DTC P2118: Throttle Actuator Current Range/Performance Problem Honda S2000 AP2 рестайлинг

Testing & Diagnostics 2 illustrations ~316 words

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 76

Scheme 76: DTC P2118: Throttle Actuator Current Range/Performance Problem
Scheme 76: DTC P2118: Throttle Actuator Current Range/Performance Problem

Scheme 77

Scheme 77
Scheme 77
  1. Disconnect the throttle actuator control module 16P connector (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(ref-221340-S38247836402006022400000) ).
  2. Measure resistance between throttle actuator control module 16P connector terminals No. 1 and No. 8. Is there about 1.0 ohms or less? YES - Go to step 3 . NO - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(ref-221340-S38247836402006022400000) ), then go to step 6 and recheck. If DTC P2118 is not indicated, replace the original throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(ref-221340-S38247836402006022400000) ), then go to step 6 .
  3. Disconnect the throttle body 6P connector.
  4. At throttle body side, measure resistance between throttle body 6P connector terminals No. 5 and No. 6 with the throttle fully closed. Is there about 1.0 ohms or less? YES - Go to step 5 . NO - Repair short in the wires between the throttle body and the throttle actuator control module (motor drive lines), then go to step 6 .
  5. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(ref-221344-S10447299522006022400000) ).
  6. Reconnect all connectors.
  7. Turn the ignition switch ON (II).
  8. Reset the ECM with the HDS.
  9. Do the ECM idle learn procedure (see «ECM IDLE LEARN PROCEDURE»(ref-221342-S09897997502006022400000) ).
  10. Turn the ignition switch OFF.
  11. Turn the ignition switch ON (II).
  12. Slowly press the accelerator pedal to the floor.
  13. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P2118 is indicated, check for poor connections or loose terminals at the throttle body and the throttle actuator control module, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - Troubleshooting is complete.
