth to avoid emitting smoke or causing a fire. |
Scheme 28
- Park the vehicle on a level surface.
- Remove the oil level gauge and wipe away the oil.
- Reinsert the oil level gauge all the way. Be sure that the oil level gauge is correctly inserted and properly orientated.
- Pull out the oil level gauge again, and check both sides of the oil level gauge. Use a lower side to determine the engine oil level. If the engine oil level is below "L" line, check for oil leakage from engine and add oil to bring the level up to "F" line.
- Start the engine to circulate the oil in engine.
- After turning off the engine, wait a few minutes for the oil to return to the oil pan before checking the level. NOTE: To prevent overfilling of engine oil, do not add oil above "F" line when the engine is cold. As the oil level gauge is used for daily maintenance, "F" line and "L" line is set assuming that the engine is cold.
Check that the oil pan, oil pan upper, oil strainer and baffle plate do not have deformation, cracks or damage.
- Check that the oil pressure switch does not have deformation, cracks or damage.
- Check the oil pressure switch installation portion for oil leakage and oil seepage.
- After installing the oil filter, run the engine and check for oil leakage. NOTE: The filter element and filter case are permanently jointed; therefore, interior cleaning is not necessary.
- Check the engine oil level. Refer to «INSPECTION»(ref-565156-S27761349082013071000000) .
Scheme 29
- Disconnect the ground cable from battery.
- Lift up the vehicle.
- Remove the under cover. Refer to «REMOVAL»(ref-565181-S28182960572013071000000) .
- Drain the engine oil. Refer to «REPLACEMENT»(ref-565156-S42948795322013071000000) .
- Disconnect the oil level switch connector from the engine harness, and remove the clip (A) securing the harness.
- Remove clip (A) from the oil pan upper, and remove the oil level switch.
INSPECTION WHILE LOW ENGINE OIL LEVEL WARNING LIGHT IS ON
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK ENGINE OIL LEVEL. | Is engine oil level normal? | Go to step 2 . | Replace engine oil or refill, and check again while the oil level is normal condition. Refer to REPLACEMENT . To turn off the low engine oil level warning light, install the spare fuse at the delivery (test) mode fuse in the main fuse box. Then turn the ignition switch to ON (engine off) again, to confirm the low engine oil level warning light turns off. Remove the spare fuse installed to finish. NOTE: The engine oil level switch is normal if the low engine oil level warning light turns off with the delivery (test) mode fuse inserted. |
| 2 CHECK LAN SYSTEM. | Has a DTC of the LAN system been input? | Perform the diagnosis according to DTC. | Go to step 3 . |
| 3 CHECK OIL LEVEL SWITCH CIRCUIT. Turn the ignition switch to ON (engine OFF). Read the current data for engine in the Subaru Select Monitor to confirm the item for "Oil level switch". Refer to DISPLAY OF ENGINE FREEZE FRAME DATA . | Is the "Oil level switch" signal displayed in Subaru Select Monitor HIGH? | To turn off the low engine oil level warning light, install the spare fuse at the delivery (test) mode fuse in the main fuse box. Then turn the ignition switch to ON (engine off) again, to confirm the low engine oil level warning light turns off. Remove the spare fuse installed to finish. NOTE: The engine oil level switch is normal if the low engine oil level warning light turns off with the delivery (test) mode fuse inserted. | Go to step 4 . |
| 4 CHECK COMBINATION METER. Perform the self-diagnosis of combination meter to check if there are any faults in the combination meter. Refer to OPERATION . | Is combination meter OK? | Go to step 5 . | Replace the combination meter. Refer to REMOVAL . |
| 5 CHECK SECURE CONNECTION OF CONNECTOR BETWEEN ENGINE HARNESS AND OIL LEVEL SWITCH. | Is there any insecure connection? | Remedy the connection condition. Then, to turn off the low engine oil level warning light, install the spare fuse at the delivery (test) mode fuse in the main fuse box. Then turn the ignition switch to ON (engine off) again, to confirm the low engine oil level warning light turns off. Remove the spare fuse installed to finish. NOTE: The engine oil level switch is normal if the low engine oil level warning light turns off with the delivery (test) mode fuse inserted. | Go to step 6 . |
| 6 CHECK OIL LEVEL SWITCH. Deliberately short circuits by connecting the engine harness connector terminal and chassis ground. Turn the ignition switch to ON (engine OFF). Read the current data for engine in the Subaru Select Monitor to confirm the item for "Oil level switch". Refer to DISPLAY OF ENGINE FREEZE FRAME DATA . Connector & terminal (E130) No. 1 - Chassis ground | Is the "Oil level switch" signal displayed in Subaru Select Monitor HIGH? | Replace the oil level switch. Refer to REMOVAL . | Go to step 7 . |
| 7 CHECK SECURE CONNECTION OF CONNECTOR BETWEEN BULKHEAD HARNESS AND ENGINE HARNESS. | Is there any insecure connection? | Remedy the connection condition. Then, to turn off the low engine oil level warning light, install the spare fuse at the delivery (test) mode fuse in the main fuse box. Then turn the ignition switch to ON (engine off) again, to confirm the low engine oil level warning light turns off. Remove the spare fuse installed to finish. NOTE: The engine oil level switch is normal if the low engine oil level warning light turns off with the delivery (test) mode fuse inserted. | Go to step 8 . |
| 8 CHECK ENGINE HARNESS. Disconnect the connector on the oil level switch side for the engine harness. Disconnect the connector on the bulkhead harness side for the engine harness. Measure the resistance between connector terminals. Connector & terminal (E2) No. 1 - (E130) No. 1 | Is the resistance less than 1 ohms? | Go to step 9 . | Repair or replace the open circuit of engine harness. |
| 9 CHECK SECURE CONNECTION OF CONNECTOR BETWEEN ENGINE CONTROL MODULE (ECM) AND BULKHEAD HARNESS. Remove the glove box lid assembly. Refer to REMOVAL . | Is there any insecure connection? | Remedy the connection condition. Then, to turn off the low engine oil level warning light, install the spare fuse at the delivery (test) mode fuse in the main fuse box. Then turn the ignition switch to ON (engine off) again, to confirm the low engine oil level warning light turns off. Remove the spare fuse installed to finish. NOTE: The engine oil level switch is normal if the low engine oil level warning light turns off with the delivery (test) mode fuse inserted. | Go to step 10 . |
| 10 CHECK BULKHEAD HARNESS. Remove the glove box lid assembly. Refer to REMOVAL . Disconnect the engine control module (ECM) side connector for the bulkhead harness. Disconnect the engine harness connectors from the bulkhead harness. Measure the resistance between connector terminals. Connector & terminal (B136) No. 24 - (B21) No. 1 | Is the resistance less than 1 ohms? | Replace the engine control module (ECM). Refer to REMOVAL . | Repair or replace the open circuit of the bulkhead harness. |
| NOTE |
|---|
| The engine oil level switch is normal if the low engine oil level warning light turns off with the delivery (test) mode fuse inserted. |
| NOTE |
|---|
| The engine oil level switch is normal if the low engine oil level warning light turns off with the delivery (test) mode fuse inserted. |
| NOTE |
|---|
| The engine oil level switch is normal if the low engine oil level warning light turns off with the delivery (test) mode fuse inserted. |
| NOTE |
|---|
| The engine oil level switch is normal if the low engine oil level warning light turns off with the delivery (test) mode fuse inserted. |
| NOTE |
|---|
| The engine oil level switch is normal if the low engine oil level warning light turns off with the delivery (test) mode fuse inserted. |
OTHER INSPECTIONS
- Check that the oil level switch does not have deformation, cracks, or damage.
- Check the oil level switch installation part for oil leakage and oil seepage.
Before performing diagnostics, make sure that the engine oil level is correct and no oil leakage exists.
| Trouble | Possible cause | Corrective action |
|---|---|---|
| Warning light remains ON. | A. Oil pressure switch failure | |
| O Cracked diaphragm or oil leakage within switch | Replace. | |
| O Broken spring or seized contacts | Replace. | |
| B. Low oil pressure | ||
| O Clogging of oil filter | Replace. | |
| O Malfunction of oil by-pass valve in oil filter | Replace. | |
| O Clogged oil passage | Clean. | |
| O Excessive tip clearance and side clearance of oil pump rotor | Replace. | |
| O Clogged oil strainer or broken pipe | Clean or replace. | |
| C. No oil pressure | ||
| O Insufficient engine oil (degradation, etc.) | Replace. | |
| O Broken pipe of oil strainer | Replace. | |
| O Stuck oil pump rotor | Replace. | |
| Warning light does not illuminate. | A. Malfunction of combination meter | Replace. |
| B. Poor contact of switch contact points | Replace. | |
| C. Disconnection of wiring | Repair. | |
| Warning light flickers momentarily. | A. Defective terminal contact | Repair. |
| B. Defective wiring harness | Repair. | |
| C. Oil pressure switch failure | ||
| O Cracked diaphragm or oil leakage within switch | Replace. | |
| O Broken spring or seized contacts | Replace. | |
| D. Low oil pressure | ||
| O Clogging of oil filter | Replace. | |
| O Malfunction of oil by-pass valve in oil filter | Replace. | |
| O Clogged oil passage | Clean. | |
| O Excessive tip clearance and side clearance of oil pump rotor | Replace. | |
| O Clogged oil strainer or broken pipe | Clean or replace. | |
