Communication Devices 7 illustrations ~334 words

CAUTION

  1. Before disassembling or reassembling parts, always disconnect the battery ground cable from battery. When replacing the audio, control module and other parts provided with memory functions, record the memory contents before disconnecting the battery ground cable. Otherwise, the memory is cleared.
  2. Reassemble the parts in the reverse order of disassembly procedure unless otherwise indicated.
  3. Connect the connectors securely during reassembly.
  4. After reassembly, make sure that the functional parts operate normally.
  5. Yellow connectors and harnesses with yellow tapes around them are the connectors and harnesses for the airbag system. Using a tester above such circuits may cause malfunction of airbag system. Follow the cautions for the airbag system in this case. Refer to «CAUTION»(ref-565203-S06105343772013071000000) .
  6. Be careful not to damage the airbag system wiring harness when servicing electrical parts and switches.

GENERAL TOOL

TOOL NAMEREMARKS
Circuit testerUsed for measuring resistance and voltage.

Scheme 34

Scheme 34: LOCATION
Main fuse boxFuse 7.5A (Hi pitch (RH) side horn)(A)
Fuse 7.5A (Lo pitch (LH) side horn)(B)
Horn relay(C)

Note. For other related fuses, refer to appropriate SYSTEM WIRING DIAGRAM article.

CHECK FUSE

  1. Remove the fuse and check visually.
  2. If the fuse is blown out, replace the fuse.

Scheme 35

Scheme 35: CHECK RELAY
  1. Check the resistance between relay terminals. Terminal No. Inspection conditions Specification Circuit 1 - 2 Always 1 Mohms or more 1 - 2 Apply battery voltage between 4 - 3 terminals. Less than 1 ohms
  2. Replace the relay if the inspection result is not within the standard value.

NOTE

For operation procedures of each component of the horn system, refer to the respective article.

  1. Horn ASSY: Refer to «HORN»(ref-565216-S18796621052013071000000) .
  2. Horn switch: Refer to «HORN SWITCH»(ref-565216-S41487792772013071000000) .

Scheme 36

Scheme 36: REMOVAL

Scheme 37

Scheme 37

Scheme 38

Scheme 38

Scheme 39

Scheme 39

Scheme 40

Scheme 40
  1. Disconnect the ground cable from battery.
  2. Remove the Lo pitch side horn. Remove the clips and remove the air intake duct. Remove the clips and remove the grille bracket. Disconnect the connector. Remove the horn bracket mounting bolt, and remove the Lo pitch side horn.
  3. Remove the Hi pitch side horn. Remove the clips and turn over the front mud guard RH. Disconnect the connector. Remove the horn bracket mounting bolt, and remove the Hi pitch side horn.
