Hev Control System Diagnosis - Hev: Specifications Kia Optima III

Specification

Scheme 440

Scheme 441

Scheme 442

1. Ignition ON (SSB LED "BLUE") & Vehicle "STOP".
2. Connect GDS and select "DTC Analysis" mode.
3. Click "DTC Status" on the menu bar to view DTC information.
4. Confirm that the "DTC Readiness Flag" indicates "COMPLETED". If not, drive the vehicle within conditions noted in Freeze Frame Data or Enable Conditions.
5. Read the "DTC Status" parameter.
6. Is parameter displayed "Present fault"? YES Go to Next procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or Control module's connector or was repaired and Control module's memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Monitoring with a DVOM on min/max or VMI while wiggling connectors may help find the problem. Any change in voltage indicate a possible problem. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535818-S03030375152013031200000) " procedure.

Non-compliance with the following instructions can induce death or injury caused by electric shock.

1. Carefully read and follow service manual instructions.
2. Wear insulated gloves, safety glasses and use insulated tools for your safety.
3. Turn the ignition switch off and Disconnect ground cable of auxiliary battery and Remove the safety plug.
4. Wait for more than 5 minutes so that the inverter capacitor can be naturally discharged.
5. Check high voltage terminal on Power Relay Assembly is lower than 30V.
6. Perform Resolver adaptation after the HPCU or the Driver Motor or the Generator(HSG) is replaced or reinstalled.
7. When replaced HPCU, Perform air bleeding for HPCU with GDS.

Scheme 443

Scheme 444

1. Ignition ON (SSB LED "BLUE") & Vehicle "STOP".
2. Connect GDS and select "Data Analysis" mode.
3. Select "Current Data" mode and monitor "Brake Switch ON_NO" and "Brake Switch ON_NC" parameter.
4. Is the measured data within specifications? YES Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-535818-S33216778562013031200000) " procedure. NO Go to " «SIGNAL CIRCUIT INSPECTION»(ref-535818-S17588583302013031200000) " procedure.

Scheme 445

Scheme 446

Scheme 447

1. Ignition ON (SSB LED "BLUE"). & Vehicle "STOP".
2. Connect GDS and select "Data Analysis" mode.
3. Select "Current Data" mode and monitor "12V Battery Voltage" parameter. Specification
4. Is parameter within specifications? YES Fault is intermittent and caused either by poor contact in connectors or wiring harness, or it has been repaired and Control Module memory is not cleared yet. Thoroughly check all connectors (and connections) for looseness, bending, corrosion, contamination, deterioration, and/or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535818-S02629147702013031200000) " procedure. NO Check in GDS the LDC System to confirm if there is 12V battery charging system malfunction. If LDC system DTC are found it must be diagnosed according to LDC section DTC procedures. Confirm health of the 12V battery by Micro - 570 Diagnostic Charger Tool, charge the 12V battery by the Micro - 570 tool if it displays CHARGE & RETEST, or replace the 12V battery if it displays REPLACE BATTERY or BAD CELL.

Non-compliance with the following instructions can induce death or injury caused by electric shock.

1. Carefully read and follow service manual instructions.
2. Wear insulated gloves, safety glasses and use insulated tools for your safety.
3. Turn the ignition switch off and Disconnect ground cable of auxiliary battery and Remove the safety plug.
4. Wait for more than 5 minutes so that the inverter capacitor can be naturally discharged.
5. Check high voltage terminal on Power Relay Assembly is lower than 30V.
6. Perform Resolver adaptation after the HPCU or the Driver Motor or the Generator(HSG) is replaced or reinstalled.
7. When replaced HPCU, Perform airbleeding for HPCU with GDS.

Scheme 448

Scheme 449

Scheme 450

1. Ignition ON (SSB LED "BLUE") & Vehicle "STOP".
2. Connect GDS and select "DTC Analysis" mode.
3. Click "DTC Status" on the menu bar to view DTC information.
4. Confirm that the "DTC Readiness Flag" indicates "COMPLETED". If not, drive the vehicle within conditions noted in Freeze Frame Data or Enable Conditions.
5. Read the "DTC Status" parameter.
6. Is parameter displayed "Present fault"? YES Go to Next procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or Control module's connector or was repaired and Control module's memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Monitoring with a DVOM on min/max or VMI while wiggling connectors may help find the problem. Any change in voltage indicate a possible problem. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535818-S37921094792013031200000) " procedure.

Non-compliance with the following instructions can induce death or injury caused by electric shock.

1. Carefully read and follow service manual instructions.
2. Wear insulated gloves, safety glasses and use insulated tools for your safety.
3. Turn the ignition switch off and Disconnect ground cable of auxiliary battery and Remove the safety plug.
4. Wait for more than 5 minutes so that the inverter capacitor can be naturally discharged.
5. Check high voltage terminal on Power Relay Assembly is lower than 30V.
6. Perform Resolver adaptation after the HPCU or the Driver Motor or the Generator(HSG) is replaced or reinstalled.
7. When replaced HPCU, Perform airbleeding for HPCU with GDS.

Scheme 451

Scheme 452

1. Ignition ON (SSB LED "BLUE") & Vehicle "STOP".
2. Connect GDS and select "Data Analysis" mode.
3. Select "Current Data" mode and monitor "E/C Fluid Pressure Offset stored" and "Engine Clutch Fluid Pressure" parameter. Specification
4. Is the measured data within specifications? YES Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-535818-S26747008992013031200000) " procedure. NO Go to " «SIGNAL CIRCUIT INSPECTION»(ref-535818-S28804387742013031200000) " procedure.

Scheme 453

Scheme 454

Scheme 455

1. Ignition ON (SSB LED "BLUE") & Vehicle "STOP".
2. Connect GDS and select "DTC Analysis" mode.
3. Click "DTC Status" on the menu bar to view DTC information.
4. Confirm that the "DTC Readiness Flag" indicates "COMPLETED". If not, drive the vehicle within conditions noted in Freeze Frame Data or Enable Conditions.
5. Read the "DTC Status" parameter.
6. Is parameter displayed "Present fault"? YES Go to Next procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or Control module's connector or was repaired and Control module's memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Monitoring with a DVOM on min/max or VMI while wiggling connectors may help find the problem. Any change in voltage indicate a possible problem. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535818-S34974569192013031200000) " procedure.

Non-compliance with the following instructions can induce death or injury caused by electric shock.

1. Carefully read and follow service manual instructions.
2. Wear insulated gloves, safety glasses and use insulated tools for your safety.
3. Turn the ignition switch off and Disconnect ground cable of auxiliary battery and Remove the safety plug.
4. Wait for more than 5 minutes so that the inverter capacitor can be naturally discharged.
5. Check high voltage terminal on Power Relay Assembly is lower than 30V.
6. Perform Resolver adaptation after the HPCU or the Driver Motor or the Generator(HSG) is replaced or reinstalled.
7. When replaced HPCU, Perform airbleeding for HPCU with GDS.

Scheme 456

Scheme 457

1. Ignition ON (SSB LED "BLUE") & Vehicle "STOP".
2. Connect GDS and select "Data Analysis" mode.
3. Select "Current Data" mode and monitor "E/C Fluid Pressure Offset stored" and "Engine Clutch Fluid Pressure" parameter. Specification
4. Is the measured data within specifications? YES Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-535818-S32182650272013031200000) " procedure. NO Go to " «SIGNAL CIRCUIT INSPECTION»(ref-535818-S12069228562013031200000) " procedure.

Scheme 458

Scheme 459

Scheme 460

1. Ignition ON (SSB LED "BLUE") & Vehicle "STOP".
2. Connect GDS and select "DTC Analysis" mode.
3. Click "DTC Status" on the menu bar to view DTC information.
4. Confirm that the "DTC Readiness Flag" indicates "COMPLETED". If not, drive the vehicle within conditions noted in Freeze Frame Data or Enable Conditions.
5. Read the "DTC Status" parameter.
6. Is parameter displayed "Present fault"? YES Go to Next procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or Control module's connector or was repaired and Control module's memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Monitoring with a DVOM on min/max or VMI while wiggling connectors may help find the problem. Any change in voltage indicate a possible problem. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535818-S18043851052013031200000) " procedure.

Non-compliance with the following instructions can induce death or injury caused by electric shock.

1. Carefully read and follow service manual instructions.
2. Wear insulated gloves, safety glasses and use insulated tools for your safety.
3. Turn the ignition switch off and Disconnect ground cable of auxiliary battery and Remove the safety plug.
4. Wait for more than 5 minutes so that the inverter capacitor can be naturally discharged.
5. Check high voltage terminal on Power Relay Assembly is lower than 30V.
6. Perform Resolver adaptation after the HPCU or the Driver Motor or the Generator(HSG) is replaced or reinstalled.
7. When replaced HPCU, Perform airbleeding for HPCU with GDS.

Scheme 461

Scheme 462

1. Ignition ON (SSB LED "BLUE") & Vehicle "STOP".
2. Connect GDS and select "Data Analysis" mode.
3. Select "Current Data" mode and monitor "E/C Fluid Pressure Offset stored" and "Engine Clutch Fluid Pressure" parameter. Specification
4. Is the measured data within specifications? YES Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-535818-S30665657782013031200000) " procedure. NO Go to " «SIGNAL CIRCUIT INSPECTION»(ref-535818-S16485077792013031200000) " procedure.
