Special Tools Opel Agila A

DOHC Petrol Engine 31 illustrations
KM-194-ESpark plug socket wrench
Removal, installation of spark plugs
KM-235-DAssembly tool
Installation of rear crankshaft sealing ring in combination with KM-658
KM-328-BPuller
Pulling injectors out of the cylinder head in combination with KM-931
KM-412Engine assembly stand
Holding dismantled engine
KM-412-18Adapter
Holding the engine in combination with KM-412
KM-427Tool for pressing out, pressing in
KM-470-BAngled tightening wrench
Tightening cylinder head bolts
KM-471Adapter
Testing the cooling system under pressure in combination with the cooling system tester and KM-6132
KM-498-BOil pressure gauge
Testing engine oil pressure
MKM-571-BMeasuring gauge
MKM-596-ATemperature measuring instrument
Measuring the oil temperature
MKM-604-DTorx bit and socket set
Installation and removal of Torx-screws
MKM-610Torque wrench 1 / 2 " - drive
Range: 30 - 130 Nm
Use when tightening all screwed joints to a specified torque
MKM-611Torque wrench 3 / 8 " - drive
Range: 10 - 60 Nm
For use when tightening all screwed joints to a specified torque
KM-652Flywheel bracket
Locking the flywheel or drive pulley
KM-658Installer
Installation of rear crankshaft sealing ring
MKM-669Torque wrench 1 / 2 " - drive
Range: 50 - 300 Nm
For use when tightening all screwed joints to a specified torque
KM-796-ARemover
Opening snap connections in the fuel system
KM-807Sealing bung
Sealing the fuel lines
MKM-883-1Engine bridge
Installation and removal of engine damping blocks
MKM-883-4Hook
Holding the engine with MKM-883-1
KM-904Base frame
Installation and removal of engine with transmission using KM-6054
KM-952Locking pin
Locking pin, crankshaft TDC-position
KM-955Locking pins
Locking ribbed V-belt and chain tensioner
KM-956Holding wrench
Counterhold when removing and installing the crankshaft hub
KM-953Fixing gauge
Fixing the camshafts 1st cylinder "ignition TDC"
KM-954Fixing gauge
Fixing-phase sensor disc camshaft
KM-957Adapter
Tensioning the valve spring with KM-348 (cylinder head dismantled)
KM-958Installer
Insert valve stem seals
KM-960Installer
Installation of crankshaft sealing ring in timing case
KM-2358Wire ropes
Suspending the engine
KM-6009Installation and removal tool
Installation, removal of the ignition module
KM-6054Holding the engine
Installation and removal of the engine with transmission using KM-904 and KM-6056
KM-6056Engine bracket
Holding the engine when removing and installing the engine with transmission using KM-6054
KM-6103-AEngine bracket
Holding the engine when removing and installing the cylinder head and working on the engine timing side
KM-6129Installation and removal tool
Installation and removal of oxygen sensors with MKM-611
KM-6130Fixing pin
Fixing Ribbed V-Belt Tensioner (only for air conditioning)
KM-6131Assembly wrench
Tensioning ribbed V-belt tensioner
KM-6132Adapter
Testing the cooling system for leaks with KM-471 and filling the cooling system
KM-6136Installer
Hammering the driveshaft guide bearing into the flywheel
KM-6137Remover
Removing the driveshaft guide bearing from the flywheel with KM-328-B
