Shift Control System: Other Saab 9-2X I

Automatic Trans 7 illustrations ~210 words

TECHNICAL DATA

ItemSpecification
Swing torque of rod against lever : N (kgf, lb)3.7 (0.38, 0.84) or less

TECHNICAL DATA

PRECAUTIONS

  1. Wear working clothing, including a cap, protective goggles, and protective shoes during operation.
  2. Remove contamination including dirt and corrosion before removal, installation or disassembly.
  3. Keep the disassembled parts in order and protect them from dust or dirt.
  4. Before removal, installation or disassembly, be sure to clarify the failure. Avoid unnecessary removal, installation, disassembly, and replacement.
  5. Use genuine grease etc. or the equivalent. Do not mix grease etc. with that of another grade or from other manufacturers.
  6. Be sure to tighten fasteners including bolts and nuts to the specified torque.
  7. Place shop jacks or rigid racks at the specified points.
  8. Apply grease onto sliding or revolution surfaces before installation.
  9. Before installing O-rings or snap rings, apply sufficient amount of grease to avoid damage and deformation.
  10. Before securing a part on a vise, place cushioning material such as wood blocks, aluminum plate, or shop cloth between the part and the vise.
  11. Before disconnecting electrical connectors, be sure to disconnect the ground cable from battery.

Scheme 57

Scheme 57: A/T SHIFT LOCK CONTROL SYSTEM
Scheme 57: A/T SHIFT LOCK CONTROL SYSTEM

Scheme 58

Scheme 58
Scheme 58

Scheme 59

Scheme 59
Scheme 59

Scheme 60

Scheme 60
Scheme 60

Scheme 61

Scheme 61
Scheme 61

Scheme 62

Scheme 62
Scheme 62
  1. Inhibitor switch
  2. Body integrated unit
  3. Stop light switch
  4. Key warning switch
  5. Shift lock solenoid
  6. "P" range switch
  7. Key lock solenoid

Scheme 63

Scheme 63: ELECTRICAL SPECIFICATION
Scheme 63: ELECTRICAL SPECIFICATION
ContentsTo Connector No.Terminal No.Input/Output signal
Measured value and measuring conditions
Battery power supplyB28029 - 16 V
Ignition power supplyB2811910 - 15 V when ignition switch is at ON or START.
Ignition power supplyB2811010 - 15 V when ignition switch is at ACC.
Inhibitor Switch ("P" range)B28150 V when select lever is in "P" range. 9 - 16 V when select lever is in other ranges than "P" range.
Stop light switchB28199 - 16 V when stop light switch is ON. 0 V when stop light switch is OFF.
"P" range switchB28160 V when select lever is in "P" range. 9 - 16 V when select lever is in other ranges than "P" range.
Shift lock solenoid signalB28098.5 - 16 V when shift lock is released. 0 V when shift lock is operating.
Key warning switch signalB281209 - 16 V when key is inserted. 0 V when key is removed.
Key lock solenoid signalB28037.5 - 16 V when turning ignition switch to ON, select lever is in "P" range and brake switch is ON. 0 V at other conditions than above.
GroundB2804
GroundB28013

ELECTRICAL SPECIFICATION - TECHNICAL DATA
