OPERATION OF SELECT LEVER
Make sure there is no noise, dragging or contact pattern in each select lever range.
| WARNING | Stop the engine while checking operation of the select lever. |
Scheme 115
OPERATION
Refer to "Subaru Select Monitor" for information on how to display a DTC. < Ref. to OPERATION , Subaru Select Monitor . >
For details concerning DTCs, refer to "List of Diagnostic Trouble Code (DTC)". < Ref. to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) . >
Refer to "Subaru Select Monitor" for information about how to clear a DTC.
< Ref. to CLEAR MEMORY MODE , OPERATION, Subaru Select Monitor . >
When any on-board diagnostics item is malfunctioning, the ATF temperature warning light blinks when a malfunction is detected after starting the engine until the ignition switch is turned OFF. The malfunctioning part or unit can be determined by a DTC during the on-board diagnostics operation. Problems which occurred previously can also be identified through the memory function. If the ATF temperature warning light does not show a problem (although a problem is occurring), the problem can be determined by checking the performance characteristics of each sensor using the Subaru Select Monitor. Warning light signal patterns are shown in the figure.
Scheme 116
Perform the inspection when the ATF temperature warning light does not operate correctly. < Ref. to INSPECTION , AT Oil Temp Warning Light Display . >
