3.7L Engine - Service Information: Overhaul RAM Pickup 2500

DISASSEMBLY

1. Remove oil pump cover screws and lift off cover plate.
2. Remove pump inner and outer rotors. NOTE: Once the oil pressure relief valve, cup plug, and pin are removed, the pump assembly must be replaced.
3. If it is necessary to remove the pressure relief valve, drive the roll pin from pump housing and remove cup plug, spring and valve.

Scheme 99

Scheme 100

Scheme 101

Scheme 102

Scheme 103

Scheme 104

1. Clean all parts thoroughly. Mating surface of the oil pump housing should be smooth. If the pump cover is scratched or grooved the oil pump assembly should be replaced.
2. Lay a straight edge across the pump cover surface (3). If a 0.025 mm (0.001 in.) feeler gauge (2) can be inserted between the cover and the straight edge the oil pump assembly should be replaced.
3. Measure the thickness of the outer rotor. If the outer rotor thickness measures at 12.005 mm (0.472 in.) or less the oil pump assembly must be replaced.
4. Measure the diameter of the outer rotor. If the outer rotor diameter measures at 85.925 mm (3.382 in.) or less the oil pump assembly must be replaced.
5. Measure the thickness of the inner rotor. If the inner rotor thickness measures at 12.005 mm (0.472 in.) or less then the oil pump assembly must be replaced. 1 - FEELER GAUGE 2 - OUTER ROTOR
6. Slide outer rotor (2) into the body of the oil pump. Press the outer rotor to one side of the oil pump body and measure clearance between the outer rotor and the body. If the measurement is 0.235 mm (0.009 in.) or more the oil pump assembly must be replaced. 1 - OUTER ROTOR 2 - FEELER GAUGE 3 - INNER ROTOR
7. Install the inner rotor into the oil pump body. Measure the clearance between the inner (3) and outer (1) rotors. If the clearance between the rotors is.150 mm (0.006 in.) or more the oil pump assembly must be replaced. 1 - STRAIGHT EDGE 2 - FEELER GAUGE
8. Place a straight edge (1) across the body of the oil pump (between the bolt holes), if a feeler gauge (2) of.095 mm (0.0038 in.) or greater can be inserted between the straightedge and the rotors, the pump must be replaced.

Note. The 3.7L/4.7L Oil pump is released as an assembly. There are no Chrysler part numbers for Sub-Assembly components. In the event the oil pump is not functioning or out of specification it must be replaced as an assembly.

ASSEMBLY

1. Wash all parts in a suitable solvent and inspect carefully for damage or wear.
2. Install inner and outer rotors
3. Install oil pump cover plate and install cover bolts and tighten them to 12 N.m (105 in. lbs.).
4. Prime oil pump before installation by filling rotor cavity with engine oil.
5. If oil pressure is low and pump is within specifications, inspect for worn engine bearings or other causes for oil pressure loss.

Scheme 105

Scheme 106

1. Position the oil pump onto the crankshaft and install one oil pump retaining bolt.
2. Position the primary timing chain tensioner and install three retaining bolts.
3. Tighten the oil pump and primary timing chain tensioner retaining bolts to 28 N.m (250 in. lbs.) in the sequence shown in illustration.
4. Install the secondary timing chain tensioners and timing chains. Refer to «CHAIN and SPROCKETS, Timing , Installation , 3.7L»(ref-457795-S27896854792012030200000) .
5. Install the timing chain cover. Refer to «COVER(S), Engine Timing , Installation , 3.7L»(ref-457795-S34138853242012030200000) .
6. Install the pick-up tube and oil pan. Refer to «PAN, Oil , Installation , 3.7L»(ref-457795-S42017704832012030200000) .
