Charging System - 2.0L: Overview Kia Optima III

Charging System 2 illustrations ~192 words

Description

The charging system includes a battery, an alternator with a built-in regulator, and the charging indicator light and wire.

The Alternator has built-in diodes, each rectifying AC current to DC current.

Therefore, DC current appears at alternator "B" terminal.

In addition, the charging voltage of this alternator is regulated by the battery voltage detection system.

The main components of the alternator are the rotor, stator, rectifier, capacitor brushes, bearings and V-ribbed belt pulley.

The brush holder contains a built-in electronic voltage regulator.

Scheme 33

Scheme 33: Description

Vehicles have many control units that use more electricity. These units control their own system based on information from diverse sensors. It is important to have a stable power supply as there diverse sensors giving a variety of information. Battery sensor is mounted on battery (-) terminal. It transmits battery voltage, current, temperature information to ECM. ECM controls generating voltage by duty cycle based on these signals.

Scheme 34

Scheme 34: Description
CAUTIONWhen battery sensor signal fault occurs, inspect the vehicle parasitic draw in advance after inspecting the sensor because the sensor will behave abnormally when the parasitic draw is more than 100 mA. Refer to VEHICLE PARASITIC CURRENT INSPECTION .

Note. Perform the following process after replacing the battery sensor. Ignition switch ON/OFF. Park the vehicle about 4 hours. After 4 hours later, check the SOC (State of charge) of battery using GDS.

CAUTIONFor the vehicle equipped with a battery sensor, be careful not to damage the battery sensor when the battery is replaced or recharged. When replacing the battery, it should be same one (type, capacity and brand) that is originally installed on your vehicle. If a battery of a different type is replaced, the battery sensor may recognize the battery to be abnormal. When installing the ground cable on the negative post of battery, tighten the clamp with specified torque of 4.0~6.0 N.m (0.4~0.6kgf.m, 3.0~4.4 lb-ft). An excessive tightening torque can damage the PCB internal circuit and the battery terminal. When recharging the battery, ground the negative terminal of the booster battery to the vehicle body. If the negative cable from a battery charger is connected to the negative terminal of the battery, the battery sensor can make an error. In this case, repeat the above process for battery sensor replacement (1~3) after disconnecting and reconnecting the battery connector.
