Body Network System: Overview Hyundai Genesis I рестайлинг

Scheme 65

Abbreviation description

IPM: Instrument Panel Module

FAM: Front Area Module

DDM: Driver Door Module

ADM: Assist Door Module

SCM: Steering Control Module

SMK: Smart Key

PDM: Power Distribution Module

CLU: Cluster

MFSW: Multi Function Switch

PSM: Power Seat Module

FBWS: Front Back Warning System

PTM: Power Trunk Module

ECW: Electronic Control Wiper

ESCL: Electronic Steering Column Lock

Description

The driver door module is a part of a Controller Area Network (CAN), and performs CAN communication with the FAM, IPM, ADM, and IMS. Driver controls driver side power window switch button located inside of the driver side door to operate power window, mirror, door lock and unlock.

1. Two manual operations (up and down) for four p/windows. However, on the driver's seat the auto up/down operation must be possible.
2. Opening and closing the quarter glass by the quarter glass switch.
3. Window UP/DOWN operation.
4. Manually operating the mirror position by the manual switch (Up, Down, Right, and Left)
5. Saving and replacing the mirror position by the MEMORY switch --> For 2 persons
6. Out side mirror AUTO reverse operation
7. Out side mirror FOLD/UNFOLD power control
8. CENTRAL DOOR LOCK/UNLOCK function
9. Illumination control

Outside Mirror Memory Operation By The Memory Switch

1. If position switch (POS1 or POS2) is pressed within 5 seconds after pressing the memory switch under ignition 2 on, it registers current mirror position. (Memory permit status lasts for 5 seconds after memory switch ON. After 5 seconds, memory permits status terminates. In other words, current position is registered if the position switch (POS1 or POS2) is turned on, during the memory permit status). However, RH side mirror position is not registered during the LH side mirror manual switch operation.
2. Memory permit status is released if any of the following conditions is met If 5 seconds is elapsed after the memory switch is turned on If the ignition 2 is turned off When saving is completed If Ignition switch of the CAN communication data sent by the IPM is not "Run" or "Start". If Inhibit switch of the CAN communication data sent by the FAM is not "P". If vehicle speed of the CAN communication data sent by the cluster is "3Km/h" or more.
3. Memory is cleared if the battery is removed.

Outside Mirror Memory And Replay Operation By Keyless

1. Memory operation Outside mirror LH position is registered in the driver side power window switch when the ignition is turned off from on.
2. Replay prohibit condition If the mirror switch on the LH side is pressed If Ignition switch of the CAN communication data sent by the IPM is not "Run" or "Start". If Inhibit switch of the CAN communication data sent by the IPM is not "P". If vehicle speed of the CAN communication data sent by the CLUSTER is "3Km/h" or more.

AUTO REVERSE FUNCTION

The assist door module is a part of CAN, and performs CAN communication with the FAM, IPM, DDM, and IMS. The driver can control the power window, mirror, door (lock/unlock) by using buttons of the ADM on the door of the driver's seat.

1. Operating the power window by buttons
2. Central Door LOCK/UNLOCK function
3. Manually operating the mirror position by the manual SW (Up, Down, Right, and Left)
4. Saving and replacing the mirror position by the memory switch --> For 2 persons
5. Out side mirror AUTO reverse operation
6. Illumination control

1. IMS Message from DDM is sent to RETURN1 or RETURN2, out side mirror returns to the position stored.
2. Memory permit status is released if any of the following conditions is met If 5 seconds is elapsed after the memory switch is turned on If the ignition 2 is turned off When saving is completed If Ignition switch of the CAN communication data sent by the IPM is not "Run" or "Start". If Inhibit switch of the CAN communication data sent by the FAM is not "P". If vehicle speed of the CAN communication data sent by the cluster is "3Km/h" or more.
3. Memory is cleared if the battery is removed

Outside Mirror Memory And Replay Operation By The Memory Switch

1. IMS message from DDM is sent to RETURN1 or RETURN2, O/S MIRROR returns to the position stored.
2. Replacing not stored position doesn't work.
3. If RETURN Message is sent during replacing, the last Message has priority.
4. Replacing Prohibition Conditions. If the mirror switch on the LH side is pressed If Ignition switch of the CAN communication data sent by the IPM is not "Run". If Inhibit switch of the CAN communication data sent by the IPM is not "P". If vehicle speed of the CAN communication data sent by the CLUSTER is "3Km/h".

AUTO REVERSE FUNCTION
