Integrated Memory System (Ims): Overview Hyundai Genesis I рестайлинг

Communication Devices 4 illustrations ~284 words

Scheme 42

Scheme 42: Component Location

Scheme 43

Scheme 43: Communication System

Scheme 44

Scheme 44: Circuit Diagram

Description

Seat, steering column and mirror positions set by the driver are memorized in the IMS control unit by the position sensors. So, those positions can be returned to the memorized positions by the IMS control switch even when the seat, steering column and mirror positions are changed. (This is called replay operation). In addition, CAN communication is performed between power seat control unit and power window. For the sake of safety, replay is prohibited during driving and replay operation can be stopped immediately.

Scheme 45

Scheme 45: IMS Connectors
PinConnector AConnector BConnector CConnector D
1Battery (power)Slide front limit switchFront height up limit switch
2Front height motor upRecline front limit switchRear height up limit switch
3Rear height motor upBattery (power)Front height up manual switchRear height up manual switch
4Recline motor frontGND (power)Slide front manual switchCAN high
5Slide motor frontGND (power)Recline front manual switchCAN low
6Slide rear sensorRear height down manual switch
7Front height motor downIGN1
8Slide front sensorB+
9Rear height up sensorFront height down limit switch
10Rear height motor downSensor Vcc (seat)Rear height down limit switch
11Recline motor rearSlide rear limit switch
12Slide motor rearRecline rear limit switch
13Front height down manual switch
14Slide rear manual switch
15Recline rear manual switch
16Front height down sensorGND
17Rearheight down sensor
18Recline sensor
19Front height up sensor
20Sensor GND

CONNECTOR PIN NAME

Driver may choose and store the best seat position at the memory power seat unit using the memory switch and the position sensor, in order to restore the seat position at once.

There are CAN communication for data transmission and reception between the memory power seat unit and the driver side door module. The operation is inhibited for safety during driving.

Manual Operation

  1. Motor operation by the seat manual switch (Slide, reclining, front height and rear height control)
  2. Seat position setting and 4-way simultaneous operation can be made by the manual switch operation.

Driver may choose and store the best steering column position at the tilt & telescope unit using the memory switch and the position sensor, in order to restore the steering column position at once.

There are CAN communication for data transmission and reception between the memory power seat unit and the driver side door module. The operation is inhibited for safety during driving.

  1. Motor operation by the manual switch (Tilt & telescope steering column tilt up & down, telescope forward & backward)
  2. Manual switch operation auto stop by limit switch OFF.
