DTC P0122: TP Sensor A Circuit Low Voltage Honda S2000 AP2 рестайлинг

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 54

Scheme 55

Scheme 56

Scheme 57

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Check TP SENSOR A in the DATA LIST with the HDS. Is there about 0.3 V or less? YES - Go to step 4 . NO - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the throttle body and the throttle actuator control module.
4. Check for Temporary DTCs or DTCs with the HDS. Are DTC P0122 and P0222 indicated at the same time? YES - Go to step 9 . NO - Go to step 5 .
5. Turn the ignition switch OFF.
6. Disconnect the throttle body 6P connector.
7. Disconnect the throttle actuator control module 16P connector.
8. Check for continuity between throttle body 6P connector terminal No. 1 and body ground. Is there continuity? YES - Repair short in the wire between the throttle body and the throttle actuator control module (TPSA line), then go to step 17 . NO - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(ref-221340-S38247836402006022400000) ), then go to step 17 and recheck. If DTC P0122 is not indicated, replace the original throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(ref-221340-S38247836402006022400000) ), then go to step 17 . If DTC P0122 is indicated, go to step 15 .
9. Measure voltage between throttle body 6P connector terminal No. 2 and body ground. Is there about 5 V? YES - Go to step 15 . NO - Go to step 10 .
10. Turn the ignition switch OFF.
11. Disconnect the throttle actuator control module 16P connector (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(ref-221340-S38247836402006022400000) ).
12. Disconnect the throttle body 6P connector.
13. Connect throttle body 6P connector terminal No. 2 to body ground with a jumper wire.
14. Check for continuity between throttle actuator control module 16P connector terminal No. 11 and body ground. Is there continuity? YES - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(ref-221340-S38247836402006022400000) ), then go to step 17 and recheck. If DTC P0122 is not indicated, replace the original throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(ref-221340-S38247836402006022400000) ), then go to step 17 . If DTC P0122 is indicated, go to step 15. NO - Repair open in the wire between the throttle body and the throttle actuator control module (VCC line), then go to step 17 .
15. Turn the ignition switch OFF.
16. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(ref-221344-S10447299522006022400000) ).
17. Reconnect all connectors.
18. Turn the ignition switch ON (II).
19. Reset the ECM with the HDS.
20. Do the ECM idle learn procedure (see «ECM IDLE LEARN PROCEDURE»(ref-221342-S09897997502006022400000) ).
21. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0122 is indicated, check for poor connections or loose terminals at the throttle body and the throttle actuator control module, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - Troubleshooting is complete.
