Specification
| Throttle angle(°) | Output Voltage (V) |
| TPS1 | TPS2 |
| 0 | 0.5 | 4.5 |
| 10 | 0.96 | 4.05 |
| 20 | 1.41 | 3.59 |
| 30 | 1.87 | 3.14 |
| 40 | 2.32 | 2.68 |
| 50 | 2.78 | 2.23 |
| 60 | 3.23 | 1.77 |
| 70 | 3.69 | 1.32 |
| 80 | 4.14 | 0.86 |
| 90 | 4.6 | 0.41 |
| 98 | 4.65 | 0.35 |
| C.T (0) | 0.5 | 4.5 |
| W.O.T (86) | 4.41 | 0.59 |
THROTTLE POSITION SENSOR SPECIFICATION
Scheme 323
| Item | Specification |
| Coil Resistance (ohms) | 1.2 ~1.8 [20°C (68°F)] |
Scheme 324
Scheme 324: Circuit Diagram
| Pressure [kPa (kgf/cm 2 , psi)] | Output Voltage (V) |
| 20.0 (0.20, 2.9) | 0.79 |
| 46.7 (0.47, 6.77) | 1.84 |
| 101.3 (1.03, 14.7) | 4.0 |
Scheme 325
Scheme 326
Scheme 326: Circuit Diagram
| Temperature | Resistance (kohms) |
| °C | °F |
| 40 | 40 | 40.93 ~ 48.35 |
| 20 | 4 | 13.89 ~ 16.03 |
| 0 | 32 | 5.38 ~ 6.09 |
| 10 | 50 | 3.48 ~ 3.90 |
| 20 | 68 | 2.31 ~ 2.57 |
| 40 | 104 | 1.08 ~ 1.21 |
| 60 | 140 | 0.54 ~ 0.66 |
| 80 | 176 | 0.29 ~ 0.34 |
Scheme 327
Scheme 327: Circuit Diagram
| Temperature | Resistance (kohms) |
| °C | °F |
| 40 | 40 | 48.14 |
| 20 | 4 | 14.13 ~ 16.83 |
| 0 | 32 | 5.79 |
| 20 | 68 | 2.31 ~ 2.59 |
| 40 | 104 | 1.15 |
| 60 | 140 | 0.59 |
| 80 | 176 | 0.32 |
Scheme 328
Scheme 328: Circuit Diagram
| Item | Specification |
| Coil Resistance (ohms) | 774 ~ 946 [20°C (68°F)] |
| Air cap (mm) | 0.5 ~ 1.5 |
Scheme 329
This example shows a typical Crankshaft Position Sensor (CKPS) and Camshaft Position Sensor (CMPS) waveform at idle.
Scheme 330
Scheme 330: Circuit Diagram
| Item | Specification |
| Capacitance (pF) | 950 ~ 1, 350 |
Scheme 331
Scheme 331: Circuit Diagram
Scheme 332
Scheme 333
Scheme 334
Scheme 335
- Turn the ignition switch OFF and disconnect the battery negative (-) cable.
- Remove the intake manifold (Refer to " «INTAKE MANIFOLD»(/hyundai/genesis/i-2011-2016/remont/exhaust/#intake-and-exhaust-system-50l) " in EM group).
- Disconnect the knock sensor connector (A). [Bank 1] [Bank 2]
- Remove the cross over fuel pipe (A).
- Remove the installation bolt (A), and then remove the sensor from the cylinder block.
| A/F Ratio (lambda) | Output Voltage (V) |
| RICH | 0.6 ~ 1.0 |
| LEAN | 0 ~ 0.4 |
| Item | Specification |
| Heater Resistance (ohms) | Approx. 9.0 [21°C (69.8°F)] |
Scheme 336
Scheme 337
Scheme 338
Scheme 339
Scheme 339: Circuit Diagram
| Pedal Position | Output Voltage (V) [Vref = 5.0V] |
| APS1 | APS2 |
| C.T | 0.58 ~ 0.93 | 0.33 ~ 0.43 |
| W.O.T | 3.85 ~ 4.35 | 1.93 ~ 2.18 |
Scheme 340
Scheme 341
Scheme 341: Circuit Diagram
| Pressure [kPa (kgf/cm 2 , in H2O) | Output Voltage (V) |
| 6.67 (-0.068, -26.8) | 0.5 |
| 0 | 2.5 |
| +6.67 (0.068, 26.8) | 4.5 |
Scheme 342
Scheme 343
Scheme 343: Circuit Diagram
| Item | Specification |
| Coil Resistance (ohms) | 1.08 ~ 1.23 [23°C (73.4°F)] |
Scheme 344
Scheme 344: Signal Waveform
Scheme 345
Scheme 345: Circuit Diagram
| Item | Specification |
| Coil Resistance (ohms) | 14.0 ~ 18.0 [20°C (68°F)] |
Scheme 346
Scheme 346: Circuit Diagram
| Item | Specification |
| Coil Resistance (ohms) | 6.9 ~ 7.9 [20°C (68°F)] |
Scheme 347
Scheme 347: Circuit Diagram
| Item | Specification |
| Coil Resistance (ohms) | 0.47 ~ 0.51 [20°C (68°F)] |
Scheme 348
Scheme 348: Signal Waveform
Scheme 349
Scheme 349: Circuit Diagram
| Item | Specification |
| Coil Resistance (ohms) | 23.0 ~ 26.0 [20°C (68°F) |
Scheme 350
Scheme 350: Circuit Diagram
