Installation
- Reassemble the IMS module after connecting the connectors.
- Reassemble the seats in the car.
Scheme 46
| Pin | Connector A | Connector B |
|---|---|---|
| 1 | Rear recline motor | B+ |
| 2 | B+ | Inflate upper bladder |
| 3 | Deflate upper bladder | |
| 4 | Inflate lower bladder | |
| 5 | Rear height limit motor down | Deflate lower bladder |
| 6 | Rear height limit motor up | Pump signal |
| 7 | ||
| 8 | Rear slide motor | |
| 9 | Front slide motor | |
| 10 | ||
| 11 | Front recline motor | |
| 12 | ||
| 13 | ||
| 14 | ||
| 15 | Front height limit motor down | |
| 16 | ||
| 17 | Front height limit motor up | |
| 18 |
- Connect the connectors and reassemble the power seat control switch.
- Reassemble the recliner cover and seat front cover.
Scheme 47
Scheme 48
- Remove the seat control switch.
- With the power seat control switch in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the power seat control switch.
Scheme 49
Scheme 50
Scheme 51
Scheme 52
Scheme 53
- Disconnect the negative (-) battery terminal.
- Remove the front door trim panel (A). (Refer to the «FRONT DOOR»(ref-590394-S42377900762013121700000) )
- Remove the door trim garnish (A) after removing the screws inside the door trim.
- After removing the mounting screws (3EA) and switch connector, then remove the IMS control switch.
- Connect the connectors and reassemble the IMS control switch.
- Install the door trim garnish and door trim.
- Connect the negative (-) battery terminal.
Scheme 54
Scheme 55
- Remove the IMS control switch.
- With the power IMS control switch in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the IMS control switch.
