PROCEDURE
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK PRE-INSPECTION. Ask the customer when and how the trouble occurred using the interview check list. < Ref. to CHECK LIST FOR INTERVIEW . > Before performing diagnosis, inspect the following items which may influence AT problems. General Inspection < Ref. to INSPECTION , General Description . > Disconnection of harness connector Visual check for harness damage Oil leakage Stall speed test < Ref. to STALL TEST . > Line pressure test < Ref. to LINE PRESSURE TEST . > Transfer clutch pressure test < Ref. to TRANSFER CLUTCH PRESSURE TEST . > Time lag test < Ref. to TIME LAG TEST . > Road test < Ref. to ROAD TEST . > Inhibitor switch < Ref. to INHIBITOR SWITCH . > | Is the unit that is thought to influence the AT problem working properly? | Go to step 2. | Repair or replace each item. |
| 2 ATF TEMPERATURE WARNING LIGHT INSPECTION. Start the engine and wait for 2 seconds or more. | Is the ATF temperature warning light blinking? | Go to step 4. | Go to step 3. |
| 3 ATF TEMPERATURE WARNING LIGHT INSPECTION. Turn the ignition switch to OFF Check the ATF temperature warning light. < Ref. to INSPECTION , AT Oil Temp Warning Light Display . > Turn the ignition switch to ON and wait for at least 2 seconds. Start the engine. | Is the ATF temperature warning light blinking? | Go to step 4. | Go to step 5. |
| 4 CHECK DTC. Display DTC. NOTE: If the communication function of Subaru Select Monitor cannot be executed normally, check communication circuit. < Ref. to COMMUNICATION FOR INITIALIZING IMPOSSIBLE , Diagnostic Procedure for Subaru Select Monitor Communication . > | Is DTC displayed? | Go to step 6. NOTE: Record all DTC. | Go to step 5. |
| 5 PERFORM GENERAL DIAGNOSTICS. Inspect using "Diagnostic Procedure without Diagnostic Trouble Code (DTC)". < Ref. to DIAGNOSTIC PROCEDURE WITHOUT DIAGNOSTIC TROUBLE CODE (DTC) . > Inspect using "General Diagnostic Table". < Ref. to GENERAL DIAGNOSTIC TABLE . > Perform the Inspection Mode. < Ref. to INSPECTION MODE . > Display DTC. | Is DTC displayed? | Go to step 6. | Finish the diagnosis. |
| 6 PERFORM DIAGNOSIS. Inspect using the "Diagnostic Procedure with Diagnostic Trouble Code (DTC)". < Ref. to DIAGNOSTIC PROCEDURE WITH DIAGNOSTIC TROUBLE CODE (DTC) . > NOTE: For DTC table, refer to "List of Diagnostic Trouble Code (DTC)". < Ref. to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) . > Repair the trouble cause. Perform the Clear Memory Mode. Perform the Inspection Mode. < Ref. to INSPECTION MODE . > Display DTC. | Is DTC displayed? | Inspect using the "Diagnostic Procedure with Diagnostic Trouble Code (DTC)". < Ref. to DIAGNOSTIC PROCEDURE WITH DIAGNOSTIC TROUBLE CODE (DTC) . > | Finish the diagnosis. |
| NOTE |
|---|
| If the communication function of Subaru Select Monitor cannot be executed normally, check communication circuit. < Ref. to COMMUNICATION FOR INITIALIZING IMPOSSIBLE , Diagnostic Procedure for Subaru Select Monitor Communication . > |
| NOTE |
|---|
| Record all DTC. |
| NOTE |
|---|
| For DTC table, refer to "List of Diagnostic Trouble Code (DTC)". < Ref. to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) . > |
DIAGNOSIS PROCEDURE
CHECK
Check the following item when problem has occurred.
Note. Use copies of this information for interviewing customers.
Scheme 137
CAUTION
- Supplemental Restraint System "Airbag"
The airbag system wiring harness is routed near the TCM.
| CAUTION | All the airbag system wiring harnesses and connectors are colored yellow. Do not use an electric test equipment to check these circuits. Be careful not to damage the airbag system wiring harness when performing TCM diagnostics or servicing. MEASUREMENT |
When measuring the voltage and resistance of the ECM, TCM or each sensor, use a tapered pin with a diameter of less than 0.64 mm (0.025 in) in order to avoid poor contact. Do not insert a pin of more than 0.65 mm (0.026 in) diameter.
BATTERY
Measure the battery voltage and specific gravity of the electrolyte.
Standard voltage: 12 V or more
Specific gravity: 1.260 or more
TRANSMISSION GROUND
Make sure that the ground terminal bolt is tightened securely.
Chassis side
Tightening torque
13 N.m (1.3 kgf-m, 9.4 ft-lb)
Scheme 138
ATF LEVEL
Make sure that ATF level is the specified amount. < Ref. to INSPECTION , Automatic Transmission Fluid . >
Scheme 139
FRONT DIFFERENTIAL OIL LEVEL
Make sure the front differential oil level is the specified amount. < Ref. to INSPECTION , Differential Gear Oil . >
Scheme 140
GENERAL TOOL
| TOOL NAME | REMARKS |
|---|---|
| Circuit tester | Used for measuring resistance, voltage and current. |
| Oscilloscope | Used for measuring the sensor. |
GENERAL TOOL CHART
Scheme 141
Scheme 142
Scheme 143
Scheme 144
Scheme 145
Scheme 146
Scheme 147
| Check with ignition switch ON. | ||||||
|---|---|---|---|---|---|---|
| Contents | Measured terminal (Connector & Terminal No.) | Measuring condition | Voltage (V) | Resistance (ohms) | ||
| Positive terminal | Ground terminal | |||||
| Backup power supply | (B55) No. 27 | Chassis ground | 10 - 13 | |||
| (B55) No. 26 | Chassis ground | |||||
| (B55) No. 25 | Chassis ground | |||||
| ACC power supply | (B55) No. 12 | Chassis ground | Ignition Switch ACC | 10 - 13 | ||
| Ignition power supply | (B55) No. 1 | Chassis ground | Ignition Switch ON | 10 - 13 | ||
| (B55) No. 2 | Chassis ground | |||||
| Inhibitor switch | "P" range switch | (B55) No. 14 | Chassis ground | Select lever "P" range | Less than 1 | |
| Select lever Except "P" range | 8 or more | |||||
| "N" range switch | (B55) No. 11 | Chassis ground | Select lever "N" range | Less than 1 | ||
| Select lever Except "N" range | 8 or more | |||||
| "R" range switch | (B55) No. 13 | Chassis ground | Select lever "R" range | Less than 1 | ||
| Select lever Except "R" range | 8 or more | |||||
| "D" range switch | (B55) No. 10 | Chassis ground | Select lever "D" range | Less than 1 | ||
| Select lever Except "D" range | 8 or more | |||||
| ATF temperature sensor | (B54) No. 23 | (B54) No. 12 | ATF temperature 20°C (68°F) | 3.5 - 4.3 | 2.5 k - 7.0 k | |
| ATF temperature 80°C (176°F) | 1.0 - 2.2 | 300 - 800 | ||||
| ATF temperature sensor ground | (B54) No. 12 | Chassis ground | 0 | Less than 1 (When inserting connector) infinity (When disconnecting connector) | ||
| Rear vehicle speed sensor | (B54) No. 26 | (B54) No. 15 | 20 km/h (12 MPH) Vehicle speed at least | 2 or more (AC range) | ||
| Rear vehicle speed sensor ground | (B54) No. 15 | Chassis ground | 0 | Less than 1 (When inserting connector) infinity (When disconnecting connector) | ||
| Front vehicle speed sensor | (B54) No. 27 | (B54) No. 16 | 450 - 650 | |||
| Front vehicle speed sensor ground | (B54) No. 16 | Chassis ground | ||||
| Torque converter turbine speed sensor | (B54) No. 1 | (B54) No. 2 | Engine idling after warm-up ("D" range) | 0 | 450 - 650 | |
| Engine idling after warm-up ("N" range) | 1 or more (AC range) | |||||
| Torque converter turbine speed sensor ground | (B54) No. 2 | Chassis ground | ||||
| Engine speed signal | (B55) No. 11 | Chassis ground | Ignition switch ON (engine OFF) | Less than 1 | ||
| Ignition switch ON (with engine ON) | 5 or more (AC range) | |||||
| Line pressure linear solenoid | (B54) No. 4 | (B54) No. 3 | Ignition switch ON (with engine OFF) Throttle fully closed in "R" range after warm-up. | 3.7 - 7.7 | 4.0 - 6.0 | |
| Ignition switch ON (with engine OFF) Throttle fully opened in "R" range after warm-up. | 1.1 - 5.1 | |||||
| Line pressure linear solenoid ground | (B54) No. 3 | Chassis ground | Less than 1 | Less than 1 | ||
| Lock-up duty solenoid | (B54) No. 6 | Chassis ground | When lock up occurs. | 10.5 or more | 2.0 - 4.5 | |
| When lock up is released. | Less than 1 | |||||
| Transfer duty solenoid | (B54) No. 5 | Chassis ground | With fuse installed to FWD switch | Less than 1 | 2.0 - 4.5 | |
| With fuse removed from FWD switch (1st gear) | 2.0 - 3.0 | |||||
| 2-4 brake duty solenoid | (B55) No. 4 | Chassis ground | "P" or "N" range | 5.0 or more | 2.0 - 4.5 | |
| 2nd or 4th gear | Less than 1 | |||||
| High clutch duty solenoid | (B55) No. 6 | Chassis ground | 3rd or 4th gear | Less than 1 | 2.0 - 4.5 | |
| "P" or "N" range | 5.0 or more | |||||
| Low clutch duty solenoid | (B55) No. 7 | Chassis ground | 1st or 2nd gear | Less than 1 | 2.0 - 4.5 | |
| "P" or "N" range | 5.0 or more | |||||
| Low & reverse duty solenoid | (B55) No. 5 | Chassis ground | Except "1" range | 5.0 or more | 2.0 - 4.5 | |
| Driving at 1st gear on manual mode (15 km/h (9.3 MPH) or more) | 2.5 - 5.0 | |||||
| Data link signal (Subaru Select Monitor) | (B55) No. 8 | Chassis ground | ||||
| CAN communication signal (+) | (B54) No. 18 | Chassis ground | Ignition switch ON | Pulse signal | ||
| CAN communication signal (-) | (B54) No. 17 | Chassis ground | Ignition switch ON | Pulse signal | ||
| FWD switch | (B55) No. 10 | Chassis ground | Fuse removed | 10.5 or more | ||
| Fuse installed | 1 or less | |||||
| System ground circuit | (B55) No. 20 | Chassis ground | 0 | Less than 1 | ||
| (B55) No. 21 | Chassis ground | 0 | Less than 1 | |||
| (B55) No. 22 | Chassis ground | 0 | Less than 1 | |||
| (B55) No. 23 | Chassis ground | 0 | Less than 1 | |||
ELECTRICAL SPECIFICATION
Scheme 148
- Prepare the Subaru Select Monitor kit. < Ref. to «PREPARATION TOOL»(ref-306922-S00127790762008122600000) , General Description . >
- Prepare PC with Subaru Select Monitor installed.
- Connect the SDI (Subaru Diagnostic Interface) to the PC USB port (exclusively for Subaru Selector Monitor) using a USB cable. NOTE: Port exclusively for Subaru Select Monitor refers to the USB port used when installing Subaru Select Monitor.
- Connect the diagnosis cable to the SDI.
- Connect the SDI to data link connector located in the lower portion of the instrument panel (on the driver's side). CAUTION: Do not connect scan tools other than the Subaru Select Monitor.
- Start the PC.
- Turn the ignition switch to ON (engine OFF) and run the "PC application help for Subaru Select Monitor".
- On the «Main Menu», select {Each System Check}.
- On the «System Selection Menu», select {Transmission}.
- After transmission type information pops up, select [OK].
- On the «Transmission Diagnosis», select {DTC Display}.
- On the «DTC Display», select {Temporary Diagnostic Code(s)} or {Memorized Diagnostic Code(s)}. NOTE: For details concerning the operation procedure, refer to the "help on PC application for Subaru Select Monitor". For details concerning DTC, refer to "List of Diagnostic Trouble Code (DTC)". < Ref. to «LIST OF DIAGNOSTIC TROUBLE CODE (DTC)»(ref-306922-S10090399402008122600000) . >
READ CURRENT DATA
- On the «Main Menu», select {Each System Check}.
- On the «System Selection Menu», select {Transmission}.
- After transmission type information pops up, select [OK].
- On the «Transmission Diagnosis», select {Current Data Display & Save}.
- On the «Current Data Display & Save», select {Normal sampling}.
- Using the scroll key, scroll the display screen up or down until the desired data is shown.
A list of the support data is shown in the following table.
| Contents | Display | Unit of measure |
|---|---|---|
| Battery voltage | Battery Voltage | V |
| Rear vehicle speed sensor signal | Rear Wheel Speed | Km/h or MPH |
| Front vehicle speed sensor signal | Front Wheel Speed | Km/h or MPH |
| Engine speed signal | Engine Speed | Rpm |
| Automatic transmission fluid temperature signal | ATF Temp. | °C or °F |
| Accelerator pedal position sensor | Throttle voltage | V |
| Gear position | Gear Position | |
| Line pressure control duty ratio | Line Pressure Duty Ratio | % |
| Lock up clutch control duty ratio | Lock up Duty Ratio | % |
| Transfer clutch control duty ratio | Transfer Duty Ratio | % |
| Accelerator pedal position sensor power supply | Throttle Voltage | V |
| Torque converter turbine speed signal | Turbine Revolution Speed | Rpm |
| 2 - 4 brake timing pressure control duty ratio | Brake Clutch Duty Ratio | % |
| Low clutch duty ratio | L/C Duty | % |
| High clutch duty ratio | H/C Duty | % |
| Low & reverse brake duty ratio | L&R/B Duty | % |
| Accelerator position | Acceleration Opening Angle | % |
| FWD switch signal | FWD SW | ON or OFF |
| Stop light switch signal | Stop light SW | ON or OFF |
| Anti lock brake system signal | ABS signal | ON or OFF |
| Parking range signal | P Range Signal | ON or OFF |
| Neutral range signal | N Range Signal | ON or OFF |
| Reverse range signal | R Range Signal | ON or OFF |
| Drive range signal | D Range Signal | ON or OFF |
| AT diagnosis light output signal | Diagnosis Light | ON or OFF |
| Cruise control signal | Cruise Control Signal | ON or OFF |
| ATF temperature light | ATF temperature light | ON or OFF |
| Up shift signal | Up SW | ON or OFF |
| Down shift signal | Down SW | ON or OFF |
| Sport mode signal | Tiptronic Mode Switch | ON or OFF |
SUPPORT DATA
Note. For details concerning the operation procedure, refer to the "help on PC application for Subaru Select Monitor".
CLEAR MEMORY MODE
- Check that the select lever is in "P" range.
- On the «Main Menu», select {Each System Check}.
- On the «System Selection Menu», select {Transmission}.
- After transmission type information pops up, select [OK].
- On the «Transmission Diagnosis», select {Clear Memory}.
- When the "Done. Turn ignition switch to OFF" pops up, select [OK].
- Turn Subaru Select Monitor and ignition switch to OFF. To turn the ignition switch to ON again, wait for 10 seconds or more. NOTE: If {Clear Memory 2} is selected and performed, DTC and learned control memory are cleared. If {Clear Memory 2} is performed, perform learning control promotion. < Ref. to «FACILITATION OF LEARNING CONTROL»(ref-306922-S36203919282008122600000) , OPERATION, Subaru Select Monitor . > For details concerning the operation procedure, refer to the "help on PC application for Subaru Select Monitor".
FACILITATION OF LEARNING CONTROL
Note. When the following services have been performed or when the shifting shock is felt during the total check with vehicle driving, perform the transmission learning control with the following procedures. Replacement of TCM Replacement or disassembly of transmission assembly Replacement of control valve body When {Clear Memory 2} is executed
| CAUTION | Warm-up the engine until the ATF temperature displayed on Subaru Select Monitor reaches 60 - 90°C (140 - 194°F) before performing learning control promotion. < Ref. to READ CURRENT DATA , OPERATION, Subaru Select Monitor . > |
- Shift the select lever to "P" range, and apply the parking brake.
- Lift up the vehicle. CAUTION: When performing learning control promotion, be sure to keep the lower edge of the tires 30 cm or more above the ground as vehicle vibrates during the work.
- Connect the Subaru Select Monitor to the data link connector.
- Turn the ignition switch to ON (engine OFF).
- Perform {Clear Memory 2} using Subaru Select Monitor. < Ref. to «CLEAR MEMORY MODE»(ref-306922-S39627182112008122600000) , OPERATION, Subaru Select Monitor . >
- Using the Subaru Select Monitor, check that there is no DTC displayed. < Ref. to «READ DIAGNOSTIC TROUBLE CODE (DTC)»(ref-306922-S03725314592008122600000) , OPERATION, Subaru Select Monitor . >
- Select {Normal sampling} on the «Current Data Display & Save» of Subaru Select Monitor, and confirm that ATF temperature reaches 60 - 90°C (140 - 194°F).
- Set the select lever to "R" range.
- Turn all switches including headlight, air conditioner, seat heater, rear defogger and etc. OFF.
- Turn the ECO mode switch to ON.
- Turn the ignition switch to OFF. (ACC is also OFF)
- When "Communication error occurred." is displayed on Subaru Select Monitor, select [OK], and when "Save the data before communication error occurred?" appears, select [NO] to return to the «System Selection Menu».
- Depress the brake pedal fully until the learning control promotion is completed.
- Turn the ignition switch to ON (engine OFF).
- On the «Current Data Display & Save» of Subaru Select Monitor, select {Normal sampling}.
- Shift the select lever to the "P" range, and wait for 3 seconds or more.
- Shift the select lever to the "R" range, and wait for 3 seconds or more.
- Shift the select lever to the "N" range, and wait for 3 seconds or more.
- Shift the select lever to the "D" range, and wait for 3 seconds or more.
- Shift the select lever to the "N" range, and wait for 3 seconds or more.
- Slowly depress the accelerator pedal to full open.
- Slowly release the accelerator pedal to full close.
- Start the engine, and idle it.
- Set the select lever to the "D" range. (When the SPORT indicator light in the combination meter blinks at 2 Hz, learning control promotion starts. When the SPORT indicator light blinking at 2 Hz goes OFF, learning control promotion is completed.) NOTE: When the SPORT indicator light does not blink or blinking changes from 2 Hz to 4 Hz, turn the ignition switch to OFF and repeat the procedure from step 4 ).
- Set the select lever to "N" range, and turn the ignition switch to OFF.
- Move the select lever to "P" range.
| WARNING | Observe the traffic law when driving on public roads. |
- Shift the select lever to "D" range, and then drive the vehicle at 60 km/h (37 MPH) for at least 10 seconds.
- Drive the vehicle with manual mode.
LIST
| DTC | Contents | Diagnosis content | Reference |
|---|---|---|---|
| P0705 | Transmission Range Sensor Circuit (PRNDL Input) | Inhibitor switch malfunction short circuit | < Ref. to DTC P0705 TRANSMISSION RANGE SENSOR CIRCUIT (PRNDL INPUT) , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . > |
| P0712 | Transmission Fluid Temperature Sensor Circuit Low Input | ATF temperature sensor is faulty or input signal circuit is open. | < Ref. to DTC P0712 TRANSMISSION FLUID TEMPERATURE SENSOR CIRCUIT LOW INPUT , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . > |
| P0713 | Transmission Fluid Temperature Sensor Circuit High Input | ATF temperature sensor is faulty or input signal circuit is shorted. | < Ref. to DTC P0713 TRANSMISSION FLUID TEMPERATURE SENSOR CIRCUIT HIGH INPUT , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . > |
| P0715 | Input/Turbine Speed Sensor Circuit | Torque converter turbine speed sensor malfunction, open or shorted input signal circuit | < Ref. to DTC P0715 INPUT/TURBINE SPEED SENSOR CIRCUIT , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . > |
| P0719 | Torque Converter / Brake Switch "B" Circuit Low | Brake switch malfunction, open input signal circuit | < Ref. to DTC P0719 BRAKE SWITCH CIRCUIT LOW , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . > |
| P0720 | Output Speed Sensor Circuit | Front vehicle speed sensor malfunction, open or shorted input signal circuit | < Ref. to DTC P0720 OUTPUT SPEED SENSOR CIRCUIT , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . > |
| P0724 | Torque Converter / Brake Switch "B" Circuit High | Brake switch malfunction, shorted input signal circuit | < Ref. to DTC P0724 BRAKE SWITCH CIRCUIT HIGH , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . > |
| P0725 | Engine Speed Input Circuit | Open or shorted engine speed output signal circuit | < Ref. to DTC P0725 ENGINE SPEED INPUT CIRCUIT , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . > |
| P0731 | Gear 1 Incorrect Ratio | Vehicle sensor, torque converter turbine speed sensor or control valve malfunction | < Ref. to DTC P0731 GEAR 1 INCORRECT RATIO , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . > |
| P0732 | Gear 2 Incorrect Ratio | Vehicle sensor, torque converter turbine speed sensor or control valve malfunction | < Ref. to DTC P0732 GEAR 2 INCORRECT RATIO , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . > |
| P0733 | Gear 3 Incorrect Ratio | Vehicle sensor, torque converter turbine speed sensor or control valve malfunction | < Ref. to DTC P0733 GEAR 3 INCORRECT RATIO , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . > |
| P0734 | Gear 4 Incorrect Ratio | Vehicle sensor, torque converter turbine speed sensor or control valve malfunction | < Ref. to DTC P0734 GEAR 4 INCORRECT RATIO , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . > |
| P0736 | Reverse Incorrect Ratio | Vehicle sensor, torque converter turbine speed sensor or control valve malfunction | < Ref. to DTC P0736 REVERSE INCORRECT RATIO , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . > |
| P0741 | Torque Converter Clutch Circuit Performance or Stuck Off | Lock-up clutch is faulty or valve is stuck. | < Ref. to DTC P0741 TORQUE CONVERTER CLUTCH CIRCUIT PERFORMANCE OR STUCK OFF , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . > |
| P0743 | Torque Converter Clutch Circuit Electrical | Lock-up solenoid is faulty or output signal circuit is open or shorted. | < Ref. to DTC P0743 TORQUE CONVERTER CLUTCH CIRCUIT ELECTRICAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . > |
| P0748 | Pressure Control Solenoid "A" Electrical | Line pressure linear solenoid is faulty or output signal circuit is open or shorted. | < Ref. to DTC P0748 PRESSURE CONTROL SOLENOID "A" ELECTRICAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . > |
| P0753 | Shift Solenoid "A" Electrical | Low clutch duty solenoid is faulty or output signal circuit is open or shorted. | < Ref. to DTC P0753 SHIFT SOLENOID "A" ELECTRICAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . > |
| P0758 | Shift Solenoid "B" Electrical | 2-4 brake duty solenoid is faulty or output signal circuit is open or shorted. | < Ref. to DTC P0758 SHIFT SOLENOID "B" ELECTRICAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . > |
| P0763 | Shift Solenoid "C" Electrical | High clutch duty solenoid is faulty or output signal circuit is open or shorted. | < Ref. to DTC P0763 SHIFT SOLENOID "C" ELECTRICAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . > |
| P0768 | Shift Solenoid "D" Electrical | Low & reverse clutch duty solenoid is faulty or output signal circuit is open or shorted. | < Ref. to DTC P0768 SHIFT SOLENOID "D" ELECTRICAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . > |
| P0801 | Reverse Inhibit Control Circuit | Shift lock solenoid is faulty or output signal circuit is open or shorted. | < Ref. to DTC P0801 REVERSE INHIBIT CONTROL CIRCUIT , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . > |
| P1706 | AT Vehicle Speed Sensor Circuit Malfunction (Rear Wheel) | Rear vehicle speed sensor is faulty or input signal circuit is open or shorted. | < Ref. to DTC P1706 AT VEHICLE SPEED SENSOR CIRCUIT MALFUNCTION (REAR WHEEL) , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . > |
| P1707 | AT AWD Solenoid Valve Circuit Malfunction | Transfer duty solenoid is faulty or output signal circuit is open or shorted. | < Ref. to DTC P1707 AT AWD SOLENOID VALVE CIRCUIT MALFUNCTION , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . > |
| P1718 | CAN Communication Circuit | CAN communication circuit is open or shorted. | < Ref. to DTC P1718 CAN COMMUNICATION CIRCUIT , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . > |
| P1817 | SPORT Mode Switch Circuit | Sport shift switch is faulty or input signal circuit is open or shorted. | < Ref. to DTC P1817 SPORT MODE SWITCH CIRCUIT , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . > |
LIST OF DIAGNOSTIC TROUBLE CODE
