DTC P2552: ETCS Control Module Relay Malfunction Honda S2000 AP2 рестайлинг

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 99

Scheme 100

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Do the ETCS TEST in the INSPECTION MENU with the HDS. Is the RELAY circuit OK? YES - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the ETCS control module relay, the throttle actuator control module, and the ECM. NO - Go to step 4 .
4. Turn the ignition switch OFF.
5. Jump the SCS line with the HDS.
6. Remove the ETCS control module relay (A).
7. Disconnect ECM connector D (17P).
8. Check for continuity between ECM connector terminal D15 and body ground. Is there continuity? YES - Repair short in the wire between the ETCS control module relay and the ECM (D15), then go to step 10 . NO - Go to step 9 .
9. Test the ETCS control module relay (see «POWER RELAY TEST»(ref-221386-S33182512862006022400000) ). Is the relay OK? YES - Go to step 17 . NO - Replace the ETCS control module relay, then go to step 10.
10. Reconnect ECM connector D (17P).
11. Turn the ignition switch ON (II).
12. Reset the ECM with the HDS.
13. Do the ECM idle learn procedure (see «ECM IDLE LEARN PROCEDURE»(ref-221342-S09897997502006022400000) ).
14. Turn the ignition switch OFF.
