Identifying Gear Shift Lever Components. Scheme 659

Scheme 659: Identifying Gear Shift Lever Components

Tightening torque: N.m (kg-m, ft-lb)

T1: 4.5+/-1.5 (0.46+/-0.15, 3.3+/-1.1)

T2: 5 (0.51, 3.7)

T3: 12+/-3 (1.2+/-0.3, 8.7+/-2.2)

T4: 18+/-5 (1.8+/-0.5, 13.0+/-3.6)

T5: 24.5+/-2 (2.50+/-0.20, 18.07+/-1.48)

Identifying Select Lever Components. Scheme 660

Scheme 660: Identifying Select Lever Components

Tightening torque: N.m (kg-m, ft-lb)

T1: 4.5+/-1.5 (0.46+/-0.15, 3.3+/-1.1)

T2: 18+/-5 (1.8+/-0.5, 13.0+/-3.6)

T3: 32+/-10 (3.3+/-1.0, 24+/-7)

Scheme 661

Scheme 661: Removal

Scheme 662

Scheme 662

Scheme 663

Scheme 663

Scheme 664

Scheme 664

Scheme 665

Scheme 665

Scheme 666

Scheme 666

Scheme 667

Scheme 667

Scheme 668

Scheme 668
  1. Remove gear shift knob.
  2. Remove front cover, see «FRONT COVER - CENTER CONSOLE»(ref-175206-S08755492302005050200000).
  3. Remove console boot.
  4. Remove boot plate from body. (Scheme 661): Removing Console Boot & Boot Plate
  5. Remove rear exhaust pipe and muffler. See «REAR EXHAUST PIPE»(ref-176319-S03748520142005050300000). CAUTION: When removing exhaust pipes, make sure no exhaust pipes drop out. (Scheme 662): Removing Rear Exhaust Pipe And Muffler
  6. Remove heat shield cover. (Scheme 663): Removing Heat Shield Cover
  7. Remove stay from transmission bracket. (Scheme 664): Removing Stay From Transmission Bracket
  8. Remove rod from joint. (Scheme 665): Removing Rod From Joint
  9. Remove cushion rubber from body. (Scheme 666): Removing Cushion Rubber From Body
  10. Remove joint and then extract straight pin. (Scheme 667): Removing Joint & Extracting Straight Pin
  11. Remove gear shift lever. (Scheme 668): Removing Gear Shift Lever

Scheme 669

Scheme 669: Disassembly

Scheme 670

Scheme 670

Scheme 671

Scheme 671

Scheme 672

Scheme 672

Scheme 673

Scheme 673

Scheme 674

Scheme 674
  1. Disassemble locking wire. (Scheme 669): Removing Locking Wire
  2. Remove rod from gear shift lever. (Scheme 670): Removing Rod From Gear Shift Lever
  3. Remove snap ring from bush D, then disconnect stay. (Scheme 671): Removing Snap Ring From Bush "D"
  4. Remove boot from gear shift lever.
  5. Remove bush and cushion rubber from stay. (Scheme 672): Removing Bush & Cushion Rubber From Stay
  6. Remove O-ring, then disconnect bush D. (Scheme 673): Removing O-Ring & Disconnect Bush "D"
  7. Draw out straight pin, then remove bush C from gear shift lever. (Scheme 674): Removing Straight Pin & Removing Bush "C"
