SPECIAL TOOL
Note. To view special tools (Scheme 392)- (Scheme 434).
| TOOL NUMBER | DESCRIPTION | REMARKS |
|---|---|---|
| ST-498575400 | OIL PRESSURE GAUGE ASSY | Used for measuring oil pressure. |
| ST-498897200 | OIL PRESSURE GAUGE ADAPTER | Used oil pump housing when measuring reverse clutch pressure and line pressure. |
| ST-498897700 | OIL PRESSURE ADAPTER SET | Used for measuring transfer clutch pressure. |
| ST-498545400 | OIL FILTER WRENCH | Used for removing and installing ATF filter. |
| ST-498277200 | STOPPER SET | Used for removing and installing automatic transmission assembly to engine. |
| ST41099AC000 | ENGINE SUPPORT ASSY | Used for supporting engine. |
| ST-398527700 | PULLER ASSY | Used for removing extension case roller bearing. Used for removing extension oil seal. Used for removing front differential side retainer bearing outer race. Used for removing front differential side retainer bearing outer ball race. |
| ST-498057300 | INSTALLER | Used for installing extension oil seal. |
| ST-498077000 | REMOVER | Used for removing differential taper roller bearing. |
| ST-499247400 | INSTALLER | Used for installing transfer outer snap ring. Used with SNAP RING OUTER GUIDE (32005128). |
| ST-499257300 | SNAP RING OUTER GUIDE | Used for installing transfer outer snap ring. Used with INSTALLER (32005127). |
| ST18630AA010 | WRENCH ASSY | Used for removing and installing differential side retainer. |
| ST-398437700 | DRIFT | Used for installing converter case oil seal. Used for installing taper roller bearing of front differential. |
| ST-398673600 | COMPRESSOR | Used for removing and installing clutch spring. |
| ST-498255400 | PLATE | Used for measuring backlash of hypoid gear. |
| ST-399893600 | PLIERS | Used for removing and installing clutch spring. |
| ST-498247001 | MAGNET BASE | Used for measuring gear backlash. Used with DIAL GAUGE (32005095). |
| ST-498247100 | DIAL GAUGE | Used for measuring gear backlash. Used with MAGNET BASE (32005094). |
| ST-498517000 | REPLACER | Used for removing front roller bearing. |
| ST-398623600 | SEAT | Used for removing spring of transfer clutch piston. |
| ST-499267300 | STOPPER PIN | Used for installing inhibitor switch. |
| ST-499787700 | WRENCH | Used for removing and installing drive pinion lock nut. |
| ST-499787500 | ADAPTER | Used for removing and installing drive pinion lock nut. |
| ST-398643600 | GAUGE | Used for measuring total end play, extension end play and drive pinion height. |
| ST-498627100 | SEAT | Used for holding low clutch piston retainer spring when installing snap ring. |
| ST-499577000 | GAUGE | Used for measuring the transmission case mating surface to the reduction gear end surface. For MPT model. |
| ST-398744300 | GAUGE | Use for measuring contact face between multi-plate clutch end and transmission. For VTD model. |
| ST-499737000 | PULLER | Used for removing reduction driven gear assembly. |
| ST-499737100 | PULLER SET | Used for removing reduction drive gear assembly. |
| ST-498077600 | REMOVER | Used for removing ball bearing. |
| ST-498937110 | HOLDER | Used for removing and installing drive pinion lock nut. |
| ST-498677100 | COMPRESSOR | Used for installing 2 -4 brake snap ring. |
| ST-498437000 | HIGH CLUTCH PISTON GUIDE | Used for installing high clutch piston. |
| ST-498437100 | LOW CLUTCH PISTON GUIDE | Used for installing low clutch piston. |
| ST-899580100 | INSTALLER | Used for press-fitting the ball bearing for transfer clutch. |
| ST18675AA000 | DIFFERENTIAL SIDE OIL SEAL INSTALLER | Used for installing differential side retainer oil seal. |
| ST28399SA010 | OIL SEAL PROTECTOR | Used for installing front drive shaft. |
| ST-398497701 | INSTALLER | Used for installing needle bearing. |
| ST-899524100 | PULLER SET | Used for bolt only. Used with PULLER SET (32005145). Used with PULLER (32005144). Puller Cap |
| ST-398663600 | PLIERS | Used for removing and installing snap ring. |
| ST-499977100 | CRANK PULLEY WRENCH | Used for stopping rotation of crank pulley when loosening and tightening crank pulley bolts. (Saab 9 -2X 2.5i Linear) |
| ST-499977400 | CRANK PULLEY WRENCH | Used for stopping rotation of crank pulley when loosening and tightening crank pulley bolt. (Saab 9 -2X 2.0T Aero) |
| ST22771AA030 | Vehicle Diagnostic Interface | Troubleshooting for electrical systems. |
