Electronic Throttle Control System: Diagnosis Honda S2000 AP2 рестайлинг

Testing & Diagnostics 2 illustrations ~371 words

DTC Troubleshooting

DTCDescription
P0122TP Sensor A Circuit Low Voltage
P0123TP Sensor A Circuit High Voltage
P0222TP Sensor B Circuit Low Voltage
P0223TP Sensor B Circuit High Voltage
P1683Throttle Valve Default Position Spring Performance Problem
P1684Throttle Valve Return Spring Performance Problem
P2101Throttle Actuator System Malfunction
P2108Throttle Actuator Control Module Problem
P2118Throttle Actuator Current Range/Performance Problem
P2122APP Sensor A (TP Sensor D) Circuit Low Voltage
P2123APP Sensor A (Throttle Position Sensor D) Circuit High Voltage
P2127APP Sensor B (TP Sensor E) Circuit Low Voltage
P2128APP Sensor B (Throttle Position Sensor E) Circuit High Voltage
P2135TP Sensor A/B Incorrect Voltage Correlation
P2138APP Sensor A/B (TP Sensor D/E) Incorrect Voltage Correlation
P2176Throttle Actuator Control System Idle Position Not Learned
P2552ETCS Control Module Relay Malfunction
U0107Lost Communication With Throttle Actuator Control Module

DTC INDEX

APP Sensor Signal Inspection

Note. This procedure checks the APP sensor in its fully closed position. In any other position, the APP sensor stores DTCs which are covered in other troubleshooting procedures. Check for Temporary DTCs or DTCs with the HDS before doing this procedure. If any DTCs are indicated, troubleshoot them first, then do this procedure. Press the accelerator pedal several times to check its operation. If it does not operate properly, check the pedal, the throttle cable, and the APP sensor individually. If you find a problem in one of them, replace the part(s) that caused the problem.

Scheme 52

Scheme 52: APP Sensor Signal Inspection
Scheme 52: APP Sensor Signal Inspection
  1. Connect the HDS to the data link connector (DLC) (A) located behind the driver's side of the front console.
  2. Turn the ignition switch ON (II).
  3. Make sure the HDS communicates with the vehicle and the ECM. If it doesn't, go to the DLC circuit troubleshooting (see «DLC CIRCUIT TROUBLESHOOTING»(ref-351945-S34342936082009122900000) ).
  4. Make sure the accelerator pedal is not pressed, then check the APP SENSOR in the DATA LIST with the HDS. If it is below 2%, the APP sensor is OK. If it is above 2%, adjust the throttle cable (see «THROTTLE CABLE ADJUSTMENT»(ref-221344-S11008582622006022400000) ), then go to step 5.
  5. Make sure the accelerator pedal is not pressed, then check the APP SENSOR in the DATA LIST with the HDS. If it is below 2%, the APP sensor is OK. If it is above 2%, update the ECM if it does not have the latest software, or substitute a known-good ECM (see «UPDATING THE ECM»(ref-221338-S06618208692006022400000) ), then go to step 6.
  6. Make sure the accelerator pedal is not pressed, then check the APP SENSOR in the DATA LIST with the HDS. If it is below 2%, the APP sensor is OK. If it is above 2%, replace the APP sensor (see «APP SENSOR REPLACEMENT»(ref-221340-S24350517622006022400000) ), then go to step 1 .

Scheme 53

Scheme 53: Throttle Actuator Control Module Replacement
Scheme 53: Throttle Actuator Control Module Replacement
  1. Remove the passenger's dashboard lower cover (see «PASSENGER'S DASHBOARD LOWER COVER REMOVAL/INSTALLATION»(ref-221367-S01244536242006022400000) ).
  2. Push the tab (A), and disconnect the throttle actuator control module 16P connector (B).
  3. Remove the nuts (C), and the throttle actuator control module (D).
  4. Install the control module in the reverse order of removal.
