Testing & Diagnostics 3 illustrations ~229 words

Fuel Delivery System

ItemsSpecification
Fuel TankCapacity77 lit. (87.4 U.S.gal., 81.4 U.S.qt., 67.8 Imp.qt.)
Fuel FilterTypePaper type
Fuel PressureLow Pressure Fuel Line496.5 ~537.0 kPa (4.9 ~ 5.3 kgf/cm 2 , 72.0 ~ 77.9 psi)
High Pressure Fuel Line1.96 ~ 14.7 MPa (20.0 ~ 150.0 kgf/cm 2 , 284.5 ~ 2133.5 psi)
Fuel PumpTypeElectrical, in-tank type
Driven byElectric motor
High Pressure Fuel PumpTypeMechanical type
Driven byCamshaft

Sensors

Manifold Absolute Pressure Sensor (MAPS)

  1. Type: Piezo-resistive pressure sensor type
  2. Specification
Pressure [kPa (kgf/cm 2 , psi)]Output Voltage (V)
20.0 (0.20, 2.9)0.79
46.7 (0.47, 6.77)1.84
101.3 (1.03, 14.7)4.0

Intake Air Temperature Sensor (IATS)

  1. Type: Thermistor type
  2. Specification
TemperatureResistance (kohms)
°C°F
404040.93 ~ 48.35
20413.89 ~ 16.03
0325.38 ~ 6.09
10503.48 ~ 3.90
20682.31 ~ 2.57
401041.08 ~ 1.21
501221.56 ~ 1.74
601400.54 ~ 0.62
801760.29 ~ 0.34

Engine Coolant Temperature Sensor (ECTS)

  1. Type: Thermistor type
  2. Specification
TemperatureResistance (kohms)
°C°F
404048.14
20414.13 ~ 16.83
0325.79
20682.31 ~ 2.59
401041.15
601400.59
801760.32

Throttle Position Sensor (TPS) [integrated into ETC module]

  1. Type: Hall IC Non-contact sensor type
  2. Specification
Throttle angle(°)Output Voltage (V)
TPS1TPS2
00.54.5
100.964.05
201.413.59
301.873.14
402.322.68
502.782.23
603.231.77
703.691.32
804.140.86
904.60.41
984.650.35
C.T (0)0.54.5
W.O.T (86)4.410.59

Crankshaft Position Sensor (CKPS)

  1. Type: Magnetic field sensitive Type
  2. Specification
ItemSpecification
Coil Resistance (ohms)774 ~ 946 [20°C (68°F)]

Camshaft Position Sensor (CMPS)

  1. Type: Hall effect type

Knock Sensor (KS)

  1. Type: Piezo-electricity type
  2. Specification
ItemSpecification
Resistance (Mohms)4.87

Heated Oxygen Sensor (HO2S)

  1. Type: Zirconia (ZrO2) [Binary] Type
  2. Specification
A/F Ratio (lambda)Output Voltage (V)
RICH0.6 ~ 1.0
LEAN0 ~ 0.4
ItemSpecification
Heater Resistance (ohms)Approx. 9.0 [21°C (69.8°F)]

Rail Pressure Sensor (RPS)

Scheme 320

Scheme 320
Scheme 320
  1. Type: Piezo-electricity type
  2. Specification

Accelerator Position Sensor (APS)

  1. Type: Magnetic Field sensitive sensor
  2. Specification
Accelerator PositionOutput Voltage (V)
APS1APS2
C.T0.7 ~ 0.83.3 ~ 3.4
W.O.T3.8 ~ 4.41.9 ~ 2.2

Fuel Tank Pressure Sensor (FTPS)

  1. Type: Piezo - Resistivity type
  2. Specification
Pressure [kPa (kgf/cm 2 , in H2O)Output Voltage (V)
6.67 (-0.068, -26.8)0.5
02.5
+6.67 (0.068, 26.8)4.5

Actuators

Injector

  1. Specification
ItemSpecification
Coil Resistance (ohms)1.08 ~ 1.23 [23°C (73.4°F)]

ETC Motor [integrated into ETC Module]

  1. Specification
ItemSpecification
Coil Resistance (ohms)1.2 ~ 1.8 [20°C (68°F)]

Purge Control Solenoid Valve (PCSV)

  1. Specification
ItemSpecification
Coil Resistance (ohms)14.0 ~ 18.0 [20°C (68°F)]

CVVT Oil Control Valve (OCV)

  1. Specification
ItemSpecification
Coil Resistance (ohms)6.9 ~ 7.9 [20°C (68°F)]

Fuel Pressure Regulator Valve

  1. Specification
ItemSpecification
Coil Resistance (ohms)0.47 ~ 0.51 [20°C (68°F)]

Ignition Coil

  1. Type: Stick type
  2. Specification
ItemSpecification
Primary Coil Resistance (ohms)0.62 ± 10%[20°C (68°F)]
Secendary Coil Resistance (kohms)7.0 ± 15%[20°C (68°F)]

Canister Close Valve (CCV)

  1. Specification
ItemSpecification
Coil Resistance (ohms)23.0 ~ 26.0 (20°C)

Service Standard

ItemSpecification
Ignition Timing (°)7° ± 10°
Idle Speed (rpm)A/C OFFNeutral, N, P-range550±100rpm
D-range
A/C ONNeutral, N, P-range550±100rpm
D-range

Special Service Tools

Item Illustration Application Fuel Pressure Gauge (09353-24100) Measuring the fuel line pressure Fuel Pressure Gauge Adapter (09353-02100) Connection between the high pressure fuel pump and the fuel feed line Torque Wrench Socket (19mm) (09314-3Q100 or 09314-27130) Removal and installation of the high pressure fuel pipe Injector Combustion Seal Guide & Sizing tool (09353-2B000) Installation of the injector combustion seal

Scheme 321

Scheme 321: Special Service Tools
Scheme 321: Special Service Tools

Scheme 322

Scheme 322
Scheme 322
