Description
Evaporative Emission Control System prevents fuel vapor stored in fuel tank from vaporizing into the atmosphere. When the fuel evaporates in the fuel tank, the vapor passes through vent hoses or tubes to canister filled with charcoal. The canister temporarily holds the vapor in the charcoal. If ECM determines to draw the gathered vapor into the combustion chambers during certain operating conditions, it will vacuum into intake manifold.
Scheme 286
A ratchet tightening device on the threaded fuel filler cap reduces the chances of incorrect installation, which would seal the fuel filler. After the gasket on the fuel filler cap and the filler neck flange contact each other, the ratchet produces a loud clicking noise indicating the seal has been set.
Scheme 287
Scheme 288
Scheme 289
Scheme 290
- Turn the ignition switch OFF and disconnect the negative (-) battery cable.
- Remove the service cover (A).
- Disconnect the canister close valve connector (A).
- Disconnect the vapor hose (B) from the canister.
- Remove the installation bolt (C).
- Disconnect the vapor hose (A) from the connector assembly (B).
- Remove the fuel tank air filter after removing the connector assembly installation bolts (C).
- Install a new fuel tank assembly. Ventilation hose connector assembly installation: 3.9 ~ 5.9 N.m (0.4 ~ 0.6 kgf.m, 2.9 ~ 4.3 lb-ft)
