SPECIFICATION
| Fuel tank | Capacity | 64 l (16.9 US gal, 14.1 lmp gal) |
|---|---|---|
| Location | Under rear seat | |
| Fuel pump | Type | Impeller |
| Shutoff discharge pressure | 550 - 850 kPa (5.61 - 8.67 kg/cm 2 , 79.8 - 123.3 psi) | |
| Discharge rate | 155 l (41 US gal, 34.1 lmp gal)/h or more. [12 V at 300 kPa (3.06 kg/cm 2 , 43.5 psi)] | |
| Fuel filter | In-tank type | |
FUEL TANK CAPACITY SPECIFICATION
Scheme 334
Scheme 335
Scheme 336
Scheme 337
Scheme 338
Scheme 339
Throttle body is a non-disassembled part, so do not remove the throttle position sensor from throttle body. Refer to "Throttle Body" for removal and installation procedure. < Ref. to REMOVAL, Throttle Body. > < Ref. to INSTALLATION, Throttle Body. >
Scheme 340
- Remove the collector cover.
- Disconnect the ground cable from the battery.
- Disconnect the connector from the manifold absolute pressure sensor (A), and remove the filter assembly (B) from the intake manifold.
- Remove the manifold absolute pressure sensor from intake manifold.
Fuel filter forms a single unit with fuel pump. Refer to "Fuel Pump" for removal and installation. < Ref. to REMOVAL, Fuel Pump. > < Ref. to INSTALLATION, Fuel Pump. >
