Symptom Troubleshooting - Automatic Transaxle [FW6A-EL]: Other Mazda 3 BM

Automatic Trans 2 illustrations ~350 words

FOREWORD [FW6A-EL]

If there is any vehicle malfunction complaint lodged by a customer, perform malfunction diagnosis according to the troubleshooting procedure.

Automatic Transaxle Control System Troubleshooting Procedure Flow Chart. Scheme 1768

Scheme 1768: Automatic Transaxle Control System Troubleshooting Procedure Flow Chart

Action for Non-repeatable Malfunction

If the malfunction does not recur, verify the malfunction cause by performing the following actions: Verify that no DTCs are stored. (See «ON-BOARD DIAGNOSTIC SYSTEM DTC INSPECTION [FW6A-EL]»(ref-579376-S25255133932013100700000) .) Based on the repair order form, attempt to drive the vehicle or perform tests to replicate the malfunction, record the data at that time, and detect the malfunction cause.
If the malfunction does not recur after the above servicing, explain to the customer that the vehicle is normal.

VEHICLE DOES NOT MOVE IN D, M OR R POSITION [FW6A-EL]

TROUBLESHOOTING ITEM	Vehicle does not move in D, M or R position
DESCRIPTION	Vehicle does not move when accelerator pedal is depressed. The engine revs up but the vehicle does not move even though the accelerator pedal is depressed. Tires are locked and do not move even though the accelerator pedal is depressed.
POSSIBLE CAUSE	Improper operation of parking mechanism Poor GND Manual shaft (manual valve) stuck Torque converter malfunction

Rotating Manual Shaft. Scheme 1769

Scheme 1769: Rotating Manual Shaft

VEHICLE MOVES IN P POSITION, OR PARKING GEAR DOES NOT DISENGAGE WHEN P IS DISENGAGED [FW6A-EL]

TROUBLESHOOTING ITEM	Vehicle moves in P position, or parking gear does not disengage when P is disengaged
DESCRIPTION	Vehicle rolls when on a downward slope in P position. Vehicle does not move in D, M and R position when accelerator pedal is depressed, and engine remains in stalled condition.
POSSIBLE CAUSE	Parking mechanism malfunction

EXCESSIVE CREEP [FW6A-EL]

TROUBLESHOOTING ITEM	Excessive creep
DESCRIPTION	Vehicle accelerates in D and R position when accelerator pedal is not depressed.
POSSIBLE CAUSE	Not within idle speed specification

NO CREEP AT ALL [FW6A-EL]

TROUBLESHOOTING ITEM	No creep at all
DESCRIPTION	Vehicle does not move in D, M or R position when idling on flat paved road.
POSSIBLE CAUSE	Not within idle speed specification

LOW MAXIMUM SPEED AND POOR ACCELERATION [FW6A-EL]

TROUBLESHOOTING ITEM	Low maximum speed and poor acceleration
DESCRIPTION	Vehicle acceleration is poor at start. Delayed acceleration when accelerator pedal is depressed while driving.
POSSIBLE CAUSE	Engine control system malfunction Signal malfunction APP sensor malfunction CKP sensor malfunction MAF sensor malfunction Poor GND Torque converter malfunction

CAUTION

Verify the malfunction symptom according to not only the PID value but also the symptom troubleshooting.

Related PIDs

Monitor item (Definition)	Unit/Condition	Condition/Specification (Reference)
APP	%	Accelerator pedal released: approx. 0 % Accelerator pedal depressed: approx. 100 %
MAF	G/sec	Displays the MAF
MAF	V	Switch the ignition to ON (MAF: 0.59 g/s {0.078 lb/min} ): approx. 0.72 V Idle (after warm up) (MAF: 2.17 g/s {0.287 lb/min} ): approx. 0.86 V Racing (engine speed is 2,000 rpm ) (MAF: 4.73 g/s {0.626 lb/min} ): approx. 1.07 V
RPM	RPM	Displays the engine speed

NO SHIFTING [FW6A-EL]

TROUBLESHOOTING ITEM	No shifting
DESCRIPTION	Single shift position only. Sometimes shifts correctly.
POSSIBLE CAUSE	Signal malfunction APP sensor malfunction BARO sensor malfunction Brake switch malfunction CKP sensor malfunction IAT sensor No.1 malfunction MAF sensor malfunction Poor GND Low-G (XY) sensor (built into SAS control module) malfunction NOTE: If a tire of a different diameter from the standard tire is installed, the TCM determines that the driving mode is the AAS mode, and may change to a different shift timing from the normal timing.

TROUBLESHOOTING ITEM

No shifting

DESCRIPTION

Single shift position only. Sometimes shifts correctly.

POSSIBLE CAUSE

Signal malfunction APP sensor malfunction BARO sensor malfunction Brake switch malfunction CKP sensor malfunction IAT sensor No.1 malfunction MAF sensor malfunction Poor GND Low-G (XY) sensor (built into SAS control module) malfunction NOTE: If a tire of a different diameter from the standard tire is installed, the TCM determines that the driving mode is the AAS mode, and may change to a different shift timing from the normal timing.

NOTE
If a tire of a different diameter from the standard tire is installed, the TCM determines that the driving mode is the AAS mode, and may change to a different shift timing from the normal timing.

CAUTION

Verify the malfunction symptom according to not only the PID value but also the symptom troubleshooting.

Related PIDs

Monitor item (Definition)	Unit/Condition	Condition/Specification (Reference)
APP	%	Accelerator pedal released: approx. 0 % Accelerator pedal depressed: approx. 100 %
BARO	KPa {MPa}, mBar {Bar}, psi, in H20	Displays the BARO
BARO	V	Switch the ignition to ON (at sea level): approx. 4.08 V
BOO	OFF/ON	Brake pedal released: Off Brake pedal depressed: On
IAT	°C, °F	Displays the IAT (No.1)
IAT	V	IAT is 20 °C {68 °F}: approx. 2.70 V IAT is 40 °C {104 °F}: approx. 1.80 V IAT is 60 °C {140 °F}: approx. 1.20 V
MAF	G/sec	Displays the MAF
MAF	V	Switch the ignition to ON (MAF: 0.59 g/s {0.078 lb/min} ): approx. 0.72 V Idle (after warm up) (MAF: 2.17 g/s {0.287 lb/min} ): approx. 0.86 V Racing (engine speed is 2,000 rpm ) (MAF: 4.73 g/s {0.626 lb/min} ): approx. 1.07 V
RPM	RPM	Displays the engine speed

DOES NOT SHIFT TO 5GR OR 6GR [FW6A-EL]

TROUBLESHOOTING ITEM	Does not shift to 5GR or 6GR
DESCRIPTION	Vehicle does not upshift from 4GR to 5GR or 5GR to 6GR even though vehicle speed is increased. Vehicle does not shift to 5GR or 6GR even though accelerator pedal is released in D position at 60 km/h {37 mph} (5GR) or 80 km/h {50 mph} (6GR).
POSSIBLE CAUSE	Signal malfunction APP sensor malfunction BARO sensor malfunction CKP sensor malfunction IAT sensor No.1 malfunction MAF sensor malfunction Poor GND Low-G (XY) sensor (built into SAS control module) malfunction NOTE: If a tire of a different diameter from the standard tire is installed, the TCM determines that the driving mode is the AAS mode, and may change to a different shift timing from the normal timing.

TROUBLESHOOTING ITEM

Does not shift to 5GR or 6GR

DESCRIPTION

Vehicle does not upshift from 4GR to 5GR or 5GR to 6GR even though vehicle speed is increased. Vehicle does not shift to 5GR or 6GR even though accelerator pedal is released in D position at 60 km/h {37 mph} (5GR) or 80 km/h {50 mph} (6GR).

POSSIBLE CAUSE

Signal malfunction APP sensor malfunction BARO sensor malfunction CKP sensor malfunction IAT sensor No.1 malfunction MAF sensor malfunction Poor GND Low-G (XY) sensor (built into SAS control module) malfunction NOTE: If a tire of a different diameter from the standard tire is installed, the TCM determines that the driving mode is the AAS mode, and may change to a different shift timing from the normal timing.

NOTE
If a tire of a different diameter from the standard tire is installed, the TCM determines that the driving mode is the AAS mode, and may change to a different shift timing from the normal timing.

CAUTION

Verify the malfunction symptom according to not only the PID value but also the symptom troubleshooting.

Related PIDs

Monitor item (Definition)	Unit/Condition	Condition/Specification (Reference)
APP	%	Accelerator pedal released: approx. 0 % Accelerator pedal depressed: approx. 100 %
APP	V	Switch the ignition to ON (at sea level): approx. 4.08 V
IAT	°C, °F	Displays the IAT (No.1)
IAT	V	IAT is 20 °C {68 °F}: approx. 2.70 V IAT is 40 °C {104 °F}: approx. 1.80 V IAT is 60 °C {140 °F}: approx. 1.20 V
MAF	G/sec	Displays the MAF
MAF	V	Switch the ignition to ON (MAF: 0.59 g/s {0.078 lb/min} ): approx. 0.72 V Idle (after warm up) (MAF: 2.17 g/s {0.287 lb/min} ): approx. 0.86 V Racing (engine speed is 2,000 rpm ) (MAF: 4.73 g/s {0.626 lb/min} ): approx. 1.07 V
RPM	RPM	Displays the engine speed

ABNORMAL SHIFTING [FW6A-EL]

TROUBLESHOOTING ITEM	Abnormal shifting
DESCRIPTION	Shifts incorrectly (incorrect shift pattern).
POSSIBLE CAUSE	Signal malfunction APP sensor malfunction BARO sensor malfunction Brake switch malfunction CKP sensor malfunction ECT sensor No.1 malfunction IAT sensor No.1 malfunction MAF sensor malfunction Poor GND Low-G (XY) sensor (built into SAS control module) malfunction NOTE: If a tire of a different diameter from the standard tire is installed, the TCM determines that the driving mode is the AAS mode, and may change to a different shift timing from the normal timing.

TROUBLESHOOTING ITEM

Abnormal shifting

DESCRIPTION

Shifts incorrectly (incorrect shift pattern).

POSSIBLE CAUSE

Signal malfunction APP sensor malfunction BARO sensor malfunction Brake switch malfunction CKP sensor malfunction ECT sensor No.1 malfunction IAT sensor No.1 malfunction MAF sensor malfunction Poor GND Low-G (XY) sensor (built into SAS control module) malfunction NOTE: If a tire of a different diameter from the standard tire is installed, the TCM determines that the driving mode is the AAS mode, and may change to a different shift timing from the normal timing.

NOTE
If a tire of a different diameter from the standard tire is installed, the TCM determines that the driving mode is the AAS mode, and may change to a different shift timing from the normal timing.

CAUTION

Verify the malfunction symptom according to not only the PID value but also the symptom troubleshooting.

Related PIDs

Monitor item (Definition)	Unit/Condition	Condition/Specification (Reference)
APP	%	Accelerator pedal released: approx. 0 % Accelerator pedal depressed: approx. 100 %
BARO	KPa {MPa}, mBar {Bar}, psi, in H20	Displays the BARO
BARO	V	Switch the ignition to ON (at sea level): approx. 4.08 V
BOO	OFF/ON	Brake pedal released: Off Brake pedal depressed: On
ECT	°C, °F	Displays the ECT
ECT	V	ECT is 20 °C {68 °F}: approx. 3.10 V ECT is 40 °C {104 °F}: approx. 2.16 V ECT is 60 °C {140 °F}: approx. 1.40 V ECT is 80 °C {176 °F}: approx. 0.87 V ECT is 100 °C {212 °F}: approx. 0.54 V
IAT	°C, °F	Displays the IAT (No.1)
IAT	V	IAT is 20 °C {68 °F}: approx. 2.70 V IAT is 40 °C {104 °F}: approx. 1.80 V IAT is 60 °C {140 °F}: approx. 1.20 V
MAF	G/sec	Displays the MAF
MAF	V	Switch the ignition to ON (MAF: 0.59 g/s {0.078 lb/min} ): approx. 0.72 V Idle (after warm up) (MAF: 2.17 g/s {0.287 lb/min} ): approx. 0.86 V Racing (engine speed is 2,000 rpm ) (MAF: 4.73 g/s {0.626 lb/min} ): approx. 1.07 V
RPM	RPM	Displays the engine speed

FREQUENT SHIFTING [FW6A-EL]

TROUBLESHOOTING ITEM	Frequent shifting
DESCRIPTION	Downshifting occurs suddenly even when accelerator pedal is depressed slightly in D position.
POSSIBLE CAUSE	Signal malfunction APP sensor malfunction Poor GND Low-G (XY) sensor (built into SAS control module) malfunction

CAUTION

Verify the malfunction symptom according to not only the PID value but also the symptom troubleshooting.

Related PIDs

Monitor item (Definition)	Unit/Condition	Condition/Specification (Reference)
APP	%	Accelerator pedal released: approx. 0 % Accelerator pedal depressed: approx. 100 %

SHIFT POINT IS HIGH OR LOW [FW6A-EL]

TROUBLESHOOTING ITEM	Shift point is high or low
DESCRIPTION	Shift point considerably different from automatic shift diagram. Shift delays when accelerating. Shift occurs suddenly when accelerating and engine speed does not increase.
POSSIBLE CAUSE	Signal malfunction APP sensor malfunction BARO sensor malfunction Brake switch malfunction ECT sensor No.1 malfunction IAT sensor No.1 malfunction Poor GND Low-G (XY) sensor (built into SAS control module) malfunction NOTE: If a tire of a different diameter from the standard tire is installed, the TCM determines that the driving mode is the AAS mode, and may change to a different shift timing from the normal timing.

TROUBLESHOOTING ITEM

Shift point is high or low

DESCRIPTION

Shift point considerably different from automatic shift diagram. Shift delays when accelerating. Shift occurs suddenly when accelerating and engine speed does not increase.

POSSIBLE CAUSE

Signal malfunction APP sensor malfunction BARO sensor malfunction Brake switch malfunction ECT sensor No.1 malfunction IAT sensor No.1 malfunction Poor GND Low-G (XY) sensor (built into SAS control module) malfunction NOTE: If a tire of a different diameter from the standard tire is installed, the TCM determines that the driving mode is the AAS mode, and may change to a different shift timing from the normal timing.

NOTE
If a tire of a different diameter from the standard tire is installed, the TCM determines that the driving mode is the AAS mode, and may change to a different shift timing from the normal timing.

CAUTION

Verify the malfunction symptom according to not only the PID value but also the symptom troubleshooting.

Related PIDs

Monitor item (Definition)	Unit/Condition	Condition/Specification (Reference)
APP	%	Accelerator pedal released: approx. 0 % Accelerator pedal depressed: approx. 100 %
BARO	KPa {MPa}, mBar {Bar}, psi, in H20	Displays the BARO
BARO	V	Switch the ignition to ON (at sea level): approx. 4.08 V
BOO	OFF/ON	Brake pedal released: Off Brake pedal depressed: On
ECT	°C, °F	Displays the ECT
ECT	V	ECT is 20 °C {68 °F}: approx. 3.10 V ECT is 40 °C {104 °F}: approx. 2.16 V ECT is 60 °C {140 °F}: approx. 1.40 V ECT is 80 °C {176 °F}: approx. 0.87 V ECT is 100 °C {212 °F}: approx. 0.54 V
IAT	°C, °F	Displays the IAT (No.1)
IAT	V	IAT is 20 °C {68 °F}: approx. 2.70 V IAT is 40 °C {104 °F}: approx. 1.80 V IAT is 60 °C {140 °F}: approx. 1.20 V

NO KICKDOWN [FW6A-EL]

TROUBLESHOOTING ITEM	No kickdown
DESCRIPTION	Does not downshift when accelerator pedal is fully depressed within kickdown range.
POSSIBLE CAUSE	Signal malfunction APP sensor malfunction

CAUTION

Verify the malfunction symptom according to not only the PID value but also the symptom troubleshooting.

Related PIDs

Monitor item (Definition)	Unit/Condition	Condition/Specification (Reference)
APP	%	Accelerator pedal released: approx. 0 % Accelerator pedal depressed: approx. 100 %

ENGINE FLARES UP OR SLIPS WHEN UPSHIFTING OR DOWNSHIFTING [FW6A-EL]

TROUBLESHOOTING ITEM	Engine flares up or slips when upshifting or downshifting
DESCRIPTION	When accelerator pedal is depressed, engine speed increases normally but vehicle speed increases slowly. When accelerator pedal is depressed while driving, engine speed increases but vehicle speed does not.
POSSIBLE CAUSE	Signal malfunction APP sensor malfunction CKP sensor malfunction MAF sensor malfunction Poor GND

CAUTION

Verify the malfunction symptom according to not only the PID value but also the symptom troubleshooting.

Related PIDs

Monitor item (Definition)	Unit/Condition	Condition/Specification (Reference)
APP	%	Accelerator pedal released: approx. 0 % Accelerator pedal depressed: approx. 100 %
MAF	G/sec	Displays the MAF
MAF	V	Switch the ignition to ON (MAF: 0.59 g/s {0.078 lb/min} ): approx. 0.72 V Idle (after warm up) (MAF: 2.17 g/s {0.287 lb/min} ): approx. 0.86 V Racing (engine speed is 2,000 rpm ) (MAF: 4.73 g/s {0.626 lb/min} ): approx. 1.07 V
RPM	RPM	Displays the engine speed

ENGINE FLARES UP OR SLIPS WHEN ACCELERATING VEHICLE [FW6A-EL]

TROUBLESHOOTING ITEM	Engine flares up or slips when accelerating vehicle
DESCRIPTION	Engine flares up when accelerator pedal is depressed for upshifting. Engine flares up suddenly when accelerator pedal is depressed for downshifting.
POSSIBLE CAUSE	Signal malfunction APP sensor malfunction Poor GND

CAUTION

Verify the malfunction symptom according to not only the PID value but also the symptom troubleshooting.

Related PIDs

Monitor item (Definition)	Unit/Condition	Condition/Specification (Reference)
APP	%	Accelerator pedal released: approx. 0 % Accelerator pedal depressed: approx. 100 %

EXCESSIVE SHIFT SHOCK FROM N TO D OR N TO R POSITION [FW6A-EL]

TROUBLESHOOTING ITEM	Excessive shift shock from N to D or N to R position
DESCRIPTION	Strong shock is felt when shifting from N to D or N to R position at idle.
POSSIBLE CAUSE	Not within idle speed specification Signal malfunction APP sensor malfunction CKP sensor malfunction Poor GND Poor installation or worn of engine mount, suspension

CAUTION

Verify the malfunction symptom according to not only the PID value but also the symptom troubleshooting.

Related PIDs

Monitor item (Definition)	Unit/Condition	Condition/Specification (Reference)
APP	%	Accelerator pedal released: approx. 0 % Accelerator pedal depressed: approx. 100 %
RPM	RPM	Displays the engine speed

EXCESSIVE SHIFT SHOCK IS FELT WHEN UPSHIFTING AND DOWNSHIFTING [FW6A-EL]

TROUBLESHOOTING ITEM	Excessive shift shock is felt when upshifting and downshifting
DESCRIPTION	Excessive shift shock is felt when depressing accelerator pedal to accelerate at upshifting. During cruising, excessive shift shock is felt when depressing accelerator pedal at downshifting.
POSSIBLE CAUSE	Signal malfunction APP sensor malfunction Poor GND Poor installation or worn of engine mount, suspension

CAUTION

Verify the malfunction symptom according to not only the PID value but also the symptom troubleshooting.

Related PIDs

Monitor item (Definition)	Unit/Condition	Condition/Specification (Reference)
APP	%	Accelerator pedal released: approx. 0 % Accelerator pedal depressed: approx. 100 %

NO ENGINE BRAKING IN 1GR POSITION OF M POSITION [FW6A-EL]

TROUBLESHOOTING ITEM	No engine braking in 1GR position of M position
DESCRIPTION	Engine speed drops to idle but vehicle coasts when accelerator pedal is released when in M position (1GR) at low vehicle speed.
POSSIBLE CAUSE	Poor GND

TRANSAXLE OVERHEATS [FW6A-EL]

TROUBLESHOOTING ITEM	Transaxle overheats
DESCRIPTION	Burnt smell emitted from the transaxle. Smoke is emitted from the transaxle.
POSSIBLE CAUSE	Signal malfunction APP sensor malfunction Brake switch malfunction CKP sensor malfunction ECT sensor No.1 malfunction ATF malfunction Oil cooler malfunction Control valve body malfunction

CAUTION

Verify the malfunction symptom according to not only the PID value but also the symptom troubleshooting.

Related PCM PIDs

Monitor item (Definition)	Unit/Condition	Condition/Specification (Reference)
APP	%	Accelerator pedal released: approx. 0 % Accelerator pedal depressed: approx. 100 %
BOO	OFF/ON	Brake pedal released: Off Brake pedal depressed: On
ECT	°C, °F	Displays the ECT
ECT	V	ECT is 20 °C {68 °F}: approx. 3.10 V ECT is 40 °C {104 °F}: approx. 2.16 V ECT is 60 °C {140 °F}: approx. 1.40 V ECT is 80 °C {176 °F}: approx. 0.87 V ECT is 100 °C {212 °F}: approx. 0.54 V
RPM	RPM	Displays the engine speed

Related TCM PIDs

Item	Unit/Condition	Test condition	Specification (Reference)
ECU_A	°C {°F}	Displays the ECU internal temperature A.
ECU_B	°C {°F}	Displays the ECU internal temperature B.
ECU_C	°C {°F}	Displays the ECU internal temperature C.
GEAR_SEL	1/2/3/4/5/6	Selector lever in 1GR at D position	1
		Selector lever in 2GR at D position	2
		Selector lever in 3GR at D position	3
		Selector lever in 4GR at D position	4
		Selector lever in 5GR at D position	5
		Selector lever in 6GR at D position	6
LINEDES	KPa {kgf/cm 2 , psi}	Idle at P position after warm-up	Approx. 500 kPa {5.10 kgf/cm 2 , 72.5 psi}
OP_SW1	Off/On	Selector lever at P position	Off
		Selector lever at R position	Off
		Selector lever at N position	Off
		Selector lever in 1GR at D position	On
		Selector lever in 2GR at D position	On
		Selector lever in 3GR at D position	On
		Selector lever in 4GR at D position	On
		Selector lever in 5GR at D position	Off
		Selector lever in 6GR at D position	Off
OP_SW2	Off/On	Selector lever at P position	Off
		Selector lever at R position	Off
		Selector lever at N position	Off
		Selector lever in 1GR at D position	Off
		Selector lever in 2GR at D position	On
		Selector lever in 3GR at D position	Off
		Selector lever in 4GR at D position	Off
		Selector lever in 5GR at D position	Off
		Selector lever in 6GR at D position	On
OP_SW3	Off/On	Selector lever at P position	Off
		Selector lever at R position	On
		Selector lever at N position	Off
		Selector lever in 1GR at D position	Off
		Selector lever in 2GR at D position	Off
		Selector lever in 3GR at D position	On
		Selector lever in 4GR at D position	Off
		Selector lever in 5GR at D position	On
		Selector lever in 6GR at D position	Off
OP_SW4	Off/On	Selector lever at P position	Off
		Selector lever at R position	Off
		Selector lever at N position	Off
		Selector lever in 1GR at D position	Off
		Selector lever in 2GR at D position	Off
		Selector lever in 3GR at D position	Off
		Selector lever in 4GR at D position	On
		Selector lever in 5GR at D position	On
		Selector lever in 6GR at D position	On
OSS	RPM	Vehicle stopped	0 RPM
OSS	RPM	Vehicle speed 30 km/h {19 mph} in 3GR at D position	Approx. 940 RPM
SS1	A	Vehicle stopped at P position	Approx. 0 A
		Vehicle stopped at R position	Approx. 0 A
		Vehicle stopped at N position	Approx. 0 A
		Driving in D position 1GR	Approx. 1 A
		Driving in D position 2GR	Approx. 1 A
		Driving in D position 3GR	Approx. 1 A
		Driving in D position 4GR	Approx. 1 A
		Driving in D position 5GR	Approx. 0 A
		Driving in D position 6GR	Approx. 0 A
SS2	A	Vehicle stopped at P position	Approx. 0 A
		Vehicle stopped at R position	Approx. 0 A
		Vehicle stopped at N position	Approx. 0 A
		Driving in D position 1GR	Approx. 0 A
		Driving in D position 2GR	Approx. 1 A
		Driving in D position 3GR	Approx. 0 A
		Driving in D position 4GR	Approx. 0 A
		Driving in D position 5GR	Approx. 0 A
		Driving in D position 6GR	Approx. 1 A
SS3	A	Vehicle stopped at P position	Approx. 1 A
		Vehicle stopped at R position	Approx. 0 A
		Vehicle stopped at N position	Approx. 1 A
		Driving in D position 1GR	Approx. 1 A
		Driving in D position 2GR	Approx. 1 A
		Driving in D position 3GR	Approx. 0 A
		Driving in D position 4GR	Approx. 1 A
		Driving in D position 5GR	Approx. 0 A
		Driving in D position 6GR	Approx. 1 A
SS4	A	Vehicle stopped at P position	Approx. 0 A
		Vehicle stopped at R position	Approx. 0 A
		Vehicle stopped at N position	Approx. 0 A
		Driving in D position 1GR	Approx. 0 A
		Driving in D position 2GR	Approx. 1 A
		Driving in D position 3GR	Approx. 1 A
		Driving in D position 4GR	Approx. 0 A
		Driving in D position 5GR	Approx. 0 A
		Driving in D position 6GR	Approx. 0 A
SSLU	A	Vehicle stopped at P position	Approx. 0 A
		Vehicle stopped at R position	Approx. 0 A
		Vehicle stopped at N position	Approx. 0 A
		Under the following conditions: Driving in D position 1GR Accelerator pedal opening angle is approx. 10 %	Approx. 430 mA
		Under the following conditions: Driving in D position 2GR Accelerator pedal opening angle is approx. 10 %	Approx. 430 mA
		Under the following conditions: Driving in D position 3GR Accelerator pedal opening angle is approx. 10 %	Approx. 430 mA
		Under the following conditions: Driving in D position 4GR Accelerator pedal opening angle is approx. 10 %	Approx. 430 mA
		Under the following conditions: Driving in D position 5GR Accelerator pedal opening angle is approx. 10 %	Approx. 430 mA
		Under the following conditions: Driving in D position 6GR Accelerator pedal opening angle is approx. 10 %	Approx. 430 mA
SSLU_PRES	KPa {kgf/cm 2 , psi}	Vehicle stopped at P position	0 kPa {0 kgf/cm 2 , 0 psi}
		Vehicle stopped at R position	0 kPa {0 kgf/cm 2 , 0 psi}
		Vehicle stopped at N position	0 kPa {0 kgf/cm 2 , 0 psi}
		Under the following conditions: Driving in D position 1GR Accelerator pedal opening angle is approx. 10 %	Approx. 360 kPa {3.67 kgf/cm 2 , 52.2 psi}
		Under the following conditions: Driving in D position 2GR Accelerator pedal opening angle is approx. 10 %	Approx. 360 kPa {3.67 kgf/cm 2 , 52.2 psi}
		Under the following conditions: Driving in D position 3GR Accelerator pedal opening angle is approx. 10 %	Approx. 360 kPa {3.67 kgf/cm 2 , 52.2 psi}
		Under the following conditions: Driving in D position 4GR Accelerator pedal opening angle is approx. 10 %	Approx. 360 kPa {3.67 kgf/cm 2 , 52.2 psi}
		Under the following conditions: Driving in D position 5GR Accelerator pedal opening angle is approx. 10 %	Approx. 360 kPa {3.67 kgf/cm 2 , 52.2 psi}
		Under the following conditions: Driving in D position 6GR Accelerator pedal opening angle is approx. 10 %	Approx. 360 kPa {3.67 kgf/cm 2 , 52.2 psi}
SSP	A	Vehicle stopped at P position	Approx. 980 mA
		Vehicle stopped at R position	Approx. 930 mA
		Vehicle stopped at N position	Approx. 980 mA
		Under the following conditions: Driving in D position 1GR Accelerator pedal opening angle is approx. 10 %	Approx. 400-800 mA
		Under the following conditions: Driving in D position 2GR Accelerator pedal opening angle is approx. 10 %	Approx. 400-800 mA
		Under the following conditions: Driving in D position 3GR Accelerator pedal opening angle is approx. 10 %	Approx. 400-800 mA
		Under the following conditions: Driving in D position 4GR Accelerator pedal opening angle is approx. 10 %	Approx. 400-800 mA
		Under the following conditions: Driving in D position 5GR Accelerator pedal opening angle is approx. 10 %	Approx. 400-800 mA
		Under the following conditions: Driving in D position 6GR Accelerator pedal opening angle is approx. 10 %	Approx. 400-800 mA
SSP_PRES	KPa {kgf/cm 2 , psi}	Vehicle stopped at P position	Approx. 45 kPa {0.46 kgf/cm 2 , 6.5 psi}
		Vehicle stopped at R position	Approx. 80 kPa {0.82 kgf/cm 2 , 12 psi}
		Vehicle stopped at N position	Approx. 45 kPa {0.46 kgf/cm 2 , 6.5 psi}
		Under the following conditions: Driving in D position 1GR Accelerator pedal opening angle is approx. 10 %	130-460 kPa {1.33-4.69 kgf/cm 2 , 18.9-66.7 psi}
		Under the following conditions: Driving in D position 2GR Accelerator pedal opening angle is approx. 10 %	130-460 kPa {1.33-4.69 kgf/cm 2 , 18.9-66.7 psi}
		Under the following conditions: Driving in D position 3GR Accelerator pedal opening angle is approx. 10 %	130-460 kPa {1.33-4.69 kgf/cm 2 , 18.9-66.7 psi}
		Under the following conditions: Driving in D position 4GR Accelerator pedal opening angle is approx. 10 %	130-460 kPa {1.33-4.69 kgf/cm 2 , 18.9-66.7 psi}
		Under the following conditions: Driving in D position 5GR Accelerator pedal opening angle is approx. 10 %	130-460 kPa {1.33-4.69 kgf/cm 2 , 18.9-66.7 psi}
		Under the following conditions: Driving in D position 6GR Accelerator pedal opening angle is approx. 10 %	130-460 kPa {1.33-4.69 kgf/cm 2 , 18.9-66.7 psi}
TR	P/SHIFT_DOWN/SHIFT_UP/M/D/N/R	Selector lever at P position	P
		Selector lever at M position (-) side position	SHIFT_DOWN
		Selector lever at M position (+) side position	SHIFT_UP
		Selector lever at M position	M
		Selector lever at D position	D
		Selector lever at N position	N
		Selector lever at R position	R
TSS	RPM	Vehicle stopped at D position	0 RPM
TSS	RPM	Engine speed 1,000 rpm at P position	900-1,100 RPM
VSS	KPH {MPH}	Displays the vehicle speed.

ENGINE STALLS WHEN SHIFTED TO D, M OR R POSITION [FW6A-EL]

TROUBLESHOOTING ITEM	Engine stalls when shifted to D, M or R position
DESCRIPTION	Engine stalls when shifting from N or P position to D, M or R position at idle.
POSSIBLE CAUSE	Not within idle speed specification Torque converter malfunction

ENGINE STALLS WHEN DRIVING AT SLOW SPEEDS OR STOPPING [FW6A-EL]

TROUBLESHOOTING ITEM	Engine stalls when driving at slow speeds or stopping
DESCRIPTION	Engine stalls when brake pedal is depressed while driving at low speed or stopping.
POSSIBLE CAUSE	Not within idle speed specification Engine control system malfunction Torque converter malfunction

STARTER DOES NOT WORK [FW6A-EL]

TROUBLESHOOTING ITEM	Starter does not work
DESCRIPTION	Starter does not work even when in P or N position.
POSSIBLE CAUSE	Wiring harness between TCM terminal 1J and PCM terminal 1C malfunction Immobilizer system operating or system malfunction Engine control system malfunction

GEAR POSITION INDICATOR LIGHT DOES NOT ILLUMINATE IN M POSITION [FW6A-EL]

TROUBLESHOOTING ITEM	Gear position indicator light does not illuminate in M position
DESCRIPTION	Gear position indicator light in instrument cluster does not illuminate in M position with the ignition is ON.
POSSIBLE CAUSE	Instrument cluster malfunction ATF temperature is 132 °C {270 °F} or more . (Gear fixing is inhibited, transaxle switches to auto shift control.)

GEAR POSITION INDICATOR LIGHT ILLUMINATES IN P, R, N AND D POSITIONS [FW6A-EL]

TROUBLESHOOTING ITEM	Gear position indicator light illuminates in P, R, N and D positions
DESCRIPTION	Gear position indicator light in instrument cluster illuminates in P, R, N and D positions with the ignition is ON.
POSSIBLE CAUSE	Instrument cluster malfunction

M POSITION INDICATOR LIGHT DOES NOT ILLUMINATE IN M POSITION/M POSITION INDICATOR LIGHT ILLUMINATES IN D POSITION [FW6A-EL]

TROUBLESHOOTING ITEM	M position indicator light does not illuminate in M position/M position indicator light illuminates in D position
DESCRIPTION	M position indicator light in instrument cluster does not illuminate in M position or M position indicator light in instrument cluster in P, R, N and D positions with the ignition is ON.
POSSIBLE CAUSE	Instrument cluster malfunction

TROUBLESHOOTING ITEM	M position indicator light does not illuminate in M position/M position indicator light illuminates in D position
DESCRIPTION	M position indicator light in instrument cluster does not illuminate in M position or M position indicator light in instrument cluster in P, R, N and D positions with the ignition is ON.
POSSIBLE CAUSE	Instrument cluster malfunction

ATF SEEPING INTO AUTOMATIC TRANSAXLE [FW6A-EL]

TROUBLESHOOTING ITEM

ATF seeping into automatic transaxle

DESCRIPTION

ATF is seeping into the automatic transaxle case. Foreign matter mixed with ATF is in the automatic transaxle case.

POSSIBLE CAUSE

NOTE: ATF seeping radiates from ATF leak source. Identify the type of seeping oil referring to "SERVICE CAUTIONS, Oil Leakage Inspection" in the general information. (See SERVICE CAUTIONS .) To prevent misdiagnosis, remove any grease or dirt from the seep location and verify the location of the seeping after driving the vehicle. Sealing deterioration and damage Incorrect installation of ATX external part

NOTE
ATF seeping radiates from ATF leak source. Identify the type of seeping oil referring to "SERVICE CAUTIONS, Oil Leakage Inspection" in the general information. (See SERVICE CAUTIONS .) To prevent misdiagnosis, remove any grease or dirt from the seep location and verify the location of the seeping after driving the vehicle.

Symptom Troubleshooting - Automatic Transaxle [FW6A-EL]: Other Mazda 3 BM

FOREWORD [FW6A-EL]

Automatic Transaxle Control System Troubleshooting Procedure Flow Chart. Scheme 1768

Action for Non-repeatable Malfunction

VEHICLE DOES NOT MOVE IN D, M OR R POSITION [FW6A-EL]

Rotating Manual Shaft. Scheme 1769

VEHICLE MOVES IN P POSITION, OR PARKING GEAR DOES NOT DISENGAGE WHEN P IS DISENGAGED [FW6A-EL]

EXCESSIVE CREEP [FW6A-EL]

NO CREEP AT ALL [FW6A-EL]

LOW MAXIMUM SPEED AND POOR ACCELERATION [FW6A-EL]

NO SHIFTING [FW6A-EL]

DOES NOT SHIFT TO 5GR OR 6GR [FW6A-EL]

ABNORMAL SHIFTING [FW6A-EL]

FREQUENT SHIFTING [FW6A-EL]

SHIFT POINT IS HIGH OR LOW [FW6A-EL]

NO KICKDOWN [FW6A-EL]

ENGINE FLARES UP OR SLIPS WHEN UPSHIFTING OR DOWNSHIFTING [FW6A-EL]

ENGINE FLARES UP OR SLIPS WHEN ACCELERATING VEHICLE [FW6A-EL]

EXCESSIVE SHIFT SHOCK FROM N TO D OR N TO R POSITION [FW6A-EL]

EXCESSIVE SHIFT SHOCK IS FELT WHEN UPSHIFTING AND DOWNSHIFTING [FW6A-EL]

NO ENGINE BRAKING IN 1GR POSITION OF M POSITION [FW6A-EL]

TRANSAXLE OVERHEATS [FW6A-EL]

ENGINE STALLS WHEN SHIFTED TO D, M OR R POSITION [FW6A-EL]

ENGINE STALLS WHEN DRIVING AT SLOW SPEEDS OR STOPPING [FW6A-EL]

STARTER DOES NOT WORK [FW6A-EL]

GEAR POSITION INDICATOR LIGHT DOES NOT ILLUMINATE IN M POSITION [FW6A-EL]

GEAR POSITION INDICATOR LIGHT ILLUMINATES IN P, R, N AND D POSITIONS [FW6A-EL]

M POSITION INDICATOR LIGHT DOES NOT ILLUMINATE IN M POSITION/M POSITION INDICATOR LIGHT ILLUMINATES IN D POSITION [FW6A-EL]

ATF SEEPING INTO AUTOMATIC TRANSAXLE [FW6A-EL]

More articles — Symptom Troubleshooting - Automatic Transaxle [FW6A-EL]

Login / Signup

Enter the code

You have successfully logged in!
