Specification
| Item | Brake Pedal Release | Brake Pedal Push |
|---|
| Switch 1 | Max. 0.5V | Battery Voltage |
| Switch 2 | IG OFF | Max. 50mV |
| IG ON | Battery Voltage | Max. 0.5V |
| Items | Specification |
|---|
| Gap [mm (in)] | 1.0 ~ 2.0 (0.039 ~ 0.079) |
Scheme 138
Scheme 138: Circuit Diagram
| Pressure [MPa (kgf/cm 2 , psi)] | Output Voltage (V) |
|---|
| 0 (0, 0) | 0.5 |
| 0.2 (2.04, 29.0) | 0.9 |
| 0.4 (4.08, 58.0) | 1.3 |
| 0.6 (6.12, 87.0) | 1.7 |
| 0.8 (8.16, 116.0) | 2.1 |
| 1.0 (10.20, 145.0) | 2.5 |
| 1.2 (12.24, 174.1) | 2.9 |
| 1.4 (14.28, 203.1) | 3.3 |
| 1.6 (16.32, 232.1) | 3.7 |
| 1.8 (18.35, 261.1) | 4.1 |
| 2.0 (20.39, 290.1) | 4.5 |
Scheme 139
Scheme 140
Scheme 140: Circuit Diagram
Scheme 141
Scheme 142
- Turn the ignition switch OFF and disconnect the auxiliary 12V battery negative (-) cable.
- Remove the under cover (Refer to " «ENGINE AND TRANSAXLE ASSEMBLY»(ref-535712-S00181035742013031200000) " in EM group).
- Disconnect the sensor connector (A).
- Remove the clutch pressure sensor (A).
Scheme 143
- Installation is reverse of removal. Clutch pressure sensor installation: 11 ~ 15 N.m (1.1 ~ 1.5 kgf.m, 8.0 ~ 11.1 lb-ft) NOTE: When installing, apply the ATF oil to the O-ring (A).
- Perform the clutch pressure sensor calibration (Refer to " «CLUTCH PRESSURE SENSOR CALIBRATION»(ref-535714-S18519388772013031200000) ".
Scheme 144
Scheme 145
- Connect the GDS to the Data Link Connector (DLC).
- Turn the ignition switch ON.
- Check the GDS service data of the sensor. EV Mode (Engine clutch not operating) Clutch Oil Pressure: approx. 0 HEV Mode (Engine clutch operating) Clutch Oil Pressure: above 0
