Cruise Control System Hyundai Santa Fe III

Cruise Control Systems 13 illustrations ~730 words

Scheme 1

Scheme 1: System Block Diagram
Component partFunction
Vehicle-speed sensorConverts vehicle speed to pulse.
ECMReceives signals from sensor and control switches.
Cruise control indicatorIlluminate when CRUISE switch is ON (Built into cluster)
Cruise Control switchesON/OFF switchSwitch for automatic speed control power supply.
RES+ switchControls automatic speed control functions by Resume/Accel switch (Set/Coast switch)
SET- switch
Cancel switchesCancel switchSends cancel signals to ECM.
Brake-pedal switch
Transaxle range switch (A/T)
ETS motorRegulates the throttle valve to the set opening by ECM.
* ETC System: Electronic Throttle Control System

COMPONENT PARTS AND FUNCTION OUTLINE

The cruise control system is engaged by the cruise "ON/OFF" main switch located on right of steering wheel column. The system has the capability to cruise, coast, accelerate and resume speed.

It also has a safety interrupt, engaged upon depressing brake or shifting select lever.

The ECM is the control module for this system. The main components of cruise control system are mode control switches, transmission range switch, brake switch, vehicle speed sensor, ECM and ETS motor that connect throttle body.

The ECM contains a low speed limit which will prevent system engagement below a minimum speed of 40 km/h (25 mph).

The operation of the controller is controlled by mode control switches located on steering wheel.

Transmission range switch and brake switch are provided to disengage the cruise control system. The switches are on brake pedal bracket and transmission. When the brake pedal is depressed or select lever shifted, the cruise control system is electrically disengaged and the throttle is returned to the idle position.

Cruise main switch (ON/OFF)

The cruise control system is engaged by pressing the cruise "ON/OFF" main switch. Pressing the cruise "ON/OFF" main switch again releases throttle, clears cruise memory speed, and puts vehicle in a non-cruise mode.

Set/Coast switch (SET/-)

The "SET/-" switch located on right of steering wheel column has two functions.

The set function - Push the "SET/-" switch and release it at the desired speed. The SET indicator light in the instrument cluster will illuminate. Release the accelerator pedal. The desired speed will automatically be maintained.

The coast function - Push the "SET/-" switch and hold it when the cruise control is on. The vehicle will gradually slow down. Release the switch at the desired speed. The desired speed will be maintained.

Push the "SET/-" switch and release it quickly. The cruising speed will decrease by 2.0 km/h (1.2 mph) or 1.6 km/h (1.0 mph).

Resume/Accel switch (RES/+)

The "RES/+" switch located on right of steering wheel column has two functions.

The resume function - If any method other than the cruise "ON/OFF" main switch was used to cancel cruising speed temporarily and the system is still activated, the most recent set speed will automatically resume when the "RES/+" switch is pushed. It will not resume, however, if the vehicle speed has dropped below approximately 40 km/h (25 mph).

The accel function - Push the "RES/+" switch and hold it when the cruise control is on. The vehicle will gradually accelerate. Release the switch at the desired speed. The desired speed will be maintained.

Push the "RES/+" switch and release it quickly. The cruising speed will increase by 2.0km/h (1.2mph) or 1.6km/h (1.0 mph).

Cancel switch (CANCEL)

The cruise control system is temporarily disengaged by pushing the "CANCEL" switch.

Cruise speed canceled by this switch can be recovered by pushing the "RES/+" switch.

Scheme 2

Scheme 2: Trouble Symptom 1

Trouble Symptom 2

Trouble symptomProbable causeRemedy
The set vehicle speed varies greatly upward or downward "Surging" (repeated alternating acceleration and deceleration) occurs after settingMalfunction of the vehicle speed sensor circuitRepair the vehicle speed sensor system, or replace the part
Malfunction of ECMCheck input and output signals at ECM

Trouble Symptom 3

Trouble symptomProbable causeRemedy
The CC system is not canceled when the brake pedal is depressedDamaged or disconnected wiring of the brake pedal switchRepair the harness or replace the brake pedal switch
Malfunction of the ECM signalsCheck input and output signals at ECM

Trouble Symptom 4

Trouble symptomProbable causeRemedy
The CC system is not canceled when the shift lever is moved to the "N" position (It is canceled, however, when the brake pedal is depressed)Damaged or disconnected wiring of inhibitor switch input circuitRepair the harness or repair or replace the inhibitor switch
Improper adjustment of inhibitor switch
Malfunction of the ECM signalsCheck input and output signals at ECM

Trouble Symptom 5

Trouble symptomProbable causeRemedy
Cannot decelerate (coast) by using the "SET/-" switchTemporary damaged or disconnected wiring of "SET/-" switch input circuitRepair the harness or replace the "SET/-" switch
Malfunction of the ECM signalsCheck input and output signals at ECM

Trouble Symptom 6

Trouble symptomProbable causeRemedy
Cannot accelerate or resume speed by using the "RES/+" switchDamaged or disconnected wiring, or short circuit, or "RES/+" switch input circuitRepair the harness or replace the "RES/+" switch
Malfunction of the ECM signalsCheck input and output signals at ECM

Trouble Symptom 7

Trouble symptomProbable causeRemedy
CC system can be set while driving at a vehicle speed of less than 40 km/h (25 mph), or there is no automatic cancellation at that speedMalfunction of the vehicle-speed sensor circuitRepair the vehicle speed sensor system, or replace the part
Malfunction of the ECM signalsCheck input and output signals at ECM

Trouble Symptom 8

Trouble symptomProbable causeRemedy
The cruise main switch indicator lamp does not illuminate (But CC system is normal)Damaged or disconnected bulb of cruise main switch indicator lampRepair the harness or replace the part.
Harness damaged or disconnected

Scheme 3

Scheme 3: Components

Scheme 4

Scheme 4: Circuit Diagram

Scheme 5

Scheme 5

Scheme 6

Scheme 6

Scheme 7

Scheme 7

Scheme 8

Scheme 8: Removal

Scheme 9

Scheme 9

Scheme 10

Scheme 10

Scheme 11

Scheme 11
  1. Disconnect the negative (-) battery terminal.
  2. Remove the driver airbag module. Refer to «DRIVER AIRBAG (DAB) MODULE AND CLOCK SPRING»(/hyundai/santa-fe/iii-2012-2016/remont/airbag/#airbag-modules-clock-spring) .
  3. Remove the steering wheel. Refer to «STEERING COLUMN AND SHAFT»(/hyundai/santa-fe/iii-2012-2016/remont/electronic-steering/#electric-power-steering) .
  4. Remove the steering wheel cover (A) after loosening the screws.
  5. Loosen the screws after disconnecting the steering wheel remote control switch connector (A).
  6. Remove the remote control switch (A).

Installation

  1. Install in the reverse order of removal.

Scheme 12

Scheme 12: Measuring Resistance
  1. Disconnect the cruise control switch connector from the control switch.
  2. Measure resistance between terminals on the control switch when each function switch is ON (switch is depressed). Function switch Terminal Resistance [kohms ± 5%] CANCEL 2 - 7 0.18 RES+ 2 - 7 0.33 SET- 2 - 7 0.55 CRUISE 2 - 7 0.88
  3. If not within specification, replace switch.

Scheme 13

Scheme 13: Measuring Voltage
  1. Connect the cruise control switch connector to the control switch.
  2. Measure voltage between terminals on the harness side connector when each function switch is ON (switch is depressed). Function switch Terminal Voltage (V) CANCEL 2 - 7 0.76 RES+ 2 - 7 1.41 SET- 2 - 7 2.05 CRUISE 2 - 7 2.66
  3. If not within specification, replace switch.
