Automatic Transaxle Shift Mechanism: Overview Mazda 3 BM

Identifying Selector Cable, Lever Component And Lock. Scheme 1405

Scheme 1406

1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal. (Scheme 1406): Identifying Upper, Shift And Indicator Panels, Selector Lever And Cable With Torque Specifications

Scheme 1407

Scheme 1408

Scheme 1409

1. Remove the shift panel and indicator panel as a single unit. Release the hooks securing the shift panel and console, and then release the hooks securing the shift panel and ashtray panel. (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-579335-S24715706362013100700000).) Lift up the shift panel and indicator panel and disconnect the bulb socket from the indicator panel. (Scheme 1407): Disconnecting Bulb Socket From Indicator Panel Remove the shift panel and indicator panel from the selector lever as a single unit. (Scheme 1408): Identifying Shift Panel And Indicator Panel Of Selector Lever
2. Detach the hooks as shown in the figure and remove the indicator panel from the shift panel. (Scheme 1409): Identifying Hooks On Indicator Panel

Scheme 1410

Scheme 1411

1. Align the locator pin with the hole in the floor as shown in the figure and install the selector lever. (Scheme 1410): Identifying Selector Lever, Locator Pins And Holes
2. Tighten the selector lever installation bolts. (Scheme 1411): Identifying Selector Lever Installation Bolt Tightening torque 8-10 N.m {82-101 kgf.cm, 71-88 in.lbf}

Scheme 1412

Scheme 1413

1. Install the selector cable end (selector lever side) as shown in the figure. (Scheme 1412): Locating Selector Cable End (Selector Lever Side)
2. Install the cable outer end (selector lever side) to the selector cable bracket as shown in the figure. (Scheme 1413): Identifying Cable Outer End (Selector Lever Side)
3. Adjust the selector cable. (See «SELECTOR CABLE ADJUSTMENT»(ref-579347-S04583127982013100700000).)

Scheme 1414

Scheme 1415

Scheme 1416

1. Install the shift panel to the indicator panel. (Scheme 1414): Identifying Shift And Indicator Panels
2. Install the shift panel and indicator panel to the selector lever as a single unit. (Scheme 1415): Identifying Shift And Indicator Panels On Selector Lever
3. Connect the bulb socket to the indicator panel. (Scheme 1416): Connecting Bulb Socket To Indicator Panel
4. Install the shift panel and indicator panel to the console and ashtray panel as a single unit. (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-579335-S24715706362013100700000) )

Scheme 1417

Scheme 1418

Scheme 1419

Scheme 1420

1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
3. Remove the battery component (ex: battery, battery tray and PCM component). (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
4. Remove the air cleaner component. (See «INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579361-S37454927402013100700000).) (See «INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579374-S36284440572013100700000).)
5. Remove the aerodynamic under cover NO.2. (See «AERODYNAMIC UNDER COVER NO.2 REMOVAL/INSTALLATION»(ref-579341-S33007366072013100700000).)
6. Remove the tunnel member (rear). (MZR 2.0, MZR 2.5) (See «EXHAUST SYSTEM REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579364-S32748916862013100700000).)
7. Remove the brace bar. (SKYACTIV-G 2.0) (See «EXHAUST SYSTEM REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579377-S33147343842013100700000).)
8. Remove the insulator (front) installation nuts and set the insulator (front) aside. (See «EXHAUST SYSTEM REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579364-S32748916862013100700000).) (See «EXHAUST SYSTEM REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579377-S33147343842013100700000).)
9. Remove the upper panel. (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S17519281862013100700000).)
10. Remove the knob. (See «SELECTOR LEVER REMOVAL/INSTALLATION»(ref-579347-S42882540242013100700000).)
11. Remove the shift panel and indicator panel as a single unit. Release the hooks securing the shift panel and console, and then release the hooks securing the shift panel and ashtray panel. (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-579335-S24715706362013100700000).) Lift up the shift panel and indicator panel and disconnect the bulb socket from the indicator panel. (Scheme 1417): Disconnecting/Connecting Bulb Socket From/To Indicator Panel Remove the shift panel and indicator panel from the selector lever as a single unit. (Scheme 1418): Identifying Shift And Indicator Panels On Selector Lever
12. Remove the console. (See «CONSOLE REMOVAL/INSTALLATION»(ref-579335-S16951481782013100700000).)
13. Disconnect the drain hose connected to A/C unit. (See «A/C UNIT REMOVAL/INSTALLATION»(ref-579378-S31323166662013100700000). (Scheme 1419): Identifying A/C Unit And Drain Hose
14. Remove in the order indicated in the table.
15. Install in reverse of removal. FS5A-EL (Scheme 1420): Exploded View Of Selector Cable With Torque Specifications

Scheme 1421

1. Remove the clip, and then disconnect the selector cable end from the manual shaft lever. (Scheme 1421): Identifying Selector Cable End, Manual Shaft Lever And Clip (FS5A-EL And FW6A-EL)

Scheme 1422

Scheme 1423

Scheme 1424

Scheme 1425

Scheme 1426

Scheme 1427

Scheme 1428

Scheme 1429

Scheme 1430

1. Install the grommet as shown in the figure. (Scheme 1422): Identifying Grommet And Mounting Nuts Tightening torque 4.0-9.8 N.m {41-99 kgf.cm, 36-86 in.lbf}
2. Install the selector cable end (selector lever side) as shown in the figure. (Scheme 1423): Locating Selector Cable End (Selector Lever Side)
3. Install the cable outer end (selector lever side) to the selector cable bracket as shown in the figure. (Scheme 1424): Identifying Cable Outer End (Selector Lever Side)
4. Install the clip as shown in the figure and tighten the nut. (Scheme 1425): Locating Position Of Clips And Nut (FS5A-EL) (Scheme 1426): Locating Position Of Clips And Nut (FW6A-EL) Tightening torque 19-25 N.m {2.0-2.5 kgf.m, 15-18 ft.lbf}
5. Install the selector cable end (transaxle side) and the cable outer end (transaxle side). CAUTION: When installing selector cable, make sure the boot is not twisted. Bending the selector cable in the manner shown in the figure will damage the cable and it may become loose when shifted. When installing the selector cable, hold it straight. (Scheme 1427): Caution - Do Not Bend Selector Cable Install the cable outer end (transaxle side) to the selector cable bracket as shown in the figure. (Scheme 1428): Identifying Cable Outer End (Transaxle Side) Install the clip to the selector cable end (transaxle side) as shown in the figure. (Scheme 1429): Identifying Clip On Selector Cable End (Transaxle Side) Install the selector cable end (transaxle side) to the manual shaft lever as shown in the figure. (Scheme 1430): Identifying Selector Cable End (Transaxle Side), Manual Shaft Lever And Clip (FS5A-EL And FW6A-EL)
6. Verify that the selector cable is securely installed.
7. Adjust the selector cable. (See «SELECTOR CABLE ADJUSTMENT»(ref-579347-S04583127982013100700000).)

Scheme 1431

Scheme 1432

Scheme 1433

1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
3. Remove the upper panel. (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S17519281862013100700000).)
4. Remove the knob. (See «SELECTOR LEVER REMOVAL/INSTALLATION»(ref-579347-S42882540242013100700000).)
5. Remove the shift panel and indicator panel as a single unit. Release the hooks securing the shift panel and console, and then release the hooks securing the shift panel and ashtray panel. (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-579335-S24715706362013100700000) ) Lift up the shift panel and indicator panel and disconnect the bulb socket from the indicator panel. (Scheme 1431): Disconnecting/Connecting Bulb Socket From/To Indicator Panel Remove the shift panel and indicator pane from the selector lever as a single unit. (Scheme 1432): Identifying Shift Panel And Indicator Panel Of Selector Lever
6. Remove the bulb from the bulb socket. (Scheme 1433): Identifying Bulb And Bulb Socket
7. Install in the reverse order of removal.

Scheme 1434

Scheme 1435

Scheme 1436

Scheme 1437

1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
3. Remove the upper panel. (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S17519281862013100700000).)
4. Remove the knob. (See «SELECTOR LEVER REMOVAL/INSTALLATION»(ref-579347-S42882540242013100700000).)
5. Remove the shift panel and indicator panel as a single unit. Release the hooks securing the shift panel and console, and then release the hooks securing the shift panel and ashtray panel. (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-579335-S24715706362013100700000).) Lift up the shift panel and indicator panel and disconnect the bulb socket from the indicator panel. (Scheme 1434): Disconnecting/Connecting Bulb Socket From/To Indicator Panel Remove the shift panel and indicator panel from the selector lever as a single unit. (Scheme 1435): Identifying Shift And Indicator Panels On Selector Lever
6. Shift the selector lever to the P position.
7. Unlock the lock piece of the selector cable end (selector lever side) in the order as shown in the figure. (Scheme 1436): Selector Cable End Unlocking Order (Selector Lever Side)
8. Verify that the manual shaft is in the P position.
9. Lock the lock piece and safety lock of the selector cable end (selector lever side) in the order as shown in the figure. (Scheme 1437): Selector Cable End Locking Order (Selector Lever Side)

Scheme 1438

1. Switch the ignition to ON.
2. Perform the following procedures to inspect the selector lever. If there is any malfunction, adjust the selector cable. (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000).) Verify that the selector lever can be operated as shown in the figure. (Scheme 1438): Selector Lever Operation Diagram Verify that the selector lever can be operated smoothly and moderately.

Shift-Lock System Inspection

1. Switch the ignition to ON.
2. Shift the selector lever to the P position.
3. Perform the following procedures to inspect the shift-lock system. If there is any malfunction, inspect the shift-lock solenoid and P position switch. (See «SHIFT-LOCK SOLENOID AND P POSITION SWITCH INSPECTION»(ref-579347-S12081010042013100700000) .) Verify that the selector lever cannot be shifted from P to R position when the brake pedal is released. Verify that the selector lever can be shifted from P to R position when the brake pedal is depressed.

Scheme 1439

Scheme 1440

1. Perform the following procedures. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).) Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).) Remove the console. (See «CONSOLE REMOVAL/INSTALLATION»(ref-579335-S16951481782013100700000).) Disconnect the selector lever component connector. (Scheme 1439): Identifying Selector Lever Component Connector
2. Measure the voltage between the selector lever component terminals. (Scheme 1440): Identifying Selector Lever Component Terminals If there is any malfunction, repair or replace the related wiring harness. If there is no malfunction even though the shift-lock system has any malfunction, replace the selector lever component. (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000).)
