Automatic Transaxle Shift Mechanism: Specifications Mazda 3 BM

Automatic Trans 1 illustration ~104 words

Shift-lock solenoid specification

TerminalsConnected toTest conditionVoltage (V)
E-GNDBrake switchBrake pedal releasedBelow 1.0
Brake pedal depressedB+
I-GNDIgnition switchSwitch the ignition to offBelow 1.0
Switch the ignition to ACC or ONB+
K-GNDGNDUnder any conditionBelow 1.0

Scheme 1404

Scheme 1404: Emergency Override Button Inspection
Scheme 1404: Emergency Override Button Inspection
  1. Switch the ignition to off.
  2. Verify that the selector lever is in the P position.
  3. Without the brake pedal depressed, verify that the selector lever cannot be shifted from the P position.
  4. Remove the cover using a tape-wrapped flathead screwdriver. (Scheme 1404): Removing Cover Using Tape-Wrapped Flathead Screwdriver
  5. Insert the flathead screwdriver into the emergency override hole and push it down.
  6. Verify that the selector lever can be shifted from the P position. If there is any malfunction, replace the selector lever component. (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000).)

NOT P Position Switch Specification

Test conditionContinuity
P positionNo continuity
Except P positionContinuity
