Hydrid Control System - Hev: Adjustments Kia Optima III

Adjustment

1. Refer to «ADJUSTMENT»(ref-535765-S19461521802013031200000) .

Clutch Pressure Sensor Calibration

Note. HCU need to be learnt the kissing point at both ends of the clutch to reduce shock while engine power is connected to the transaxle. So perform the Clutch Pressure Sensor Calibration after installing the CPS, HCU, engine or hybrid drive motor.

[Condition]

1. Hybrid Motor and HSG Resolver Calibration: "Completed" state
2. "READY" Lamp ON
3. "P" Range
4. Oil Temperature: 30 ~ 80°C (86 ~ 176°F)
5. SOC: 30 ~ 80%
6. No DTC

Scheme 151

Scheme 152

Scheme 153
