Replace Intelligent Battery Sensor (Start/stop System) Opel Corsa D

Remove

1. 1. Disconnect wiring harness connector (3) from intelligent battery sensor (2)
2. 2. Undo terminal post nut (1)

3. 3. Secure/counterhold the intelligent battery sensor (2) in installed state using a suitable tool (5) (e.g. open-ended wrench with SW 16) at points provided (1)
4. 4. Remove nut (3) and ground cable (4) and set aside
5. 5. Undo terminal post further, if necessary, and remove the intelligent battery sensor

Note. Material fractures or damage to the intelligent battery sensor and battery can result if the work is carried out without a counterhold. If necessary, get a second mechanic.

Install

6. 6. Attach the intelligent battery sensor to battery negative terminal and tighten terminal post to 4.5 Nm
7. 7. Attach ground cable (4) to the intelligent battery sensor
8. 8. Fit nut (3)
9. 9. Secure/counterhold the intelligent battery sensor (2) using a suitable tool (5) (e.g. open-ended wrench with SW 16) at points provided (1)
10. 10. Tighten nut (3) to 11 Nm

Note. Material fractures or damage to the intelligent battery sensor and battery can result if the work is carried out without a counterhold. If necessary, get a second mechanic.

11. 11. Attach wiring harness connector (1) to the intelligent battery sensor (2)

12. 12. Program volatile memories
