Body Control Module (BCM): Specifications Hyundai Genesis I рестайлинг

Communication Devices 2 illustrations

Specifications

ItemsSpecifications
Rated voltageDC 12V
Operating voltageDC 9 ~ 16V
Operating temperature30°C ~ 75°C (-4°F ~ 158°F)
FAM operating temperature40°C ~ 105°C (-40°F ~ 221°F)
Insulation resistanceIPM: 3mA
DDM: 2mA
ADM: 2mA
SCM: 2mA
IMS: 2mA
PDM: 1mA
FAM: 1mA

Scheme 1

Scheme 1: Components
Scheme 1: Components

Scheme 2

Scheme 2: Schematic Diagrams
Scheme 2: Schematic Diagrams

IPM: Instrument Panel Module

FAM: Front Area Module

DDM: Driver Door Module

ADM: Assist Door Module

SCM: Steering Control Module

SMK: Smart Key

PDM: Power Distribution Module

CLU: Cluster

MFSW: Multi Function Switch

PSM: Power Seat Module

FBWS: Front Back Warning System

PTM: Power Trunk Module

ECW: Electronic Control Wiper

ESCL: Electronic Steering Column Lock
