SPECIAL TOOL
SPECIAL TOOL ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 498575400 OIL PRESSURE GAUGE ASSY Used for measuring oil pressure. 498897200 ADAPTER Used together with oil pump cover installed on when measuring line pressure. 498897700 OIL PRESSURE ADAPTER Used for measuring transfer clutch pressure. 498545400 OIL FILTER WRENCH Used for removing and installing the ATF filter. 498277200 STOPPER SET Used for removing and installing automatic transmission assembly to engine. Used for preventing the torque converter from falling. 41099AA010 ENGINE SUPPORT BRACKET Used for supporting engine. 41099AA020 ENGINE SUPPORT Used for supporting engine. 398527700 PULLER ASSY Used for removing the extension case roller bearing. Used for removing the extension oil seal. Used for removing the front differential side retainer bearing outer race. Used for removing the front differential side retainer oil seal. 498057300 INSTALLER Used for installing the extension oil seal. 498077000 REMOVER Used for removing the differential taper roller bearing. 18630AA010 WRENCH COMPL RETAINER Used for removing and installing the differential side retainer. 398487700 DRIFT Used for installing the front differential taper roller bearing. 498255400 PLATE Used for measuring the backlash of hypoid gear. 498247001 MAGNET BASE Used for measuring the gear backlash. Used together with the DIAL GAUGE (498247100). 498247100 DIAL GAUGE Used for measuring the gear backlash. Used together with the MAGNET BASE (498247001). 498517000 REPLACER Used for removing the front roller bearing. 499787700 WRENCH Used for removing and installing the drive pinion lock nut. 398643600 GAUGE Used for measuring the total end play, extension end play and drive pinion height. 378744300 PISTON GUIDE Used for measuring height from mating surface of the main case to pressure plate. 499737100 PULLER SET Used for removing the reduction driven gear assembly. 498077600 REMOVER Used for removing the ball bearing. 18667AA010 HOLDER Used for removing and installing the drive pinion lock nut. Used as a handle to rotate gear when checking tooth contact. 1B021XU0 SUBARU SELECT MONITOR III KIT Used for troubleshooting the electrical system. 18675AA000 DIFFERENTIAL SIDE OIL SEAL INSTALLER Used for installing the differential side retainer oil seal. 18654AA000 INSTALLER Used for removing and installing the ball bearing. 28399SA010 OIL SEAL PROTECTOR Used for protecting oil seal when installing front drive shaft. 18763AA000 COMPRESSOR SHAFT Used for disassembling multi-plate clutch for shift transmission. 18765AA000 COMPRESSOR SUPPORT Used for disassembling multi-plate clutch for shift transmission. 18676AA020 TORX® WRENCH Used for disassembling torque converter case. 18854AA000 ANGLE GAUGE Used for tightening parking support. 498077300 REMOVER Used for removing ball bearing of reduction driven gear. 499587100 OIL SEAL INSTALLER Used for installing the oil seal. 499787500 ADAPTER Used for removing and installing drive pinion lock nut. 499575400 GAUGE Used for measuring height of total end play. 18762AA000 COMPRESSOR SPECIAL TOOL Used for disassembling multi-plate clutch for shift transmission. 499755602 PRESS Used for installing the parking gear. 18680AA010 HOLDER GEAR Used for removing reduction driven gear assembly. (2-piece set) 18766AA000 SUPPORT PULLER Used for removing reduction driven gear assembly. 18767AA000 REMOVER Used to pull out the parking gear. Used to pull out the bearing from the VTD assembly
