3.7L Engine - Service Information: Component Locations RAM Pickup 2500

SPECIAL TOOLS

1023 - Puller (Originally Shipped In Kit Number(s) 8678.) 10368 - Set, Universal Protective Cap 6871 - Installer, A/C Hub (Originally Shipped In Kit Number(s) 6896.) 6958 - Wrench, Spanner (Originally Shipped In Kit Number(s) 6947, 6949, 6966, 8204, 8204CC, 8667.) 7700 - Tester, Cooling System (Originally Shipped In Kit Number(s) 7700-A.) 8346 - Pins, Adapter (Originally Shipped In Kit Number(s) 8503, 8510, 8520, 8520CC.) 8348 - Installer, Seal (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8349 - Installer, Crankshaft Rear Oil Seal (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC.) 8349-2 - Guide Crank Seal (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC.) 8379 - Locking Tool, Wedge (Originally Shipped In Kit Number(s) 8703, 8703CC.) 8387 - Compressor, Valve Spring (Originally Shipped In Kit Number(s) 8653, 8700, 8700CC.) 8427 - Fixture, Engine Lifting (Originally Shipped In Kit Number(s) 8703, 8703CC, 8712, 9975.) 8428A - Holder, Camshaft (Originally Shipped In Kit Number(s) 10134, 10134, 9975.) 8429 - Holder, Secondary Camshaft Chain (Originally Shipped In Kit Number(s) 8703, 8703CC, 8712, 9975.) 8454 - 3-Jaw Puller (Originally Shipped In Kit Number(s) 8673, 8675, 8676, 8709, 8709CC.) 8506 - Remover, Seal (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC.) 8507 - Guides, Connecting Rod (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC.) 8511 - Remover, Seal (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8512A - Installer, Damper (Originally Shipped In Kit Number(s) 8283, 8527, 8575, 8575CC, 8660, 8661.) 8513A - Insert, Crankshaft (Originally Shipped In Kit Number(s) 8283, 8527, 8575, 8999, 8999CC.) 8514 - Pins, Tensioner (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8516A - Remover/Installer (Originally Shipped In Kit Number(s) 8283, 8527, 8534B, 8575, 9090, 9300, 9975.) 8517 - Remover (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8519 - Adapters, Valve Spring (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8534B - Fixture, Driveline Support (Originally Shipped In Kit Number(s) 8534, 8534B, 8849, 9565.) 8641 - Remover/Installer (Originally Shipped In Kit Number(s) 8703, 8703CC, 8712, 9975.) 9867 - Wedge, Locking (Originally Shipped In Kit Number(s) 9998, 9999.) C-119 - Cylinder Indicator C-3292A - Gauge, Pressure C-3422-D - Compressor, Valve Spring C-3501 - Hone W/Oil, AMMCO Cylinder C-3501-3810 - Stones, 220 Grit Honing C-3501-3880 - Oil, Honing C-3685-A - Bloc-Chek Kit C-4171 - Driver Handle, Universal (Originally Shipped In Kit Number(s) 9202, 9202A-CAN, 9202CC, 9299, 9299CC, 9299CC, 9300A-CAN.) C-823 - Hone, Cylinder

Scheme 107

Scheme 108

Scheme 109

Scheme 110

Scheme 111

Scheme 112

Scheme 113

Scheme 114

Scheme 115

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Scheme 120

Scheme 121

Scheme 122

Scheme 123

Scheme 124

1. Loosen clamp (1) and disconnect air duct (2) at air cleaner cover (3).
2. Pry over 4 spring clips (5) from housing cover (3).
3. Release housing cover (3) from locating tabs on housing and remove cover.
4. Remove air cleaner element (filter) from housing.
5. Clean inside of housing before replacing element.
