Body Control Module (BCM) Diagnosis Hyundai Santa Fe III

DTC INDEX

DTC INDEX

Scheme 52

General Description

BCM (PAS) is a parking assistant system. It has a supersonic sensor which radiates supersonic to front and rear side of the vehicle to detect supersonic reflected from an obstacle. It calculates distances between vehicle and obstacle if it detects reflected supersonic. It warns being obstacle to drivers through buzzer or displaying on cluster according to distance from obstacle. Warning level is divided into 3 step (warning level rises progressively according to distance from obstacle)

DTC Description

This code reports an error in LIN line. The purpose is to verify the status of BCM (PAS), Sensor and Wire when error is detected at PAS of Front Left Side Sensor.

DTC Detecting Condition

Scheme 53

Scheme 54

1. Connect GDS.
2. IG "ON" and engine "OFF".
3. Select DTC Analysis mode.
4. After erase DTC, keep the vehicle condition within the enable conditions (Refer to " «DTC DETECTING CONDITION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis__dtc-detecting-condition) " table).
5. Is the same DTC occurred again? YES Go to next procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or BCM[PAS (Parking Assist System)]'s connector. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis__verification-of-vehicle-repair) " procedure.

Terminal and Connector Inspection

1. Many malfunctions in the electrical system are caused by poor harness (es) and terminals. Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
3. Has a problem been found? YES Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis__verification-of-vehicle-repair) " procedure. NO Go to " «POWER CIRCUIT INSPECTION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis__power-circuit-inspection) " procedure.

Power Circuit Inspection

1. Power Inspection IG "ON" & ENG "OFF". Measure the power voltage of "Front Left Side Sensor" at SJB (Smart Junction Box) Specification : Approx. 12V Is the signal output normal? YES Go to " 2 Ground Inspection" procedure. NO Thoroughly check fuses or connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis__verification-of-vehicle-repair) " procedure.
2. Ground Inspection IG "ON" & ENG "OFF". Measure voltage between power voltage of "Front Left Side Sensor" at SJB (Smart Junction Box) and ground terminal of "Front Left Side Sensor" or LID3 terminal of "Front Left Side Sensor". Specification : Approx.12V Is the signal output normal? YES Go to " 1 Inspection of LIN communication line between Front Left Side Sensor and BCM[PAS (Parking Assist System)]" NO Check a circuit between Front Left Side Sensor and chassis ground and poor connection. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis__verification-of-vehicle-repair) " procedure.

LIN communication line Inspection

1. Inspection of LIN communication line between Front Left Side Sensor and BCM[PAS (Parking Assist System)] Connect GDS and select "Oscilloscope". IG ON, ENG OFF and Shift lever D Set a stuff or obstacle near the Front Left Side Sensor Measure a waveform of LIN communication line between Front Left Side Sensor and BCM[PAS (Parking Assist System)] Specification : Refer to " «SIGNAL WAVEFORM»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " Is measured value normal? YES Fault is intermittent caused by BCM[PAS (Parking Assist System)] DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis__verification-of-vehicle-repair) " procedure. NO Check a circuit between Front Left Side Sensor and BCM[PAS (Parking Assist System)] and poor connection. And then repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis__verification-of-vehicle-repair) " procedure.

Verification of Vehicle Repair

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scantool and select DTC Analysis mode.
2. Clear the DTCs and Operate the vehicle within DTC Enable conditions in General information.
3. Is any DTC outputted again? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

ETM

For wiring diagram information, refer to appropriate SYSTEM WIRING DIAGRAMS article.

Scheme 55

BCM (PAS) is a parking assistant system. It has a supersonic sensor which radiates supersonic to front and rear side of the vehicle to detect supersonic reflected from an obstacle. It calculates distances between vehicle and obstacle if it detects reflected supersonic. It warns being obstacle to drivers through buzzer or displaying on cluster according to distance from obstacle. Warning level is divided into 3 step (warning level rises progressively according to distance from obstacle)

This code reports an error in LIN line. The purpose is to verify the status of BCM (PAS), Sensor and Wire when error is detected at PAS of Front Center Left Sensor.

Scheme 56

Scheme 57

1. Connect GDS.
2. IG "ON" and engine "OFF".
3. Select DTC Analysis mode.
4. After erase DTC, keep the vehicle condition within the enable conditions (Refer to " «DTC DETECTING CONDITION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " table).
5. Is the same DTC occurred again? YES Go to next procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or BCM[PAS (Parking Assist System)]'s connector. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Many malfunctions in the electrical system are caused by poor harness (es) and terminals. Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
3. Has a problem been found? YES Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Go to " «POWER CIRCUIT INSPECTION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Power Inspection IG "ON" & ENG "OFF". Measure the power voltage of "Front Center Left Sensor" at SJB (Smart Junction Box) Specification : Approx. 12V Is the signal output normal? YES Go to " 2 Ground Inspection" procedure. NO Thoroughly check fuses or connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.
2. Ground Inspection IG "ON" & ENG "OFF". Measure voltage between power voltage of "Front Center Left Sensor" at SJB (Smart Junction Box) and ground terminal of "Front Center Left Sensor", LID2 terminal of "Front Center Left Sensor" or LID3 terminal of "Front Center Left Sensor". Specification : Approx.12V Is the signal output normal? YES Go to " 1 Inspection of LIN communication line between Front Center Left Sensor and BCM[PAS (Parking Assist System)]" NO Check a circuit between Front Center Left Sensor and chassis ground and poor connection. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Inspection of LIN communication line between Front Center Left Sensor and BCM[PAS (Parking Assist System)] Connect GDS and select "Oscilloscope". IG ON, ENG OFF and Shift lever D Set a stuff or obstacle near the Front Center Left Sensor Measure a waveform of LIN communication line between Front Center Left Sensor and BCM[PAS (Parking Assist System)] Specification : Refer to " «SIGNAL WAVEFORM»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " Is measured value normal? YES Fault is intermittent caused by BCM[PAS (Parking Assist System)] DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Check a circuit between Front Center Left Sensor and BCM[PAS (Parking Assist System)] and poor connection. And then repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scantool and select DTC Analysis mode.
2. Clear the DTCs and Operate the vehicle within DTC Enable conditions in General information.
3. Is any DTC outputted again? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

For wiring diagram information, refer to appropriate SYSTEM WIRING DIAGRAMS article.

Scheme 58

BCM (PAS) is a parking assistant system. It has a supersonic sensor which radiates supersonic to front and rear side of the vehicle to detect supersonic reflected from an obstacle. It calculates distances between vehicle and obstacle if it detects reflected supersonic. It warns being obstacle to drivers through buzzer or displaying on cluster according to distance from obstacle. Warning level is divided into 3 step (warning level rises progressively according to distance from obstacle)

This code reports an error in LIN line. The purpose is to verify the status of BCM (PAS), Sensor and Wire when error is detected at PAS of Front Center Right Sensor.

Scheme 59

Scheme 60

1. Connect GDS.
2. IG "ON" and engine "OFF".
3. Select DTC Analysis mode.
4. After erase DTC, keep the vehicle condition within the enable conditions (Refer to " «DTC DETECTING CONDITION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " table).
5. Is the same DTC occurred again? YES Go to next procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or BCM[PAS (Parking Assist System)]'s connector. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Many malfunctions in the electrical system are caused by poor harness (es) and terminals. Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
3. Has a problem been found? YES Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Go to " «POWER CIRCUIT INSPECTION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Power Inspection IG "ON" & ENG "OFF". Measure the power voltage of "Front Center Right Sensor" at SJB (Smart Junction Box) Specification : Approx. 12V Is the signal output normal? YES Go to " 2 Ground Inspection" procedure. NO Thoroughly check fuses or connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.
2. Ground Inspection IG "ON" & ENG "OFF". Measure voltage between power voltage of "Front Center Right Sensor" at SJB (Smart Junction Box) and ground terminal of "Front Center Right Sensor", LID1 terminal of "Front Center Right Sensor" or LID3 terminal of "Front Center Right Sensor". Specification : Approx.12V Is the signal output normal? YES Go to " 1 Inspection of LIN communication line between Front Center Right Sensor and BCM[PAS (Parking Assist System)]" NO Check a circuit between Front Center Right Sensor and chassis ground and poor connection. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Inspection of LIN communication line between Front Center Right Sensor and BCM[PAS (Parking Assist System)] Connect GDS and select "Oscilloscope" IG ON, ENG OFF and Shift lever D Set a stuff or obstacle near the Front Center Right Sensor. Measure a waveform of LIN communication line between Front Center Right Sensor and BCM[PAS (Parking Assist System)] Specification : Refer to " «SIGNAL WAVEFORM»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " Is measured value normal? YES Fault is intermittent caused by BCM[PAS (Parking Assist System)] DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Check a circuit between Front Center Right Sensor and BCM[PAS (Parking Assist System)] and poor connection. And then repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scantool and select DTC Analysis mode.
2. Clear the DTCs and Operate the vehicle within DTC Enable conditions in General information.
3. Is any DTC outputted again? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

For wiring diagram information, refer to appropriate SYSTEM WIRING DIAGRAMS article.

Scheme 61

BCM (PAS) is a parking assistant system. It has a supersonic sensor which radiates supersonic to front and rear side of the vehicle to detect supersonic reflected from an obstacle. It calculates distances between vehicle and obstacle if it detects reflected supersonic. It warns being obstacle to drivers through buzzer or displaying on cluster according to distance from obstacle. Warning level is divided into 3 step (warning level rises progressively according to distance from obstacle)

This code reports an error in LIN line. The purpose is to verify the status of BCM (PAS), Sensor and Wire when error is detected at PAS of Front Right Side Sensor.

Scheme 62

Scheme 63

1. Connect GDS.
2. IG "ON" and engine "OFF".
3. Select DTC Analysis mode.
4. After erase DTC, keep the vehicle condition within the enable conditions (Refer to " «DTC DETECTING CONDITION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " table).
5. Is the same DTC occurred again? YES Go to next procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or BCM[PAS (Parking Assist System)]'s connector. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Many malfunctions in the electrical system are caused by poor harness (es) and terminals. Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
3. Has a problem been found? YES Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Go to " «POWER CIRCUIT INSPECTION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Power Inspection IG "ON" & ENG "OFF". Measure the power voltage of "Front Right Side Sensor" at SJB (Smart Junction Box) Specification : Approx. 12V Is the signal output normal? YES Go to " 2 Ground Inspection" procedure. NO Thoroughly check fuses or connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.
2. Ground Inspection IG "ON" & ENG "OFF". Measure voltage between power voltage of "Front Right Side Sensor" at SJB (Smart Junction Box) and ground terminal of "Front Right Side Sensor", LID1 terminal of "Front Right Side Sensor", LID2 terminal of "Front Right Side Sensor" or LID3 terminal of "Front Right Side Sensor". Specification : Approx.12V Is the signal output normal? YES Go to " 1 Inspection of LIN communication line between Front Right Side Sensor and BCM[PAS (Parking Assist System)]" NO Check a circuit between Front Right Side Sensor and chassis ground and poor connection. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Inspection of LIN communication line between Front Left Side Sensor and BCM[PAS (Parking Assist System)] Connect GDS and select "Oscilloscope" IG ON, ENG OFF and Shift lever D Set a stuff or obstacle near the Front Right Side Sensor. Measure a waveform of LIN communication line between Front Right Side Sensor and BCM[PAS (Parking Assist System)] Specification : Refer to " «SIGNAL WAVEFORM»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " Is measured value normal? YES Fault is intermittent caused by BCM[PAS (Parking Assist System)] DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Check a circuit between Front Right Side Sensor and BCM[PAS (Parking Assist System)] and poor connection. And then repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scantool and select DTC Analysis mode.
2. Clear the DTCs and Operate the vehicle within DTC Enable conditions in General information.
3. Is any DTC outputted again? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

For wiring diagram information, refer to appropriate SYSTEM WIRING DIAGRAMS article.

Scheme 64

BCM (PAS) is a parking assistant system. It has a supersonic sensor which radiates supersonic to front and rear side of the vehicle to detect supersonic reflected from an obstacle. It calculates distances between vehicle and obstacle if it detects reflected supersonic. It warns being obstacle to drivers through buzzer or displaying on cluster according to distance from obstacle. Warning level is divided into 3 step (warning level rises progressively according to distance from obstacle)

This code reports an error in LIN line. The purpose is to verify the status of BCM (PAS), Sensor and Wire when error is detected at PAS of Rear Left Side Sensor.

Scheme 65

Scheme 66

1. Connect GDS.
2. IG "ON" and engine "OFF".
3. Select DTC Analysis mode.
4. After erase DTC, keep the vehicle condition within the enable conditions (Refer to " «DTC DETECTING CONDITION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " table).
5. Is the same DTC occurred again? YES Go to next procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or BCM[PAS (Parking Assist System)]'s connector. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Many malfunctions in the electrical system are caused by poor harness (es) and terminals. Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
3. Has a problem been found? YES Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Go to " «POWER CIRCUIT INSPECTION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Power Inspection IG "ON" & ENG "OFF". Measure the power voltage of "Rear left side sensor" at SJB (Smart Junction Box) Specification : Approx. 12V Is the signal output normal? YES Go to " 2 Ground Inspection" procedure. NO Thoroughly check fuses or connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.
2. Ground Inspection IG "ON" & ENG "OFF". Measure voltage between power voltage of "Rear left side sensor" and ground terminal of "Rear left side sensor" at SJB (Smart Junction Box). Specification : Approx.12V Is the signal output normal? YES Go to " 1 Inspection of LIN communication line between Rear left side sensor and BCM[PAS (Parking Assist System)]" NO Check a circuit between Rear left side sensor and chassis ground and poor connection. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Inspection of LIN communication line between Rear left side sensor and BCM[PAS (Parking Assist System)] Connect GDS and select "Oscilloscope" IG ON, ENG OFF and Shift lever R Set a stuff or obstacle near the Rear left side sensor Measure a waveform of LIN communication line between Rear left side sensor and BCM[PAS (Parking Assist System)] Specification : Refer to " «SIGNAL WAVEFORM»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " Is measured value normal? YES Fault is intermittent caused by BCM[PAS (Parking Assist System)] DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Check a circuit between Rear left side sensor and BCM[PAS (Parking Assist System)] and poor connection. And then repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scantool and select DTC Analysis mode.
2. Clear the DTCs and Operate the vehicle within DTC Enable conditions in General information.
3. Is any DTC outputted again? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

For wiring diagram information, refer to appropriate SYSTEM WIRING DIAGRAMS article.

Scheme 67

BCM (PAS) is a parking assistant system. It has a supersonic sensor which radiates supersonic to front and rear side of the vehicle to detect supersonic reflected from an obstacle. It calculates distances between vehicle and obstacle if it detects reflected supersonic. It warns being obstacle to drivers through buzzer or displaying on cluster according to distance from obstacle. Warning level is divided into 3 step (warning level rises progressively according to distance from obstacle)

This code reports an error in LIN line. The purpose is to verify the status of BCM (PAS), Sensor and Wire when error is detected at PAS of Rear Center Left Sensor.

Scheme 68

Scheme 69

1. Connect GDS.
2. IG "ON" and engine "OFF".
3. Select DTC Analysis mode.
4. After erase DTC, keep the vehicle condition within the enable conditions (Refer to " «DTC DETECTING CONDITION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " table).
5. Is the same DTC occurred again? YES Go to next procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or BCM[PAS (Parking Assist System)]'s connector. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Many malfunctions in the electrical system are caused by poor harness (es) and terminals. Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
3. Has a problem been found? YES Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Go to " «POWER CIRCUIT INSPECTION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Power Inspection IG "ON" & ENG "OFF". Measure the power voltage of "Rear Center Left Sensor" at SJB (Smart Junction Box) Specification : Approx. 12V Is the signal output normal? YES Go to " 2 Ground Inspection" procedure. NO Thoroughly check fuses or connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.
2. Ground Inspection IG "ON" & ENG "OFF". Measure voltage between power voltage of "Rear Center Left Sensor" at SJB (Smart Junction Box) and ground terminal of "Rear Center Left Sensor" or LID2 terminal of "Rear Center Left Sensor". Specification : Approx.12V Is the signal output normal? YES Go to " 1 Inspection of LIN communication line between Rear Center Left Sensor and BCM[PAS (Parking Assist System)]" NO Check a circuit between Rear Center Left Sensor and chassis ground and poor connection. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Inspection of LIN communication line between Rear Center Left Sensor and BCM[PAS (Parking Assist System)] Connect GDS and select "Oscilloscope" IG ON, ENG OFF and Shift lever R Set a stuff or obstacle near the Rear Center Left Sensor. Measure a waveform of LIN communication line between Rear Center Left Sensor and BCM[PAS (Parking Assist System)] Specification : Refer to " «SIGNAL WAVEFORM»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " Is measured value normal? YES Fault is intermittent caused by BCM[PAS (Parking Assist System)] DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Check a circuit between Rear Center Left Sensor and BCM[PAS (Parking Assist System)] and poor connection. And then repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scantool and select DTC Analysis mode.
2. Clear the DTCs and Operate the vehicle within DTC Enable conditions in General information.
3. Is any DTC outputted again? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

For wiring diagram information, refer to appropriate SYSTEM WIRING DIAGRAMS article.

Scheme 70

BCM (PAS) is a parking assistant system. It has a supersonic sensor which radiates supersonic to front and rear side of the vehicle to detect supersonic reflected from an obstacle. It calculates distances between vehicle and obstacle if it detects reflected supersonic. It warns being obstacle to drivers through buzzer or displaying on cluster according to distance from obstacle. Warning level is divided into 3 step (warning level rises progressively according to distance from obstacle)

This code reports an error in LIN line. The purpose is to verify the status of BCM (PAS), Sensor and Wire when error is detected at PAS of Rear Center Right Sensor.

Scheme 71

Scheme 72

1. Connect GDS.
2. IG "ON" and engine "OFF".
3. Select DTC Analysis mode.
4. After erase DTC, keep the vehicle condition within the enable conditions (Refer to " «DTC DETECTING CONDITION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " table).
5. Is the same DTC occurred again? YES Go to next procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or BCM[PAS (Parking Assist System)]'s connector. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Many malfunctions in the electrical system are caused by poor harness (es) and terminals. Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
3. Has a problem been found? YES Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Go to " «POWER CIRCUIT INSPECTION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Power Inspection IG "ON" & ENG "OFF". Measure the power voltage of "Rear Center Right Sensor" at SJB (Smart Junction Box) Specification : Approx. 12V Is the signal output normal? YES Go to " 2 Ground Inspection" procedure. NO Thoroughly check fuses or connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.
2. Ground Inspection IG "ON" & ENG "OFF". Measure voltage between power voltage of "Rear Center Right Sensor" at SJB (Smart Junction Box) and ground terminal of "Rear Center Right Sensor" or LID1 terminal of "Rear Center Right Sensor". Specification : Approx.12V Is the signal output normal? YES Go to " 1 Inspection of LIN communication line between Rear Center Right Sensor and BCM[PAS (Parking Assist System)]" NO Check a circuit between Rear Center Right Sensor and chassis ground and poor connection. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Inspection of LIN communication line between Rear Center Right Sensor and BCM[PAS (Parking Assist System)] Connect GDS and select "Oscilloscope" IG ON, ENG OFF and Shift lever R Set a stuff or obstacle near the Rear Center Right Sensor Measure a waveform of LIN communication line between Rear Center Right Sensor and BCM[PAS (Parking Assist System)] Specification : Refer to " «SIGNAL WAVEFORM»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " Is measured value normal? YES Fault is intermittent caused by BCM[PAS (Parking Assist System)] DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Check a circuit between Rear Center Right Sensor and BCM[PAS (Parking Assist System)] and poor connection. And then repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scantool and select DTC Analysis mode.
2. Clear the DTCs and Operate the vehicle within DTC Enable conditions in General information.
3. Is any DTC outputted again? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

For wiring diagram information, refer to appropriate SYSTEM WIRING DIAGRAMS article.

Scheme 73

BCM (PAS) is a parking assistant system. It has a supersonic sensor which radiates supersonic to front and rear side of the vehicle to detect supersonic reflected from an obstacle. It calculates distances between vehicle and obstacle if it detects reflected supersonic. It warns being obstacle to drivers through buzzer or displaying on cluster according to distance from obstacle. Warning level is divided into 3 step (warning level rises progressively according to distance from obstacle)

This code reports an error in LIN line. The purpose is to verify the status of BCM (PAS), Sensor and Wire when error is detected at PAS of Rear Right Side Sensor.

Scheme 74

Scheme 75

1. Connect GDS.
2. IG "ON" and engine "OFF".
3. Select DTC Analysis mode.
4. After erase DTC, keep the vehicle condition within the enable conditions (Refer to " «DTC DETECTING CONDITION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " table).
5. Is the same DTC occurred again? YES Go to next procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or BCM[PAS (Parking Assist System)]'s connector. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Many malfunctions in the electrical system are caused by poor harness (es) and terminals. Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
3. Has a problem been found? YES Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Go to " «POWER CIRCUIT INSPECTION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Power Inspection IG "ON" & ENG "OFF". Measure the power voltage of "Rear Right side sensor" at SJB (Smart Junction Box) Specification : Approx. 12V Is the signal output normal? YES Go to " 2 Ground Inspection" procedure. NO Thoroughly check fuses or connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.
2. Ground Inspection IG "ON" & ENG "OFF". Measure voltage between power voltage of "Rear Center Left Sensor" at SJB (Smart Junction Box) and ground terminal of "Rear Right Sensor", LID1 terminal of "Rear Right Sensor" or LID2 terminal of "Rear Right Sensor". Specification : Approx.12V Is the signal output normal? YES Go to " 1 Inspection of LIN communication line between Rear Right Side Sensor and BCM[PAS (Parking Assist System)]" NO Check a circuit between Rear Right Side Sensor and chassis ground and poor connection. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Inspection of LIN communication line between Rear Right Side Sensor and BCM[PAS (Parking Assist System)] Connect GDS and select "Oscilloscope" IG ON, ENG OFF and Shift lever R Set a stuff or obstacle near the Rear Right Side Sensor Measure a waveform of LIN communication line between Rear Right Side Sensor and BCM[PAS (Parking Assist System)] Specification : Refer to " «SIGNAL WAVEFORM»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " Is measured value normal? YES Fault is intermittent caused by BCM[PAS (Parking Assist System)] DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Check a circuit between Rear Right Side Sensor and BCM[PAS (Parking Assist System)] and poor connection. And then repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scantool and select DTC Analysis mode.
2. Clear the DTCs and Operate the vehicle within DTC Enable conditions in General information.
3. Is any DTC outputted again? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

For wiring diagram information, refer to appropriate SYSTEM WIRING DIAGRAMS article.

Scheme 76

This is DTC which is related with communication error between BCM and other units.

* Body CAN communication Control Units: BCM (Body Control Module), DDM (Drive Door Module), ADM (Assist Door Module), SJB (Smart Junction Box), SMK (Smart Key Module)

*1 CAN (Controller Area Network): CAN is serial bus communication type which links not only communication system but also control units each other.

*2 LIN (Local Interconnect Network): LIN is serial communication type which is used in electrical control system. (This is less expensive.)

Scheme 77

This is DTC which is related with communication error between BCM and other units.

* Control Units: BCM (Body Control Module), DDM (Drive Door Module), ADM (Assist Door Module), PSM (Power Seat Module), SJB (Smart Junction Box), SMK (Smart Key Module).

Case1: After short between CAN Low Line and High Line, short to ground together.

Case2: After short between CAN Low Line and High Line, short to power together.

* This code is occurred when It is not possible to transmit data by CAN Line in those way of Software and Hardware. But, It is possible to receive data by CAN Line.

This code reports BUS OFF status when data transmit error count number is over 255. The purpose is to verify the status of CAN controller and CAN communication line when error is detected.

According to operation condition, some of module which are connected to CAN line may not detect B1603. Also, B1602 coincides with B1603 at all times.

Scheme 78

Scheme 79

Scheme 80

1. Connect GDS.
2. IG "ON" and engine "OFF".
3. Select "DTC Analysis" mode.
4. After erase DTC, keep the vehicle condition within "the enable conditions" (Refer to " «DTC DETECTING CONDITION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " table).
5. Is the same DTC occurred again? YES Go to next procedure. NO Fault is intermittent caused by poor contact in the BCM's connector or was repaired and BCM memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Many malfunctions in the electrical system are caused by poor harness (es) and terminals. Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
3. Has a problem been found? YES Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Go to " «BCM SIGNAL CIRCUIT INSPECTION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis__bcm-signal-circuit-inspection) " procedure.

BCM Signal Circuit Inspection

1. Check CAN High Line IG "ON" & ENG "OFF". After connect GDS, select "Oscilloscope" mode. Measure the signal waveform on BCM CAN High line. Specification : Refer to " «SIGNAL WAVEFORM»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " Does the measured signal waveform follow the specification? YES Go to " 2 CAN Low Line Inspection" procedure. NO Check short to battery or ground. Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.
2. Check CAN Low Line IG "ON" & ENG "OFF". After connect GDS, select "Oscilloscope" mode. Measure the signal waveform on BCM CAN Low line. Specification : Refer to " «SIGNAL WAVEFORM»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " Does the measured signal waveform follow the specification? YES Go to " «COMPONENT INSPECTION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis__component-inspection) " procedure. NO Check short to battery or ground. Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

Component Inspection

1. Check internal errors of CAN communication units. Connect GDS. IG "ON" and engine "OFF". Select "DTC Analysis" mode. Disconnect CAN communication units one by one and monitor DTC to find the cause. * CAN communication units: BCM (Body Control Module), DDM (Drive Door Module), ADM (Assist Door Module), PSM (Power Seat Module), SJB (Smart Junction Box), SMK (Smart Key Module) Is the code erased? YES Substitute with a known - good unit and check for proper operation. If the problem is corrected, replace the unit and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scantool and select "DTC Analysis" mode.
2. Clear the DTCs and Operate the vehicle within DTC Enable conditions in General information.
3. Is any DTC outputted again? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

For wiring diagram information, refer to appropriate SYSTEM WIRING DIAGRAMS article.

Scheme 81

This is DTC which is related with communication error between BCM and other units.

* Body CAN communication Control Units: BCM (Body Control Module), DDM (Drive Door Module), ADM (Assist Door Module), SJB (Smart Junction Box), SMK (Smart Key Module)

*1 CAN (Controller Area Network): CAN is serial bus communication type which links not only communication system but also control units each other.

*2 LIN (Local Interconnect Network): LIN is serial communication type which is used in electrical control system. (This is less expensive.)

Scheme 82

This code is outputted when BCM can't receive data from DDM by CAN Line for 10 sec.

Scheme 83

Scheme 84

Scheme 85

1. Connect GDS.
2. IG "ON" and engine "OFF".
3. Select "DTC Analysis" mode.
4. After erase DTC, keep the vehicle condition within "the enable conditions" (Refer to " «DTC DETECTING CONDITION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " table).
5. Is the same DTC occurred again? YES Go to next procedure. NO Fault is intermittent caused by poor contact in BCM's and/or DDM's connector or was repaired and BCM memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Many malfunctions in the electrical system are caused by poor harness (es) and terminals. Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
3. Has a problem been found? YES Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Go to " «DDM SIGNAL CIRCUIT INSPECTION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis__ddm-signal-circuit-inspection) " procedure.

DDM Signal Circuit Inspection

1. Check CAN High Line IG "ON" & ENG "OFF". After connect GDS, select "Oscilloscope" mode. Measure the signal waveform on DDM CAN High line. Specification : Refer to " «SIGNAL WAVEFORM»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " Does the measured signal waveform follow the specification? YES Go to " 2 CAN Low Line Inspection" procedure. NO Check short to battery or ground. Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.
2. Check CAN Low Line IG "ON" & ENG "OFF". After connect GDS, select "Oscilloscope" mode. Measure the signal waveform on DDM CAN Low line. Specification : Refer to " «SIGNAL WAVEFORM»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " Does the measured signal waveform follow the specification? YES Go to " «COMPONENT INSPECTION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Check short to battery or ground. Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Check internal errors of CAN communication units. Connect GDS. IG "ON" and engine "OFF". Select "DTC Analysis" mode. Replace DDM with the new one and check DTC again. Is the code erased? YES Substitute with a known - good unit and check for proper operation. If the problem is corrected, replace the unit and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scantool and select "DTC Analysis" mode.
2. Clear the DTCs and Operate the vehicle within DTC Enable conditions in General information.
3. Is any DTC outputted again? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

For wiring diagram information, refer to appropriate SYSTEM WIRING DIAGRAMS article.

Scheme 86

This is DTC which is related with communication error between BCM and other units.

* Body CAN communication Control Units: BCM (Body Control Module), DDM (Drive Door Module), ADM (Assist Door Module), SJB (Smart Junction Box), SMK (Smart Key Module)

*1 CAN (Controller Area Network): CAN is serial bus communication type which links not only communication system but also control units each other.

*2 LIN (Local Interconnect Network): LIN is serial communication type which is used in electrical control system. (This is less expensive.)

Scheme 87

This code is outputted when BCM can't receive data from ADM by CAN Line for 10 sec.

Scheme 88

Scheme 89

Scheme 90

1. Connect GDS.
2. IG "ON" and engine "OFF".
3. Select "DTC Analysis" mode.
4. After erase DTC, keep the vehicle condition within "the enable conditions" (Refer to " «DTC DETECTING CONDITION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " table).
5. Is the same DTC occurred again? YES Go to next procedure. NO Fault is intermittent caused by poor contact in BCM's and/or ADM's connector or was repaired and BCM memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Many malfunctions in the electrical system are caused by poor harness (es) and terminals. Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
3. Has a problem been found? YES Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Go to " «ADM SIGNAL CIRCUIT INSPECTION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis__adm-signal-circuit-inspection) " procedure.

ADM Signal Circuit Inspection

1. Check CAN High Line IG "ON" & ENG "OFF". After connect GDS, select "Oscilloscope" mode. Measure the signal waveform on ADM CAN High line. Specification : Refer to " «SIGNAL WAVEFORM»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " Does the measured signal waveform follow the specification? YES Go to " 2 CAN Low Line Inspection" procedure. NO Check short to battery or ground. Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.
2. Check CAN Low Line IG "ON" & ENG "OFF". After connect GDS, select "Oscilloscope" mode. Measure the signal waveform on ADM CAN Low line. Specification : Refer to " «SIGNAL WAVEFORM»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " Does the measured signal waveform follow the specification? YES Go to " «COMPONENT INSPECTION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Check short to battery or ground. Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Check internal errors of CAN communication units. Connect GDS. IG "ON" and engine "OFF". Select "DTC Analysis" mode. Replace ADM with the new one and check DTC again. Is the code erased? YES Substitute with a known - good unit and check for proper operation. If the problem is corrected, replace the unit and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scantool and select "DTC Analysis" mode.
2. Clear the DTCs and Operate the vehicle within DTC Enable conditions in General information.
3. Is any DTC outputted again? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

For wiring diagram information, refer to appropriate SYSTEM WIRING DIAGRAMS article.

Scheme 91

This is DTC which is related with communication error between BCM and other units.

* Body CAN communication Control Units: BCM (Body Control Module), DDM (Drive Door Module), ADM (Assist Door Module), SJB (Smart Junction Box), SMK (Smart Key Module)

*1 CAN (Controller Area Network): CAN is serial bus communication type which links not only communication system but also control units each other.

*2 LIN (Local Interconnect Network): LIN is serial communication type which is used in electrical control system. (This is less expensive.)

Scheme 92

This code is outputted when BCM can't receive data from SJB by CAN Line for 10 sec.

Scheme 93

Scheme 94

Scheme 95

1. Connect GDS.
2. IG "ON" and engine "OFF".
3. Select "DTC Analysis" mode.
4. After erase DTC, keep the vehicle condition within "the enable conditions" (Refer to " «DTC DETECTING CONDITION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " table).
5. Is the same DTC occurred again? YES Go to next procedure. NO Fault is intermittent caused by poor contact in BCM's and/or SJB's connector or was repaired and BCM memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Many malfunctions in the electrical system are caused by poor harness (es) and terminals. Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
3. Has a problem been found? YES Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Go to " «SJB SIGNAL CIRCUIT INSPECTION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis__sjb-signal-circuit-inspection) " procedure.

SJB Signal Circuit Inspection

1. Check CAN High Line IG "ON" & ENG "OFF". After connect GDS, select "Oscilloscope" mode. Measure the signal waveform on SJB CAN High line. Specification : Refer to " «SIGNAL WAVEFORM»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " Does the measured signal waveform follow the specification? YES Go to " 2 CAN Low Line Inspection" procedure. NO Check short to battery or ground. Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.
2. Check CAN Low Line IG "ON" & ENG "OFF". After connect GDS, select "Oscilloscope" mode. Measure the signal waveform on SJB CAN Low line. Specification : Refer to " «SIGNAL WAVEFORM»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " Does the measured signal waveform follow the specification? YES Go to " «COMPONENT INSPECTION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Check short to battery or ground. Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Check internal errors of CAN communication units. Connect GDS. IG "ON" and engine "OFF". Select "DTC Analysis" mode. Replace SJB with the new one and check DTC again. Is the code erased? YES Substitute with a known - good unit and check for proper operation. If the problem is corrected, replace the unit and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scantool and select "DTC Analysis" mode.
2. Clear the DTCs and Operate the vehicle within DTC Enable conditions in General information.
3. Is any DTC outputted again? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

For wiring diagram information, refer to appropriate SYSTEM WIRING DIAGRAMS article.

Scheme 96

This is DTC which is related with communication error between BCM and other units.

* Body CAN communication Control Units: BCM (Body Control Module), DDM (Drive Door Module), ADM (Assist Door Module), SJB (Smart Junction Box), SMK (Smart Key Module)

*1 CAN (Controller Area Network): CAN is serial bus communication type which links not only communication system but also control units each other.

*2 LIN (Local Interconnect Network): LIN is serial communication type which is used in electrical control system. (This is less expensive.)

Scheme 97

This code is outputted when BCM can't receive data from SMK by CAN Line for 10 sec.

Scheme 98

Scheme 99

Scheme 100

1. Connect GDS.
2. IG "ON" and engine "OFF".
3. Select "DTC Analysis" mode.
4. After erase DTC, keep the vehicle condition within "the enable conditions" (Refer to " «DTC DETECTING CONDITION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " table).
5. Is the same DTC occurred again? YES Go to next procedure. NO Fault is intermittent caused by poor contact in BCM's and/or SMK's connector or was repaired and BCM memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Many malfunctions in the electrical system are caused by poor harness (es) and terminals. Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
3. Has a problem been found? YES Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Go to " «SMK SIGNAL CIRCUIT INSPECTION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis__smk-signal-circuit-inspection) " procedure.

SMK Signal Circuit Inspection

1. Check CAN High Line IG "ON" & ENG "OFF". After connect GDS, select "Oscilloscope" mode. Measure the signal waveform on SMK CAN High line. Specification : Refer to " «SIGNAL WAVEFORM»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " Does the measured signal waveform follow the specification? YES Go to " 2 CAN Low Line Inspection" procedure. NO Check short to battery or ground. Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.
2. Check CAN Low Line IG "ON" & ENG "OFF". After connect GDS, select "Oscilloscope" mode. Measure the signal waveform on SMK CAN Low line. Specification : Refer to " «SIGNAL WAVEFORM»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " Does the measured signal waveform follow the specification? YES Go to " «COMPONENT INSPECTION»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Check short to battery or ground. Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

1. Check internal errors of CAN communication units. Connect GDS. IG "ON" and engine "OFF". Select "DTC Analysis" mode. Replace SMK with the new one and check DTC again. Is the code erased? YES Substitute with a known - good unit and check for proper operation. If the problem is corrected, replace the unit and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure. NO Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(/hyundai/santa-fe/iii-2012-2016/remont/communication-devices/#body-control-module-bcm-diagnosis) " procedure.

After a repair, it is essential to verify that the fault has been corrected.

1. Connect scantool and select "DTC Analysis" mode.
2. Clear the DTCs and Operate the vehicle within DTC Enable conditions in General information.
3. Is any DTC outputted again? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

For wiring diagram information, refer to appropriate SYSTEM WIRING DIAGRAMS article.

See also:
• DTC B121000
• DTC DETECTING CONDITION
• VERIFICATION OF VEHICLE REPAIR
• POWER CIRCUIT INSPECTION
• BCM SIGNAL CIRCUIT INSPECTION
• COMPONENT INSPECTION
• DDM SIGNAL CIRCUIT INSPECTION
• ADM SIGNAL CIRCUIT INSPECTION
• SJB SIGNAL CIRCUIT INSPECTION
• SMK SIGNAL CIRCUIT INSPECTION
