SUPPLEMENTAL RESTRAINT SYSTEM "AIRBAG"

Airbag system wiring harness is routed near the transmission control module (TCM).

MEASUREMENT

When measuring voltage and resistance of the ECM, TCM or each sensor, use a tapered pin with a diameter of less than 0.64 mm (0.025 in) in order to avoid poor contact. Do not insert the pin more than 5 mm (0.20 in).

ATF LEVEL

Make sure that ATF level is in the specification.

Checking ATF Fluid Level. Scheme 634

FRONT DIFFERENTIAL OIL LEVEL

Make sure that front differential oil level is in the specification.

Checking Front Differential Oil Level. Scheme 635

ABNORMAL DISPLAY ON AT OIL TEMP INDICATOR

When any on-board diagnostics item is malfunctioning, the display on the AT OIL TEMP indicator light blinks from the time the malfunction is detected after starting the engine until the ignition switch is turned OFF. The malfunctioning part or unit can be determined by a trouble code during on-board diagnostics operation. Problems which occurred previously can also be identified through the memory function. If the AT OIL TEMP indicator does not show a problem (although a problem is occurring), the problem can be determined by checking the performance characteristics of each sensor using the select monitor. Indicator signal is as shown in the figure.

Abnormal Display On AT Oil Temperature Indicator (Indicator Light Blinks). Scheme 636

CLEAR MEMORY

Current trouble codes shown on the display are cleared by turning the ignition switch OFF after conducting on-board diagnostics operation. Previous trouble codes, however, cannot be cleared since they are stored in the TCM memory which is operating on the back-up power supply. These trouble codes can be cleared by removing the specified fuse (located under the light or left lower position of the instrument panel).

CLEAR MEMORY

Removal of No. 4 fuse (for at least one minute) .

1. The No. 4 fuse is located in the line to the memory back-up power supply of the TCM. Removal of this fuse clears the previous trouble codes stored in the TCM memory.
2. Be sure to remove the No. 4 fuse for at least the specified length of time. Otherwise, trouble codes may not be cleared.

DTC INDEX

CHECK VEHICLE SPEED SENSOR 1

1. 9C1: CHECK VEHICLE SPEED SENSOR 1. Lift-up or raise the vehicle and support with safety stand. CAUTION: On AWD models, raise all wheels off ground. Read data of vehicle speed #1 using Subaru Select Monitor. Compare speedometer with Subaru Select Monitor indications. Vehicle speed is indicated in "MPH" or "km/h". NOTE: The speed difference between front and rear wheels may light the ABS warning light, but this indicates no malfunction. When AT control diagnosis is finished, perform the ABS memory clearance procedure of on-board diagnostics system. See «CLEARING MEMORY-ABS»(ref-175571-S20362536332005042200000) . CHECK: Does the speedometer indication increase as the Subaru Select Monitor data increases? YES: Go to step vehicle speed sensor 2, see «CHECK VEHICLE SPEED SENSOR 2»(ref-175204-S36482038712005041800000) . NO: Check vehicle speed sensor 1 circuit, see «DTC 93: VEHICLE SPEED SENSOR 1 (REAR)»(ref-175204-S13837326062005041800000) .

CHECK VEHICLE SPEED SENSOR 2

1. 9D1: CHECK VEHICLE SPEED SENSOR 2. Compare speedometer with Subaru Select Monitor indications. Vehicle speed is indicated in "MPH" or "km/h". NOTE: The speed difference between front and rear wheels may light the ABS warning light, but this indicates no malfunction. When AT control diagnosis is finished, perform the ABS memory clearance procedure of on-board diagnostics system. See «CLEARING MEMORY-ABS»(ref-175571-S20362536332005042200000) . CHECK: Does the speedometer indication increase as the Subaru Select Monitor data increases? YES: Go to step engine speed signal, see «CHECK ENGINE SPEED SIGNAL»(ref-175204-S12942017422005041800000) . NO: Check vehicle speed sensor 2 circuit, see «DTC 33: VEHICLE SPEED SENSOR 2 (FRONT)»(ref-175204-S24480792392005041800000) .

CHECK ENGINE SPEED SIGNAL

1. 9E1: CHECK ENGINE SPEED SIGNAL. Turn A/C switch to OFF (with A/C models). Warm-up the engine until engine coolant temperature is above 80°C (176°F). NOTE: If ambient temperature is below 0°C (32°F), drive the vehicle until the ATF reaches its operating temperature. Read data of engine speed using Subaru Select Monitor. Engine speed is indicated in "RPM". NOTE: The speed difference between front and rear wheels may light the ABS warning light, but this indicates no malfunction. When AT control diagnosis is finished, perform the ABS memory clearance procedure of on-board diagnostics system. See «CLEARING MEMORY-ABS»(ref-175571-S20362536332005042200000) . CHECK: Does the tachometer revolution indication increase as the Subaru Select Monitor revolution data increases? YES: Go to step ATF temperature sensor. See «CHECK ATF TEMPERATURE SENSOR»(ref-175204-S08273439632005041800000) . NO: Check engine speed signal circuit, see «DTC 11: ENGINE SPEED SIGNAL»(ref-175204-S06726801442005041800000) .

CHECK ATF TEMPERATURE SENSOR

1. 9F1: CHECK AT OIL TEMP WARNING LIGHT. CHECK: Does the AT OIL TEMP warning light remain on 2 seconds after the engine has been started? YES: Go to step 9F2. NO: Check ATF temperature sensor and combination meter circuit.
2. 9F2: CHECK ATF TEMPERATURE SENSOR. Read data of ATF temperature using Subaru Select Monitor. ATF temperature is indicated in "°F" or "°C". Warm-up the transmission until ATF temperature is above 80°C (176°F). NOTE: If ambient temperature is below 0°C (32°F), drive the vehicle until the ATF reaches its operating temperature. Turn ignition switch to ON (engine OFF). CHECK: Does the ATF temperature change from 176°F (80°C)? YES: Go to step throttle position sensor, see «CHECK THROTTLE POSITION SENSOR»(ref-175204-S22676780092005041800000) . NO: Check ATF temperature sensor circuit, see «DTC 27: ATF TEMPERATURE SENSOR»(ref-175204-S24951476072005041800000) .

CHECK THROTTLE POSITION SENSOR

1. 9G1: CHECK INPUT SIGNAL FOR TCM. Read data of throttle position sensor using Subaru Select Monitor. Throttle position sensor input signal is indicated. CHECK: Is voltage between 0.3 and 0.7 V when the accelerator pedal is completely released? YES: Go to step 9G2. NO: Check throttle position sensor circuit, see «DTC 31: THROTTLE POSITION SENSOR»(ref-175204-S15853891962005041800000) .
2. 9G2: CHECK INPUT SIGNAL FOR TCM. CHECK: Is voltage between 4.3 and 4.9 V when the accelerator pedal is completely depressed? YES: Go to step 9G3. NO: Check throttle position sensor circuit, see «DTC 31: THROTTLE POSITION SENSOR»(ref-175204-S15853891962005041800000) .
3. 9G3: CHECK INPUT SIGNAL FOR TCM. CHECK: Does voltage decrease smoothly when the accelerator pedal is fully depressed and then fully released? YES: Go to step gear position, «CHECK GEAR POSITION.»(ref-175204-S37359806162005041800000) NO: Check throttle position sensor circuit, see «DTC 31: THROTTLE POSITION SENSOR»(ref-175204-S15853891962005041800000) .

CHECK GEAR POSITION

9H1: CHECK GEAR POSITION.

1. Lift-up or raise the vehicle and support with safety stand. CAUTION: On AWD models, raise all wheels off ground.
2. Start the engine.
3. Move select lever to "D", and drive vehicle.
4. Read data of gear position using Subaru Select Monitor. Gear position is indicated.

Note. The speed difference between front and rear wheels may light the ABS warning light, but this indicates no malfunction. When AT control diagnosis is finished, perform the ABS memory clearance procedure of on-board diagnostics system. See CLEARING MEMORY-ABS .

CHECK: Does the transmission gear correspond to the gear which is shown on display?

1. YES: Go to step line pressure duty solenoid, see «CHECK LINE PRESSURE DUTY SOLENOID»(ref-175204-S31581778182005041800000) .
2. NO: Check shift solenoid 1 and shift solenoid 2 signal circuit, see «DTC 71: SHIFT SOLENOID 1»(ref-175204-S40170884592005041800000) and «DTC 72: SHIFT SOLENOID 2»(ref-175204-S39883890782005041800000) .

CHECK LINE PRESSURE DUTY SOLENOID

1. 9I1: CHECK OUTPUT SIGNAL EMITTED FROM TCM. Warm-up the transmission until ATF temperature is above 80°C (176°F). NOTE: If ambient temperature is below 0°C (32°F), drive the vehicle until the ATF reaches its operating temperature. Stop the engine and turn ignition switch to ON (engine OFF). Move select lever to "N". Read data of line pressure duty solenoid using Subaru Select Monitor. Line pressure duty solenoid is indicated in "%". CHECK: Does the Subaru Select Monitor indicate 100% when the accelerator pedal is completely released? YES: Go to step 9I2. NO: Go to step 9I4.
2. 9I2: CHECK OUTPUT SIGNAL EMITTED FROM TCM. CHECK: Does the Subaru Select Monitor indicate between 10 and 20% when the accelerator pedal is completely depressed? YES: Go to step 9I3. NO: Go to step 9I4.
3. 9I3: CHECK OUTPUT SIGNAL EMITTED FROM TCM. CHECK: Does the Subaru Select Monitor change smoothly when the accelerator pedal is fully depressed and then fully released? YES: Go to step lock-up duty solenoid, see «CHECK LOCK-UP DUTY SOLENOID»(ref-175204-S24706353662005041800000) NO: Go to step 9I4.
4. 9I4: CHECK THROTTLE POSITION SENSOR. NOTE: For the diagnostics procedure on throttle position sensor circuit, see «CHECK THROTTLE POSITION SENSOR»(ref-175204-S22676780092005041800000) . CHECK: Is there any trouble in throttle position sensor circuit? YES: Repair or replace throttle position sensor circuit, see «DTC 31: THROTTLE POSITION SENSOR»(ref-175204-S15853891962005041800000) . NO: Go to step 9I5.
5. 9I5: CHECK ENGINE SPEED SIGNAL. NOTE: For the diagnostic procedure on engine speed signal circuit, see «CHECK ENGINE SPEED SIGNAL»(ref-175204-S12942017422005041800000) . CHECK: Is there any trouble in engine speed signal circuit? YES: Repair or replace engine speed signal circuit, see «DTC 11: ENGINE SPEED SIGNAL»(ref-175204-S06726801442005041800000) . NO: Go to step 9I6.
6. 9I6: CHECK ATF TEMPERATURE SENSOR. NOTE: For the diagnostics procedure on ATF temperature sensor circuit, see «F: CHECK ATF TEMPERATURE SENSOR»(ref-175204-S08273439632005041800000) . CHECK: Is there any trouble in ATF temperature sensor circuit? YES: Repair or replace ATF temperature sensor circuit, see «DTC 27: ATF TEMPERATURE SENSOR»(ref-175204-S24951476072005041800000) . NO: Go to step 9I7.
7. 9I7: CHECK INHIBITOR SWITCH. Turn ignition switch and Subaru Select Monitor to ON. Read data of range switch using Subaru Select Monitor. Range switch is indicated in ON <=> OFF. CHECK: When each range is selected, does LED of the range switch on Subaru Select Monitor light up? YES: Go to step LOCK-UP DUTY SOLENOID. See «CHECK LOCK-UP DUTY SOLENOID»(ref-175204-S24706353662005041800000) . NO: Check inhibitor switch circuit, see «CHECK INHIBITOR SWITCH»(ref-175204-S27328873982005041800000) .

CHECK LOCK-UP DUTY SOLENOID

1. 9J1: CHECK OUTPUT SIGNAL EMITTED FROM TCM. Read data of lock-up duty solenoid using Subaru Select Monitor. Lock-up duty solenoid is indicated in "%". CHECK: Does the Subaru Select Monitor indicate 5%? YES: Go to step 9J2. NO: Go to step 9J3.
2. 9J2: CHECK OUTPUT SIGNAL EMITTED FROM TCM. Move select lever to "D" and slowly increase vehicle speed to 75 km/h (47 MPH). NOTE: The speed difference between front and rear wheels may light the ABS warning light, but this indicates no malfunction. When AT control diagnosis is finished, perform the ABS memory clearance procedure of on-board diagnostics system. See «CLEARING MEMORY-ABS»(ref-175571-S20362536332005042200000) . CHECK: Does the Subaru Select Monitor indicate 95%? YES: Go to step transfer duty solenoid. See «K: CHECK TRANSFER DUTY SOLENOID»(ref-175204-S41643968492005041800000) . NO: Go to step 9J3.
3. 9J3: CHECK THROTTLE POSITION SENSOR. NOTE: For the diagnostics procedure on throttle position sensor circuit, see «CHECK THROTTLE POSITION SENSOR»(ref-175204-S22676780092005041800000) . CHECK: Is there any trouble in throttle position sensor circuit? YES: Repair or replace throttle position sensor circuit, see «DTC 31: THROTTLE POSITION SENSOR»(ref-175204-S15853891962005041800000) . NO: Go to step 9J4.
4. 9J4: CHECK VEHICLE SPEED SENSOR 1. NOTE: For the diagnostics procedure on vehicle speed sensor 1 circuit, see «CHECK VEHICLE SPEED SENSOR 1»(ref-175204-S24776056542005041800000) . CHECK: Is there any trouble in vehicle speed sensor 1 circuit? YES: Repair or replace vehicle speed sensor 1 circuit, see «DTC 93: VEHICLE SPEED SENSOR 1 (REAR)»(ref-175204-S13837326062005041800000) . NO: Go to step 9J5.
5. 9J5: CHECK VEHICLE SPEED SENSOR 2. NOTE: For the diagnostics procedure on vehicle speed sensor 2 circuit, see «CHECK VEHICLE SPEED SENSOR 2»(ref-175204-S36482038712005041800000) . CHECK: Is there any trouble in vehicle speed sensor 2 circuit? YES: Repair or replace vehicle speed sensor 2 circuit, see «DTC 33: VEHICLE SPEED SENSOR 2 (FRONT)»(ref-175204-S24480792392005041800000) . NO: Go to step 9J6.
6. 9J6: CHECK ENGINE SPEED SIGNAL. NOTE: For the diagnostics procedure on engine speed signal circuit, see «CHECK ENGINE SPEED SIGNAL»(ref-175204-S12942017422005041800000) . CHECK: Is there any trouble in engine speed signal circuit? YES: Repair or replace engine speed signal circuit, see «DTC 11: ENGINE SPEED SIGNAL»(ref-175204-S06726801442005041800000) . NO: Go to step 9J7.
7. 9J7: CHECK INHIBITOR SWITCH. Read data of range switch using Subaru Select Monitor. Range switch is indicated in ON <=> OFF. CHECK: When each range is selected, does LED of the range switch on Subaru Select Monitor light up? YES: Go to step transfer duty solenoid, see «K: CHECK TRANSFER DUTY SOLENOID»(ref-175204-S41643968492005041800000) . NO: Check inhibitor switch circuit, see «T: CHECK INHIBITOR SWITCH»(ref-175204-S27328873982005041800000) .

CHECK TRANSFER DUTY SOLENOID

1. 9K1: CHECK OUTPUT SIGNAL EMITTED FROM TCM. Turn ignition switch to ON (engine OFF). Move select lever to "D". Read data of transfer duty solenoid using Subaru Select Monitor. Transfer duty solenoid is indicated in "%" (percent). CHECK: Does the duty solenoid change in response to the depress-release motion of the accelerator pedal? YES: Go to step 9K2. NO: Go to step 9K3.
2. 9K2: CHECK OUTPUT SIGNAL EMITTED FROM TCM. Turn ignition switch to OFF. Set FWD mode. Turn ignition switch to ON (engine OFF). CHECK: Does the Subaru Select Monitor indicate 95%? YES: Go to step throttle position sensor power supply, see «L: CHECK THROTTLE POSITION SENSOR POWER SUPPLY»(ref-175204-S02323819422005041800000) . NO: Go to step 9K3.
3. 9K3: CHECK THROTTLE POSITION SENSOR. NOTE: For the diagnostics procedure on throttle position sensor circuit, see «DTC 31: THROTTLE POSITION SENSOR»(ref-175204-S15853891962005041800000) . CHECK: Is there any trouble in throttle position sensor circuit? YES: Repair or replace throttle position sensor circuit, see «DTC 31: THROTTLE POSITION SENSOR»(ref-175204-S15853891962005041800000) . NO: Go to step 9K4.
4. 9K4: CHECK VEHICLE SPEED SENSOR 1. NOTE: For the diagnostics procedure on vehicle speed sensor 1 circuit, see «CHECK VEHICLE SPEED SENSOR 1»(ref-175204-S24776056542005041800000) . CHECK: Is there any trouble in vehicle speed sensor 1 circuit? YES: Repair or replace vehicle speed sensor 1 circuit, see «DTC 93: VEHICLE SPEED SENSOR 1 (REAR)»(ref-175204-S13837326062005041800000) . NO: Go to step 9K5.
5. 9K5: CHECK VEHICLE SPEED SENSOR 2. NOTE: For the diagnostics procedure on vehicle speed sensor 2 circuit, see «CHECK VEHICLE SPEED SENSOR 2»(ref-175204-S36482038712005041800000) . CHECK: Is there any trouble in vehicle speed sensor 2 circuit? YES: Repair or replace vehicle speed sensor 2 circuit, see «DTC 33: VEHICLE SPEED SENSOR 2 (FRONT)»(ref-175204-S24480792392005041800000) . NO: Go to step 9K6.
6. 9K6: CHECK ATF TEMPERATURE SENSOR. NOTE: For the diagnostics procedure on ATF temperature sensor circuit, see «CHECK ATF TEMPERATURE SENSOR»(ref-175204-S08273439632005041800000) . CHECK: Is there any trouble in ATF temperature sensor circuit? YES: Repair or replace ATF temperature sensor circuit, see «DTC 27: ATF TEMPERATURE SENSOR»(ref-175204-S24951476072005041800000) . NO: Go to step 9K7.
7. 9K7: CHECK INHIBITOR SWITCH. Read data of range switch using Subaru Select Monitor. Range switch is indicated in ON <=> OFF. CHECK: When each range is selected, does LED of range switch on Subaru Select Monitor light up? YES: Go to step 9K8. NO: Check inhibitor switch circuit, see «T: CHECK INHIBITOR SWITCH»(ref-175204-S27328873982005041800000) .
8. 9K8: CHECK ABS SIGNAL. Start the engine, and turn Subaru Select Monitor switch to ON. Read data of ABS signal using Subaru Select Monitor. ABS switch is indicated in ON <=> OFF. CHECK: Does the LED of ABS switch light up? YES: Check ABS signal circuit, see «TROUBLE CODE 44 ABS-AT CONTROL (NON CONTROLLED)»(ref-175571-S12204993152005042200000) and «TROUBLE CODE 44 ABS-AT CONTROL (CONTROLLED)»(ref-175571-S33432492952005042200000) . NO: Go to step throttle position sensor power supply, see «CHECK THROTTLE POSITION SENSOR POWER SUPPLY»(ref-175204-S02323819422005041800000) .

CHECK THROTTLE POSITION SENSOR POWER SUPPLY

1. 9L1: CHECK THROTTLE POSITION SENSOR POWER SUPPLY. Read data of throttle position sensor power supply using Subaru Select Monitor. Throttle position sensor power supply voltage is indicated. CHECK: Is the value fixed between 4.8 and 5.3 V? YES: Go to step intake manifold pressure signal, see «CHECK INTAKE MANIFOLD PRESSURE SIGNAL»(ref-175204-S16049158812005041800000) . NO: Check throttle position sensor power supply circuit, see «DTC 31: THROTTLE POSITION SENSOR»(ref-175204-S15853891962005041800000) .

CHECK INTAKE MANIFOLD PRESSURE SIGNAL

1. 9M1: CHECK INPUT SIGNAL FOR TCM. Start the engine. Warm-up the engine until engine coolant temperature is above 80°C (176°F). NOTE: If ambient temperature is below 0°C (32°F), drive the vehicle until the ATF reaches its operating temperature. Engine idling after warm-up. Move select lever to "N". Read data of intake manifold pressure signal using Subaru Select Monitor. Display shows intake manifold pressure signal value sent from ECM. CHECK: Does voltage change in response to the depress-release motion of the accelerator pedal? YES: Go to step 9M2. NO: Check intake manifold pressure signal circuit, «DTC 45: INTAKE MANIFOLD PRESSURE SIGNAL»(ref-175204-S35426654962005041800000) .
2. 9M2: CHECK ECM. CHECK: Has trouble been eliminated after ECM replacement? YES: Replace ECM, see «ENGINE CONTROL MODULE»(ref-175204-S08951395982005042600000) . NO: Go to step 9M3.
3. 9M3: CHECK TCM. NOTE: Install former ECM. CHECK: Has trouble been eliminated after TCM replacement? YES: Replace TCM, see «TRANSMISSION CONTROL MODULE (TCM)»(ref-175202-S19617217002005041800000) . NO: Go to step torque converter turbine speed sensor, see «CHECK TORQUE CONVERTER TURBINE SPEED SENSOR»(ref-175204-S08910489822005041800000) .

CHECK 2-4 BRAKE DUTY SOLENOID

1. 9O1: CHECK OUTPUT SIGNAL EMITTED FROM TCM. Warm-up the transmission until ATF temperature is above 80°C (176°F). NOTE: If ambient temperature is below 0°C (32°F), drive the vehicle until the ATF reaches its operating temperature. Stop the engine and turn ignition switch to ON (engine OFF). Move select lever to "N". Read data of 2-4 brake duty solenoid using Subaru Select Monitor. 2-4 brake duty solenoid is indicated in "%" (percent). CHECK: Does the Subaru Select Monitor indicate 100% when the accelerator pedal is completely released? YES: Go to step 9O2. NO: Go to step 9O4.
2. 9O2: CHECK OUTPUT SIGNAL EMITTED FROM TCM. CHECK: Does the Subaru Select Monitor indicate between 10 and 20% when the accelerator pedal is completely depressed? YES: Go to step 9O3. NO: Go to step 9O4.
3. 9O3: CHECK OUTPUT SIGNAL EMITTED FROM TCM. CHECK: Does the Subaru Select Monitor change smoothly when the accelerator pedal is fully depressed and then fully released? YES: Go to step FWD switch, see «P: CHECK FWD SWITCH»(ref-175204-S11020599542005041800000) . NO: Go to step 9O4.
4. 9O4: CHECK THROTTLE POSITION SENSOR. NOTE: For the diagnostics procedure on throttle position sensor circuit, see «CHECK THROTTLE POSITION SENSOR»(ref-175204-S22676780092005041800000) . CHECK: Is there any trouble in throttle position sensor circuit? YES: Repair or replace throttle position sensor circuit, See «DTC 31: THROTTLE POSITION SENSOR»(ref-175204-S15853891962005041800000) . NO: Go to step 9O5.
5. 9O5: CHECK ENGINE SPEED SIGNAL. NOTE: For the diagnostics procedure on engine speed signal circuit, see «CHECK ENGINE SPEED SIGNAL»(ref-175204-S12942017422005041800000) . CHECK: Is there any trouble in engine speed signal circuit? YES: Repair or replace engine speed signal circuit, see «DTC 11: ENGINE SPEED SIGNAL»(ref-175204-S06726801442005041800000) . NO: Go to step 9O6.
6. 9O6: CHECK ATF TEMPERATURE SENSOR. NOTE: For the diagnostics procedure on ATF temperature sensor circuit, see «CHECK ATF TEMPERATURE SENSOR»(ref-175204-S08273439632005041800000) . CHECK: Is there any trouble in ATF temperature sensor circuit? YES: Repair or replace ATF temperature sensor circuit, see «DTC 27: ATF TEMPERATURE SENSOR»(ref-175204-S24951476072005041800000) . NO: Go to step 9O7.
7. 9O7: CHECK INHIBITOR SWITCH. Turn ignition switch and Subaru Select Monitor to ON. Read data of range switch using Subaru Select Monitor. Range switch is indicated in ON <=> OFF. CHECK: When each range is selected, does LED of the range switch on Subaru Select Monitor light up? YES: Go to step FWD switch, see «CHECK FWD SWITCH»(ref-175204-S11020599542005041800000) . NO: Check inhibitor switch circuit, see «CHECK INHIBITOR SWITCH»(ref-175204-S27328873982005041800000) .

CHECK BRAKE SWITCH

1. 9Q1: CHECK BRAKE SWITCH. CHECK: When the brake pedal is depressed, does LED light up? YES: Go to step ABS switch, see «CHECK ABS SWITCH»(ref-175204-S05753047162005041800000) . NO: Check brake switch circuit.

CHECK ABS SWITCH

1. 9R1: CHECK ABS SWITCH. CHECK: Does the LED of ABS switch light up? YES: Check ABS switch circuit, see «TROUBLE CODE 44 ABS-AT CONTROL (NON CONTROLLED)»(ref-175571-S12204993152005042200000) and «TROUBLE CODE 44 ABS-AT CONTROL (CONTROLLED)»(ref-175571-S33432492952005042200000) . NO: Go to step cruise control switch, see «S: CHECK CRUISE CONTROL SWITCH»(ref-175204-S13707708232005041800000) .

CHECK CRUISE CONTROL SWITCH

1. 9S1: CHECK CRUISE CONTROL SWITCH. CHECK: When cruise control is set, does LED light up? YES: Go to step inhibitor switch, see «CHECK INHIBITOR SWITCH»(ref-175204-S27328873982005041800000) . NO: Check cruise control.

CHECK SHIFT SOLENOID 1

1. 9U1: CHECK SHIFT SOLENOID 1. CHECK: Does the LED of shift solenoid 1 light up? YES: Go to step shift solenoid 2, see «CHECK SHIFT SOLENOID 2»(ref-175204-S28417949922005041800000) . NO: Check shift solenoid 1 circuit, see «DTC 71: SHIFT SOLENOID 1»(ref-175204-S40170884592005041800000) .

CHECK SHIFT SOLENOID 2

1. 9V1: CHECK SHIFT SOLENOID 2. CHECK: Does the LED of shift solenoid 2 light up? YES: Go to step torque control 1 signal, see «CHECK TORQUE CONTROL 1 SIGNAL»(ref-175204-S18501714642005041800000) . NO: Check shift solenoid 2 circuit. See «DTC 72: SHIFT SOLENOID 2»(ref-175204-S39883890782005041800000) .

CHECK 2-4 BRAKE TIMING SOLENOID

1. 9Y1: CHECK 2-4 BRAKE TIMING SOLENOID. Turn ignition switch to ON, and select 1 range. CHECK: Does the LED of 2-4 brake timing solenoid illuminate? YES: Go to step low clutch timing solenoid. See «CHECK LOW CLUTCH TIMING SOLENOID»(ref-175204-S01162844752005041800000) . NO: Check 2-4 brake timing solenoid circuit, see «DTC 74: 2-4 BRAKE TIMING SOLENOID»(ref-175204-S18402732932005041800000) .

CHECK LOW CLUTCH TIMING SOLENOID

1. 9Z1: CHECK LOW CLUTCH TIMING SOLENOID. Turn ignition switch to ON, and select 2 range. CHECK: Does the LED of low clutch timing solenoid illuminate? YES: Go to step diagnosis light, see «CHECK DIAGNOSIS LIGHT»(ref-175204-S09086149782005041800000) . NO: Check low clutch timing solenoid circuit. See «DTC 73: LOW CLUTCH TIMING SOLENOID»(ref-175204-S23579304582005041800000) .

CHECK FWD LIGHT

1. 9AB1: CHECK FWD LIGHT. CHECK: Does the LED of FWD light illuminate? YES: Check FWD switch circuit. See «CHECK FWD SWITCH»(ref-175204-S11020599542005041800000) . NO: Go to step general diagnostic table, see «GENERAL DIAGNOSTIC TABLE»(ref-175204-S33007318812005041800000) .

General Diagnostic Table (1 Of 5). Scheme 637

General Diagnostic Table (2 Of 5). Scheme 638

General Diagnostic Table (3 Of 5). Scheme 639

General Diagnostic Table (4 Of 5). Scheme 640

General Diagnostic Table (5 Of 5). Scheme 641

Scheme 642

Scheme 643

Scheme 644

Scheme 645

Scheme 646

Scheme 647

Scheme 648

Scheme 649

1. Disconnect battery ground cable. (Scheme 642): Disconnecting Battery Ground Cable
2. Remove side sill front cover. (Scheme 643): Removing Side Sill Front Cover
3. Detach floor mat of front passenger seat. (Scheme 644): Detaching Floor Mat Of Front Passenger Seat
4. Remove protect cover. (Scheme 645): Removing Protect Cover
5. Remove nuts which hold ECM to bracket. (Scheme 646): Removing Nuts Which Hold ECM To Bracket
6. Remove clip from bracket. (Scheme 647): Removing Clip From Bracket
7. Disconnect ECM connectors. (Scheme 648): Disconnecting ECM Connectors
8. Take out ECM. (Scheme 649): Removing ECM
9. Install in the reverse order of removal. CAUTION: When replacing ECM, be careful not to use the wrong specification. ECM to avoid any damage to the fuel injection system.

Scheme 650

Scheme 651

Scheme 652

Scheme 653

1. Disconnect battery ground cable. (Scheme 650): Disconnecting Battery Ground Cable
2. Disconnect connector from throttle position sensor. (Scheme 651): Disconnecting Connector From Throttle Position Sensor
3. Remove throttle position sensor holding screws, and remove it. (Scheme 652): Removing Throttle Position Sensor Holding Screws
4. Install in the reverse order of removal. Tightening torque: 2.2+/-0.2 N.m (0.22+/-0.02 kg-m, 1.6+/-0.1 ft-lb) CAUTION: When installing throttle position sensor, adjust to the specified data. (Scheme 653): Tightening Fasteners To Specification After Adjustment

Scheme 654

Scheme 655

Scheme 656

Scheme 657

Scheme 658

1. Turn ignition switch to OFF.
2. Loosen throttle position sensor holding screws. (Scheme 654): Loosen Throttle Position Sensor Holding Screws
3. When using voltage meter; Take out ECM. Turn ignition switch to ON. Adjust throttle position sensor to the proper position to allow the voltage signal to ECM to be in specification. Connector & terminal / Specified voltage (B136) No. 15 - (B136) No. 17/0.45 - 0.55 V Fully Closed. (Scheme 655): Adjusting Voltage Signal To ECM To Specification Tighten throttle position sensor holding screws. Tightening torque: 2.2+/-0.2 N.m (0.22+/-0.02 kg-m, 1.6+/-0.1 ft-lb) (Scheme 656): Tightening Fasteners To Specification
4. When using Subaru Select Monitor; Turn ignition switch to OFF. Loosen throttle position sensor holding screws. (Scheme 657): Loosen Throttle Position Sensor Holding Screws NOTE: For detailed operation procedures, refer to the Subaru Select Monitor Operation Manual. Insert the cartridge to Subaru Select Monitor. (Scheme 658): Inserting Cartridge Into Subaru Select Monitor Connect Subaru Select Monitor to the data link connector.
5. Turn ignition switch to ON, and Subaru Select Monitor switch to ON.
6. Select {2. Each System Check} in Main Menu.
7. Select {Engine Control System} in Selection Menu.
8. Select {1. Current Data Display & Save} in Engine Control System Diagnosis.
9. Select {1.12 Data Display} in Data Display Menu.
10. Adjust throttle position sensor to the proper position to match with the following specifications. Condition: Throttle fully closed. Throttle opening angle 0.00%. Throttle sensor voltage 0.50 V.
