Shift Control System: Overview Saab 9-2X I

Scheme 1

1. Grip
2. Indicator cover
3. Cover
4. Blind
5. Cushion
6. Button
7. Clip
8. "P" range switch
9. Spring
10. Guide plate
11. Detent arm
12. Detent spring
13. Tube
14. Select lever COMPL
15. Spring pin
16. Bushing
17. Bracket
18. Bushing
19. Lock plate B
20. Bushing
21. Bushing
22. Lock plate A (Saab 9-2X 2.5i Linear)
23. Bushing
24. Lock plate C
25. Shift lock solenoid
26. Clamp
27. Indicator light bulb
28. Clip
29. Select lever lower
30. Bushing COMPL
31. Base plate
32. Grommet
33. Packing
34. Spacer
35. Washer
36. Snap pin
37. Select cable
38. Adjusting nut B
39. Adjusting nut A
40. Cover
41. Clip
42. Lock plate A (Saab 9-2X 2.0T Aero)

Tightening torque: Nm (kgfm, ft-lb)

T1: 2.0 (0.2, 1.4)

T2: 7.5 (0.76, 5.5)

T3: 13 (1.3, 9.4)

T4: 18 (1.8, 13.0)

Scheme 2

1. Gear shift knob
2. Console boot
3. Plate ASSY
4. Lever
5. Bushing
6. Bushing
7. Lock wire
8. Boot
9. Snap ring
10. O-ring
11. Bushing A
12. Spring pin
13. Cushion rubber
14. Bushing B
15. Joint
16. Rod
17. Bracket
18. Washer
19. Stay
20. Spacer
21. Front cover

Tightening torque: Nm (kgfm, ft-lb)

T1: 7.5 (0.76, 5.5)

T2: 12 (1.2, 8.7)

T3: 18 (1.8, 13.0)
