Integrated Memory System (Ims): Specifications — Hyundai Genesis I рестайлинг (2011-2016)

Integrated Memory System (Ims): Specifications Hyundai Genesis I рестайлинг

IMS Input/Output Specification

Pin	Designation	Input/Output	Remark
A2	Seat FRT Height Up Motor	O
A3	Seat RR Height Up Motor	O
A4	Seat Rec FRT Motor	O
A5	Seat Slide FRT Motor	O
A6
A7	Seat FRT Height Down Motor	O
A8
A9
A10	Seat RR Height Down Motor	O
A11	Seat Rec RR Motor	O
A12	Seat Slide RR Motor	O
B1	Power VB	I	BAT
B2
B3	Power VB	I	BAT
B4	GROUND1		GND
B5	GROUND2		GND
C1	Seat Slide FRT Limit SW	I	NORMAL CLOSE
C2	Seat Rec FRT Limit SW	I	NORMAL CLOSE
C3	Seat FRT Height UpSW	I	ON: GND
C4	Seat Slide FRT SW	I	ON: GND
C5	Seat Rec FRT SW	I	ON: GND
C6	Slide RR Sensor	I	PULSE SIGNAL
C7	Rec RR Sensor	I	PULSE SIGNAL
C8	Slide FRT Sensor	I	PULSE SIGNAL
C9	RR Height Up Sensor	I	PULSE SIGNAL
C10	SENSOR VB	I	BAT
C11	Seat Slide RR Limit SW	I	NORMAL CLOSE
C12	Seat Rec RR Limit SW	I	NORMAL CLOSE
C13	Seat FRT Height Down SW	I	ON: GND
C14	Seat Slide RR SW	I	ON: GND
C15	Seat Rec RR SW	I	ON: GND
C16	FRT Height Down Sensor	I	PULSE SIGNAL
C17	RR Height Down Sensor	I	PULSE SIGNAL
C18	Rec FRT Sensor	I	PULSE SIGNAL
C19	FRT Height Up Sensor	I	PULSE SIGNAL
C20	SENSOR GND		GND
D1	Seat FRT Height Up Limit SW	I	NORMAL CLOSE
D2	Seat RR Height Up Limit SW	I	NORMAL CLOSE
D3	Seat RR Height Up SW	I	ON: GND
D4	CAN Hi	I/o
D5	CAN Low	I/o
	Seat RR Height Down SW	I	ON: GND
D7	IGN1 PSM	I	BAT
D8	POWER VB	I	BAT
D9	Seat FRT Height Down Limit SW	I	NORMAL CLOSE
D10	Seat RR Height Down Limit SW	I	NORMAL CLOSE
D11
D12
D13
D14
D15
D16	ECU GND		GND

Scheme 39: Removal

Remove the negative(-) battery terminal.
Remove the seats in the car. (Refer to the «FRONT SEAT»(/hyundai/genesis/i-2011-2016/remont/seats/#seat-power-seat) )
Remove the IMS module (A) after loosening 4 screws and 4 connectors in the botton of seat.
