OPERATION OF SHIFT SELECT LEVER
Make sure there is no noise, dragging or contact pattern in each select lever range.
| WARNING | Stop the engine while checking operation of the select lever. |
Scheme 699
OPERATION
Refer to "Subaru Select Monitor" for information about how to obtain and understand DTC. < Ref. to OPERATION , Subaru Select Monitor. >
Use "Subaru Select Monitor" to clear DTC. < Ref. to CLEAR MEMORY MODE , OPERATION, Subaru Select Monitor. >
Note. DTC cannot be cleared without using Subaru Select Monitor.
GENERAL DESCRIPTION
When the following services have been performed, be sure to perform the transmission learning control. Perform the learning control in order of simple learning --> driving learning.
- Replacement of TCM
- Replacement or disassembly of transmission assembly
- Replacement of control valve body
- When {Clear Memory 2} is executed
When any on-board diagnostics item is malfunctioning, the AT OIL TEMP light blinks from the time the malfunction is detected after starting the engine until the ignition switch is turned OFF. The malfunctioning part or unit can be determined by a DTC during the on-board diagnostics operation. Problems which occurred previously can also be identified through the memory function. If the AT OIL TEMP light does not show a problem (although a problem is occurring), the problem can be determined by checking the performance characteristics of each sensor using Subaru Select Monitor. Indicator light signal patterns are as shown in the figure.
When the AT OIL TEMP light does not operate normally but no DTC is stored, perform the AT OIL TEMP light inspection. < Ref. to INSPECTION , AT Oil Temp Warning Light Display. >
