SPECIFICATION
| Contents | Specification | |
|---|---|---|
| Fuel tank | Capacity | 64 l (16.9 US gal, 14.1 lmp gal) |
| Install locations | Under rear seat | |
| Fuel pump | Type | Impeller |
| Shutoff discharge pressure | 550 - 850 kPa (5.6 - 8.7 kg/cm 2 , 79.7 - 123.2 psi) | |
| Discharge rate | 125 l (33 US gal, 27.5 lmp gal)/h or more. [12 V at 300 kPa (3.06 kg/cm 2 , 43.5 psi)] | |
| Fuel filter | Intank type | |
GENERAL SPECIFICATION
Scheme 80
Scheme 81
Scheme 82
Scheme 83
Scheme 84
Throttle body is a non-disassembled part, so do not remove the throttle position sensor from throttle body.
Refer to 'Throttle Body" for removal and installation procedure. REMOVAL, Throttle Body .> INSTALLATION, Throttle Body .>
Scheme 85
- Disconnect the ground cable from the battery.
- Disconnect the connector from manifold absolute pressure sensor.
- Remove the manifold absolute pressure sensor from throttle body.
Fuel filter forms a single unit with fuel pump. Refer to "Fuel Pump" for removal and installation. REMOVAL, Fuel Pump .> INSTALLATION, Fuel Pump .>
