Engine Control System - 4.6L: Removal & Installation Hyundai Genesis I рестайлинг

Testing & Diagnostics 2 illustrations ~187 words

Removal

Note. In the case of the vehicle equipped with immobilizer, perform " KEY TEACHING " procedure together (Refer to BE group).

Scheme 91

Scheme 91: Removal
Scheme 91: Removal

Scheme 92

Scheme 92
Scheme 92
  1. Turn ignition switch OFF and disconnect the negative (-) battery cable.
  2. Remove the cover
  3. Disconnect the ECM connector (A) and the TCM connector (B).
  4. Remove the ECM & TCM bracket installation bolts (C) and nut (D).
  5. After removing the installation bolts (A), remove the ECM (B) from the bracket.

Installation

Note. In the case of the vehicle equipped with immobilizer, perform " KEY TEACHING " procedure together (Refer to BE group).

  1. Installation is reverse of removal. ECM installation bolt/nut: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
  1. Installation is the reverse of removal. CVVT oil control valve installation bolt: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: Pay attention to color of valve connector (Harness side) when installing. If an OCV is installed on opposite manifold, the engine may be damaged. CONNECTOR COLOR Item Component Side Harness Side Intake Black Gray Exhaust Black Black
