DTC P0123: TP Sensor Circuit High Voltage Honda Element I

Testing & Diagnostics 2 illustrations ~406 words

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 89

Scheme 89: DTC P0123: TP Sensor Circuit High Voltage
Scheme 89: DTC P0123: TP Sensor Circuit High Voltage

Scheme 90

Scheme 90
Scheme 90
  1. Turn the ignition switch ON (II).
  2. Check the TP SENSOR in the DATA LIST with the HDS. Is there about 0.5 V when the throttle is fully closed, and about 4.5 V when the throttle is fully opened? YES- Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the TP sensor and the ECM/PCM. NO- Go to step 3 .
  3. Turn the ignition switch OFF.
  4. Disconnect the TP sensor 3P connector.
  5. Turn the ignition switch ON (II).
  6. At the wire harness side, measure voltage between TP sensor 3P connector terminals No. 1 and No. 3. Is there about 5 V? YES- Go to step 8 . NO- Go to step 7 .
  7. Measure voltage between ECM/PCM connector terminals A20 and A23. Is there about 5 V? YES- Repair open in the wire between the ECM/PCM (A23) and the TP sensor, then go to step 10 . NO- Go to step 15 .
  8. Turn the ignition switch OFF.
  9. Replace the throttle body (the TP sensor is not available separately) (see «THROTTLE BODY REMOVAL/INSTALLATION»(ref-220574-S07939558072006022000000) ).
  10. Reconnect all connectors.
  11. Turn the ignition switch ON (II).
  12. Reset the ECM/PCM with the HDS.
  13. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(ref-220572-S08440202922006022000000) ).
  14. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES- If DTC P0123 is indicated, check for poor connections or loose terminals at the TP sensor and the ECM/PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO- Troubleshooting is complete.
  15. Update the ECM/PCM if it does not have the latest software, or substitute a known-good ECM/PCM (see «ECM/PCM UPDATING AND SUBSTITUTION FOR TESTING»(ref-220569-S23624043112006022000000) ).
  16. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES- If DTC P0123 is indicated, check for poor connections or loose terminals at the TP sensor and the ECM/PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO- If the ECM/PCM was updated, troubleshooting is complete. If the ECM/PCM was substituted, replace the original ECM/PCM (see «MAP SENSOR REPLACEMENT»(ref-220570-S17955277902006022000000) ).
