Body Control Module (BCM) Hyundai Santa Fe III

Communication Devices 10 illustrations ~505 words

Specifications

ItemsSpecifications
Rated voltageDC 12V
Operating voltageDC 9 ~ 16V
Operating temperature30°C ~ 75°C (-21°F ~ 166°F)
Dark currentKeyless type: 5.5 mA Non keyless type: 3.0 mA SMK type: 4.5 mA

Scheme 1

Scheme 1: Components
Scheme 1: Components

Connector Pin Information

No.Connector AConnector BConnector CConnector D
1IGN1Head lamp low switchWiper low relayRoom lamp
2ACCAuto light switchBurglar alarm relayCornering lamp left relay
3Wiper INT volumeRear fog switchDoor unlock relay
4Auto light power
5K-LineWasher switchAssistant seat belt indicator
6Rear wiper switchHead lamp low signalLIN_PAS
7Rear wiper INT switchB_CAN High
8Inhibit R (M/T)Key hole illuminationB_CAN Low
9Defogger switchWiper low switchDoor lock relayC_CAN High
10Head lamp washer switchKey interlock switchRear wiper relayC_CAN Low
11Passing switchHead lamp high switchDriver door unlock relay
12Battery +Front fog switchRear fog relay
13IGN2PAS switch (RPAS OFF switch)Sunroof controlCornering lamp right relay
14Auto light sensorKey solenoid
15Auto light groundWiper high switchWiper high relayATM solenoid
16MTS inputWiper MIST switchPAS indicator (RPAS OFF indicator)
17Key in switchWiper INT switchExternal buzzer
18Tail switchRear washer switchAV tailDoor unlock output (AV)
19Brake switchSecurity indicator
20PTG option lineWiper parking stateMTS output
21Safety power window enable
22Crash inputGround enable
23Sunroof state
24Power groundLIN_Rain sensor

Scheme 2

Scheme 2: Circuit Diagram
Scheme 2: Circuit Diagram

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Body Control Module Controls The Followings

  1. Wiper & Washer Control
  2. Defroster Control
  3. Driving Control
  4. Tailgate Control
  5. Window Control
  6. Interior Control
  7. Exterior Control
  8. Panic alarm Control
  9. MTS
  10. Flasher output Control
  11. Door lock/unlock Control
  12. Burglar alarm Control
  13. Remote start Control
  14. UMS (User Mode Setting) Control
  15. Gateway/Diagnosis

Scheme 5

Scheme 5: Communication Network Diagram
Scheme 5: Communication Network Diagram
AbbreviationExplanation
C_CANChassis Controller Area Network
B_CANBody Controller Area Network
MM_CANMulti media Controller Area Network
SMKSmart Key ECU
DDMDriver Door Module
ADMAssist Door Module
PSMPower Seat Module
SJBSmart Junction Box
ESCElectronic Stabilty Control
SPASSmart Parking Assist System
SWRCSteering Wheel Remote Controller
PCUPower-train Control Unit
ECUEngine Control Unit
TCUTransmission Control Unit
EPBElectronic Parking Brake
ABSAnti-lock Brake System
BCMBody Control Module
SCCSmart Cruise Control
DATCDual Automatic Temp Control
MDPSMotor Driven Power Steering
SASSteering Angle Sensor
TPMSTire Pressure Monitoring System
ACUAirbag Control Unit
CLUCluster
HUHead Unit (Audio, AVN, MTS)

Function

  1. Wiper & Washer Control Front wiper MIST Control Function Front wiper INT Control Function Front wiper washer Control Function Front wiper low/high Control Function Head lamp washer Control Function Rear wiper low Control Function Rear wiper INT Control Function Rear wiper washer Control Function
  2. Defroster Control Rear defogger Control Function Front deicer control Function
  3. Driving Control Key interlock solenoid Control Function ATM solenoid Control Function
  4. Tailgate Control Tailgate open Control Function
  5. Window Control Power window main timer Control Function Safety power window Control Function Seat belt reminder Control Function Key reminder (Key operated warning) Control Function Parking brake Control Function RKE key teaching Control Function SMK system warning Control Function Alarm horn Control Function Sunroof open warning Control Function Rear area parking assist system Control Function
  6. Interior Control Room lamp Control Function Key hole illumination Control Function
  7. Exterior Control Tail lamp Control Function Head lamp DRL Control Function Head lamp high Control Function Head lamp welcome Control Function Escort Control Function Auto light Control Function DRL Control Function Front fog Control Function AV tail Control Function
  8. Panic alarm Control
  9. MTS Control
  10. Flasher output Control Alarm flashing Control Function Arm/Disarm flashing Control Function Panic flashing Control Function MTS flashing Control Function Tailgate open/close flashing Control Function Two turn unlock set/reset flashing Control Function Crash unlock flashing Control Function Remote start flashing Control Function
  11. Door lock/unlock Control Central door lock/unlock Control Function Mechanical door lock/unlock Control Function Two turn unlock Control Function SMK door lock/unlock Control Function RKE door lock/unlock Control Function MTS door unlock Control Function ATWS relock Control Function Auto door lock/unlock Control Function Crash unlock Control Function Key reminder unlock Control Function
  12. Burglar alarm Control
  13. Remote start Control

Scheme 6

Scheme 6: Removal
Scheme 6: Removal

Scheme 7

Scheme 7
Scheme 7
  1. Disconnect the negative (-) battery terminal.
  2. Remove the crash pad center panel. Refer to «CRASH PAD CENTER PANEL»(/hyundai/santa-fe/iii-2012-2016/remont/gauges-instrument-panels/#crash-pad) .
  3. Disconnect the body control module connectors (A).
  4. Remove the body control module (A) after loosening the nuts.

Installation

  1. Install the body control module.
  2. Connect the body control module.
  3. Install the crash pad center panel.

Scheme 8

Scheme 8: BCM Diagnosis With GDS
Scheme 8: BCM Diagnosis With GDS

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10
  1. The body control module can diagnose by using the GDS more quickly. The BCM communicates with the GDS and then reads the input/output value and drives the actuator.
  2. To diagnose the BCM function, select the menu of model and body control module.
  3. Select "Input/output monitoring", if you will check current data of body network system. It provides input/output status of each module. BCM service data, CLU service data, SJB service data
  4. If you will check each module data operation forcefully, select "Actuation test".
  5. If you want to change user option, select "user option".
