Body Network System: Other Hyundai Genesis I рестайлинг

Communication Devices 4 illustrations ~1120 words

Power Window Control

  1. This switch controls power window up/down, automatic up/down from driver & assist side. Driver's power window switch sends input signal through CAN communication by the manual up/down and automatic up/down switch input. At the same time passenger side sends manual up/down and automatic up/down signals to the wires. Each safety window ECU receives the signal and performs manual up/down and automatic up/down functions.
  2. Power window lock When the driver's power window lock switch is ON, each safety window ECU receives the power window lock command to prohibit the operation by the passenger side doors except the driver's door.
  3. Timer function Power window switch can be controlled for 30 seconds after the ignition is turned off. This function stops immediately even within 30 seconds if the front door is opened.

Key Reminder

  1. If door is locked by using door lock knob after opening door while IGN KEY is inserted to KEY CYLINDER, Unlock output will be for 1sec and there will be a series of three output signals every 0.5sec if door condition is "Lock".
  2. Remained action goes on though Key Reminder Unlock message changes to "OFF".

Priority Of Door Lock/unlock

  1. Higher priority signals take precedence, and will override lower priority signals.
  2. If the priority is the same or low, it'll be ignored.

Out Side Mirror Control By The Switch

  1. If the mirror direction switch (up, down, left and right) is pressed when mirror selection switch on driver side power window switch is in outside LH (RH) under ACC ON condition, then mirror motor moves to the corresponding direction.

Fail Safe Function

  1. If the sensor does not move more than 60mV for the input changes (5 second operation) of the position sensor although the motor is operating, automatic control will stop.
  2. The mirror operation signal cannot be displayed into the same direction for more than 15 seconds. (When the mirror is replacing to the saved position or the switch is manually pressed)
  3. Monitoring the replacing time If the replacing operation does not stop within 40 seconds, the mirror motor will not outputted and the replacing operation will stop.

IMS Switch

  1. If it's satisfied with the followings Can communication Data ignition switch sent by IPM is "RUN" Can communication Data Inhibit switch sent by IPM is "P" Can communication Data vehicle speed sent by CLUSTER is under "3Km/h"
  2. If SET switch is ON, IMS message is SET.
  3. If POSITION switch is ON within 5sec since SET switch is ON, IMS message will be sent to MEMORY1 or MEMORY2.

Seat Manual Switch

If Seat switch is controlled, seat control message is sent to seat.

Scheme 68

Scheme 68: Removal
Scheme 68: Removal

Scheme 69

Scheme 69
Scheme 69
  1. Disconnect the negative (-) battery terminal.
  2. Remove the front door trim panel (Refer to the «FRONT DOOR»(ref-590394-S42377900762013121700000) )
  3. Remove the door module (DDM) (A) from the front door trim panel after disconnecting module connector. Be careful not to damage the door module removing the clip.
  4. Remove the door module (A) from the front door trim panel.
  1. This switch controls power window up/down from assist side. According to the input of assist Door module window, up/down switch, output window motor up/down. Power window up/down control from assist side.
  2. Timer function Power window switch can be controlled for 30 seconds after the ignition is turned off. This function stops immediately even within 30 seconds if the front door is opened.

Crash Unlock

  1. Under the condition "IGN ON", if Crash Sensor message from IPM is ON, Door UNLOCK is output. (5 ± 0.5sec)

Auto Door Lock

  1. If the vehicle is under any of the following conditions and the condition lasts for 3sec, all doors is locked. If message from IPM is "Door Lock Control = LOCK ALL", it will be locked for 0.5sec. IGN "RUN" or "START" ALT L ON (Engine is running) Speed of the vehicle is 40Km/h If any door is on "UNLOCK"
  2. After LOCK output, if any door is not locked, there will be a series of three Lock output every 0.5sec.
  3. If all doors are locked during a series of three output signals, output will be stopped.
  4. If any door is not locked after a series of three output signals, output will be stopped.
  1. If door is locked by using door lock knob after opening door while IGN KEY is inserted to KEY CYLINDER, Unlock output will be for 1sec and there will be a series of three output signals every 0.5sec if door condition is "Lock".
  2. Remained action goes on though Key Reminder Unlock message changes to "OFF".
  1. Higher priority signals take precedence, and will override lower priority signals.
  2. If the priority is the same or low, it'll be ignored.

Out Side Mirror Fold/unfold Power Control

  1. Supply folding power for 30sec after ACC ON or ACC OFF.
  2. FOLD/UNFOLD operation is controlled by fold switch.
  1. Manual control of left outside mirror If the mirror direction switch (up, down, left and right) is pressed when mirror selection switch on driver side power window switch is in outside LH under ACC ON condition, then mirror motor moves to the corresponding direction.
  2. Manual control of right outside mirror If the mirror direction switch (up, down, left and right) is pressed when mirror selection switch on driver side power window switch is in outside RH under ACC ON condition, then operating signal is sent to passenger side power window switch through CAN communication.
  1. If the sensor does not move more than 60mV for the input changes (5 second operation) of the position sensor although the motor is operating, it will be considered there is a harness cutting, motor breakdown, or sensor breakdown and automatic control will stop.
  2. The mirror operation signal cannot be displayed into the same direction for more than 15 seconds. (When the mirror is replacing to the saved position or the switch is manually pressed)
  3. Monitoring the replacing time If the replacing operation does not stop within 40 seconds, the mirror motor will not outputted and the replacing operation will stop.

Scheme 70

Scheme 70: Removal
Scheme 70: Removal

Scheme 71

Scheme 71
Scheme 71
  1. Disconnect the negative (-) battery terminal.
  2. Remove the front door trim panel (Refer to the «FRONT DOOR»(ref-590394-S42377900762013121700000) )
  3. Remove the door module (ADM) (A) from the front door trim panel after disconnecting module connector. Be careful not to damage the door module removing the clip.
  4. Remove the door module (A) from the front door trim panel.

FAM (Front Area Module)

The FAM includes the functions for the following list

  1. Wiper control (Rain sensor communication and transfer Rain sensor request information to Wiper module)
  2. Lamp control (Tail, Head Lamp Low and High, Front fog, Room Lamp Auto Cut, Rear Fog lamp Control)
  3. Turn Signal Control
  4. External Buzzer and Burglar Alarm Horn control
  5. Input signal sends via CAN for local functions (Hood switch, DRL option)
