Important: When replacing the control unit, before removing the control unit carry out a "Reset" using TECH 2.
Remove
- 1. Disconnect battery
- 2. Unclip the panel, instrument housing assembly (1) • Release 5 clamps (2)
- 3. Remove instrument housing assembly • Unscrew 3x bolts (1) • Release wiring harness plug (2) and disconnect
Install
- 4. Install instrument housing assembly • Connect wiring harness plug and latch • Tighten 3x bolts
- 5. Clip in the panel, instrument housing assembly • Insert 5 clamps
- 6. Connect battery
- 7. Program volatile memories
Note. When replacing the control unit, after installing the control unit, execute "Program" with TECH 2.
