INSTALLATION
- Clean all parts before installation.
- Install in the reverse order of removal.
- After completing installation, shift the select lever to the manual mode.
- Operate the paddle shift assembly and confirm that "2" illuminates on the combination meter.
Scheme 770
| Step | Check | Yes | No |
|---|---|---|---|
| 1 SHIFT-UP SWITCH CONTINUITY CHECK. Operate the + side of paddle shift assembly and hold it. Measure the resistance between the terminals of the paddle shift assembly connector. Terminals No. 1 - No. 2 | Is the resistance less than 10 ohms? | Go to step 2. | Replace the paddle shift assembly. |
| 2 SHIFT-DOWN SWITCH CONTINUITY CHECK. Operate the - side of paddle shift assembly and hold it. Measure the resistance between the terminals of the paddle shift assembly connector. Terminals No. 3 - No. 2 | Is the resistance less than 10 ohms? | Go to step 3. | Replace the paddle shift assembly. |
| 3 CHECK SHIFT SWITCH INSULATION. Do not operate the paddle shift assembly. Measure the resistance between the terminals of the paddle shift assembly connector. Terminals No.2 - No.1: No. 2 - No. 3 | Is the resistance 1 ohms? | Paddle shift assembly is normal. | Replace the paddle shift assembly. |
PADDLE SHIFT ASSEMBLY OPERATION CHART
Scheme 771
Scheme 772
Scheme 773
- Remove the console box. < Ref. to «REMOVAL»(ref-306930-S31661521552008122600000) , Console Box . >
- Disconnect the connector.
- Remove the indicator bulb.
- Remove the grip.
- Remove the indicator cover.
- Disconnect the connector from the guide plate upper.
- Shift the select lever to the "N" range, and then remove the detent spring.
- Remove the switch assembly and shift lock solenoid assembly.
- Remove the bolt to remove the guide plate upper (A) from the plate lower (B).
- Raise the claw of the connector.
- Disconnect the terminal of the "P" range switch from connector, using a flat-tip screwdriver with a thin tip.
Install in the reverse order of removal.
Note. Refer to "COMPONENT" for each tightening torque. < Ref. to AT SELECT LEVER , COMPONENT, General Description . > Connect the "P" range switch terminal to connector.
