6.7L Diesel Engine - Service Information: Component Locations RAM Pickup 2500

SPECIAL TOOLS

10136 - Installer, Crankshaft Front Oil Seal (Originally Shipped In Kit Number(s) 10138.) 10137 - Adapter, Charge Air (Originally Shipped In Kit Number(s) 10138.) 10142 - Cummins Turbo Cleaning Kit (Originally Shipped In Kit Number(s) 10138-UPD.) 10143 - Cummins Turbo Drilling Kit (Originally Shipped In Kit Number(s) 10138-UPD.) 10143-4 - Drill Assembly (Originally Shipped In Kit Number(s) 10138-UPD.) 10143-5 - Tap & Collar Assembly (Originally Shipped In Kit Number(s) 10138-UPD.) 10368 - Set, Universal Protective Cap 7471B - Barring Tool (Originally Shipped In Kit Number(s) 6860.) 8281 - Installer, Seal (Originally Shipped In Kit Number(s) 8267, 8267CC, 9697, 9698.) 8319 - Compressor, Valve Spring (Originally Shipped In Kit Number(s) 8267, 8267CC.) 8502 - Remover/Installer 8534B - Fixture, Driveline Support (Originally Shipped In Kit Number(s) 8534, 8534B, 8849, 9565.) 9007 - Adapter, Compression Test (Originally Shipped In Kit Number(s) 8848, 8849, 8849CC.) 9009 - Bracket, Engine Lifting (Originally Shipped In Kit Number(s) 8848, 8849, 8849CC.) 9010A - Remover/Installer, Fuel Injector (Originally Shipped In Kit Number(s) 8848, 8849.) 9015 - Remover, High Pressure Connector (Originally Shipped In Kit Number(s) 8848, 8849, 8849CC.) 9864 - Cap, Fuel Rail (Originally Shipped In Kit Number(s) 9860.) 9866 - Wrench, Turbo Charger Bolt (Originally Shipped In Kit Number(s) 9860.) C-3292A - Gauge, Pressure C-4171 - Driver Handle, Universal (Originally Shipped In Kit Number(s) 9202, 9202A-CAN, 9202CC, 9299, 9299CC, 9299CC, 9300A-CAN.) C-647 - Spring Tester

Scheme 559

Scheme 560

Scheme 561

Scheme 562

Scheme 563

Scheme 564

Scheme 565

Scheme 566

Scheme 567

The engine data plate (1) contains specific information that is helpful to servicing and obtaining parts for the engine. The data plate is on the cylinder head cover. Information that can be found on the data plate includes

1. Engine Part Number
2. Date of Engine Manufacture
3. Engine Serial Number
4. Control Parts List (CPL)
5. Engine Rated Horsepower
6. Engine Firing Order
7. Engine Displacement
8. Valve Lash Reset Specifications

If the engine data plate is missing or not legible, the engine serial number is used for engine identification. The engine serial number is stamped on the right side of the block, on top of the oil cooler cavity.
